| General |
| Comments | Small windscreen. Riding Modes Rain and Road. | - |
| Year | - | 2026 |
| Colours | Racing Blue Metallic, Racing Red Matt | - |
| Make Model | - | KTM 690 Enduro R |
| Dimensions |
| Wheelbase (in.) | 61.9 inches | - |
| Storage | Saddle bags. | - |
| Seat Height (mm) | 890 mm | - |
| Seat Height (in.) | 35.0 inches | - |
| Length (mm) | 2,305 mm | - |
| Length (in.) | 90.7 inches | - |
| Height (mm) | 1,450 mm | - |
| Height (in.) | 57.1 inches | - |
| Width (mm) | 925 mm | - |
| Width (in.) | 36.4 inches | - |
| Wheelbase (mm) | 1,573 mm | - |
| Seat Height | 890 mm / 35.0 in. | 935 mm / 36.8 in |
| Wheelbase | 1,573 mm / 61.9 in. | 1506 mm / 59.3 in |
| Ground Clearance | - | 265 mm / 10.4 in |
| Height | 1,450 mm / 57.1 in. | - |
| Length | 2,305 mm / 90.7 in. | - |
| Width | 925 mm / 36.4 in. | - |
| Weights & Capacities |
| Wet Weight (lbs.) | 511.5 pounds | - |
| Wet Weight (kg) | 232.0 kg | 162 |
| Fuel Capacity (l) | 24.00 litres | - |
| Fuel Capacity (gal.) | 6.34 gallons | - |
| Dry Weight (lbs.) | 423.3 pounds | - |
| Dry Weight (kg) | 192 | - |
| Dry Weight | 192 kg / 423.3 lbs | - |
| Fuel Capacity | 24.00 litres / 6.34 gallons | 13.3 Litres / 3.5 US gal |
| Wet Weight | 232.0 kg / 511.5 lbs | 162 kg / 357 lbs |
| Performance |
| Top Speed (mph.) | 119.9 mph | - |
| Top Speed (km/h) | 193.0 km/h | - |
| Top Speed | 193.0 km/h / 119.9 mph | - |
| Max Power | - | 79 hp / 58.1 kW |
| Max Torque | 83.00 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 5750 Revolutions | 73 Nm / 54 lb-ft |
| Power-to-Weight Ratio | 0.4427 HP/kg | - |
| Engine |
| Bore x Stroke (mm) | 82.0 x 75.6 mm | - |
| Bore x Stroke (in,) | 3.2 x 3.0 inches | - |
| Engine Type | Twin, four-stroke | - |
| Fuel Control | Double Overhead Cams/Twin Cam (DOHC) | - |
| Fuel Reserve (gal.) | 1.06 gallons | - |
| Fuel Reserve (l) | 4.00 litres | - |
| Displacement (cc) | 798.00 cc | - |
| CO2 | 99.8 CO2 g/km. (CO2 - Carbon dioxide emission) | - |
| Displacement (ci) | 48.69 cubic inches | - |
| Displacement | - | 692.7 cc / 42.27 cu in |
| Engine Detail | - | Single cylinder, 4-stroke, SOHC, 4-valve |
| Fuel System | Injection. Electronic intake pipe injection, digital engine management (BMS-K+) | - |
| Compression Ratio | 12.0:1 | - |
| Cooling System | - | Liquid cooled |
| Engine Lubrication | Dry sump | - |
| Exhaust | - | Stainless steel primary and secondary silencer |
| Fuel Consumption | 4.30 litres/100 km (23.3 km/l or 54.70 mpg) | - |
| Fuel Induction | - | Keihin EFI (throttle body 50 mm) |
| Fuel Reserve | 4.00 litres / 1.06 gallons | - |
| Ignition | - | Keihin EMS with RBW, double ignition |
| Lubrication System | - | Pressure lubrication with 2 oil pumps |
| Starter | Electric | Electric |
| Valve System | 4 | - |
| Drivetrain |
| Clutch | Multiple-disc clutch in oil bath, mechanically operated | PASC slipper clutch, hydraulically operated |
| Final Drive | Chain | Chain, 520 X-ring |
| Gearbox | 6-speed | - |
| Primary Drive | Endless O-ring chain with shock damping in rear wheel hub | - |
| Transmission / Drive | - | 6-Speed |
| Chassis |
| Wheel Travel - Rear (mm) | 215 mm | - |
| Wheel Travel - Front (in.) | 9.1 inches | - |
| Trail (in.) | 4.6 inches | - |
| Trail (mm) | 117 mm | - |
| Wheel Travel - Front (mm) | 230 mm | - |
| Wheel Travel - Rear (in.) | 8.5 inches | - |
| Frame Type | Tubular steel space frame, load-bearing engine | Chromium-molybdenum-steel trellis frame, powder coated |
| Suspension - Front | Upside-down fork | WP USD XPLOR 48 forks, compression and rebound adjustable |
| Suspension - Rear | Aluminium double sided swing-arm at the rear | WP XPLOR shock absorber with Pro-Lever linkage, preload adjuster |
| Rake | 26.0° | - |
| Steering Head Angle | - | 62.3° |
| Subframe | - | Self-supporting plastic tank |
| Trail | 117 mm / 4.6 in. | 120 mm / 4.7 in |
| Wheel Travel - Front | 230 mm / 9.1 in. | 265 mm / 10.4 in |
| Wheel Travel - Rear | 215 mm / 8.5 in. | 250 mm / 9.8 in |
| Wheels & Brakes |
| Brakes - Front Diameter (in.) | 11.8 inches | - |
| Brakes - Front Diameter (mm) | 300 mm | - |
| Brakes - Rear Diameter (in.) | 10.4 inches | - |
| Brakes - Rear Diameter (mm) | 265 mm | - |
| Brakes - Front | Double disc. ABS | Single 300 mm disc, Brembo 2 piston floating caliper |
| Brakes - Rear | Single disc. ABS | Single 240 mm disc, Brembo single piston floating caliper |
| ABS | - | Bosch 9.1 MP (incl. Cornering ABS and offroad mode, disengageable) |
| Rims | Spoke wheels | - |
| Tyres - Front | 90/90-21 | 90/90 -21 |
| Tyres - Rear | 150/70-17 | 140/80 -18 |
| Wheels - Front | - | Spoked wheels with aluminum rims, 1.85 x 21″ |
| Wheels - Rear | - | Spoked wheels with aluminum rims, 2.50 x 18″ |
