| General |
| Comments | - | Windscreen. Bluetooth Audio and Apple CarPlay/Android auto. |
| Year | 200 | - |
| Colours | - | Matte Iridium Grey Metallic |
| Make Model | BMW R 1200RT | - |
| Warranty | - | Transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan. |
| Dimensions |
| Wheelbase (mm) | 1,480 mm | 1694 mm |
| Height (mm) | - | 1430 mm |
| Storage | - | Saddle bags, top box, glovebox (121 L total) |
| Width (in.) | - | 36.4 inches |
| Width (mm) | - | 925 mm |
| Ground Clearance (mm) | - | 130 mm |
| Ground Clearance (in.) | - | 5.1 inches |
| Height (in.) | - | 56.3 inches |
| Wheelbase (in.) | 58.3 inches | 66.7 inches |
| Seat Height (mm) | 820 mm | 745 mm |
| Seat Height (in.) | 32.3 inches | 29.3 inches |
| Length (mm) | 2,230 mm | 2615 mm |
| Length (in.) | 87.8 inches | 103.0 inches |
| Seat Height | 820 mm - 840 mm / 32.2 in - 33.0 in 780 mm - 800 mm / 30.7 - 31.4 in (special equipment low seat bench) | 745 mm / 29.3 in. |
| Wheelbase | 1485 mm / 58.4 in | 1694 mm / 66.7 in. |
| Ground Clearance | 155 mm / 6.1 in | - |
| Height | - | 1430 mm / 56.3 in. |
| Length | 2230 mm / 79.9 in | 2615 mm / 103.0 in. |
| Width | 905 mm / 35.6 in (incl. mirrors) 980 mm / 38.5 in (incl. panniers) | 925 mm / 36.4 in. |
| Weights & Capacities |
| Wet Weight (kg) | 259 | 367.0 kg |
| Wet Weight (lbs.) | - | 809.1 pounds |
| Oil Capacity (Quarts) | - | 5.92 US quarts |
| Dry Weight (kg) | 229 | - |
| Dry Weight (lbs.) | 504.9 pounds | - |
| Fuel Capacity (gal.) | 7.13 gallons | 5.57 US gallons |
| Fuel Capacity (l) | 27.00 litres | 21.10 litres |
| Oil Capacity (l) | - | 5.60 litres |
| Dry Weight | 229 kg / 485.0 lbs | - |
| Fuel Capacity | 27 Liters / 7.1 US gal | 21.10 litres / 5.57 US gallons |
| Wet Weight | 259 kg / 570.9 lbs | 367.0 kg / 809.1 lbs |
| Performance |
| Top Speed | 210 km/h / 130.5 mph | - |
| Acceleration (60-140 km/h) | 9.8 sec | - |
| Max Power | 81kW / 110 hp @ 7500 rpm | - |
| Max Torque | 115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm | 170.0 Nm (17.3 kgf-m or 125.4 ft.lbs) @ 4500 rpm |
| Power-to-Weight Ratio | 0.4803 HP/kg | - |
| Standing Start 0-100 km | 3.7 sec | - |
| Standing Start ¼ Mile | 12.2 sec | - |
| Engine |
| CO2 | - | 127.4 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel Control | - | Single Overhead Cams (SOHC) |
| Bore x Stroke (in,) | 4.0 x 2.9 inches | 2.9 x 2.9 inches |
| Stroke | 4 | - |
| Engine Type | Two cylinder boxer | Six cylinder boxer, four-stroke |
| Displacement (ci) | 71.39 cubic inches | 111.85 cubic inches |
| Displacement (cc) | 1170.00 cc | 1833.0 cc |
| Bore x Stroke (mm) | 101.0 x 73.0 mm | 73.0 x 73.0 mm |
| Displacement | 1170 cc / 71.4 cu in | - |
| Engine Detail | Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder | - |
| Fuel System | Injection. Electronic fuel injection | Injection. Programmed Fuel Injection |
| Bore x Stroke | 101 x 73 mm | - |
| Compression Ratio | 12.0:1 | 10.5:1 |
| Cooling System | Air/Oil cooled | - |
| Emissions | - | Meets current California Air Resources Board (CARB) and EPA standards. |
| Fuel Consumption | 5.3 L/100 km / 19.0 km/l / 44.7 US mpg | 5.49 litres/100 km (18.2 km/l or 42.85 mpg) |
| Fuel Induction | BMW engine management, BMS-K | - |
| Fuel Reserve | 4 Litres / 1.0 US gal | - |
| Ignition | Digital engine management | Transistorized |
| Starter | Electric | Electric |
| Valve System | - | 4 |
| EV Specifics |
| Battery Capacity | 12 V / 14 Ah, maintenance-free | - |
| Drivetrain |
| Clutch | Single dry plate clutch, hydraulically | Hydraulic, wet, multiplate with coil springs, assist slipper cam. Or 7-speed (DCT) Hydraulic, wet, multiplate with oil pressure. |
| Final Drive | System Enclosed driveshaft with two universal joints | Shaft drive (cardan) (final drive) |
| Final Drive Ratio | 2.62:1 | - |
| Gear Ratios | 1st 2.28 / 2nd 1.58 / 3rd 1.26 / 4th 1.03 / 5th 0.90 / 6th 0.81:1 | - |
| Gearbox | 6-speed | 7-speed |
| Transmission / Drive | 6 Speed | - |
| Chassis |
| Wheel Travel - Rear (mm) | - | 104 mm |
| Wheel Travel - Rear (in.) | - | 4.1 inches |
| Wheel Travel - Front (mm) | - | 109 mm |
| Wheel Travel - Front (in.) | - | 4.3 inches |
| Trail (mm) | - | 109 mm |
| Trail (in.) | - | 4.3 inches |
| Frame Type | Three-section frame consisting of front and rear section, load bearing engine-gearbox unit | Die-cast, aluminium twin-beam |
| Suspension - Front | BMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA | Double Wishbone |
| Suspension - Rear | Die-cast aluminium single-sided swinging arm with BMW Motorrad EVO-Paralever, spring preload hydraulically adjustable to continuously variable levels by means of electronically adjustable ESA, rebound damping with standard ESA | Pro Arm® single-side swingarm with Pro-Link® single shock |
| Rake | - | 30.5° |
| Seat | - | Suede/synthetic leather seats |
| Steering Head Angle | 63.8° | - |
| Trail | 116 mm / 4.5 in | 109 mm / 4.3 in. |
| Wheel Travel - Front | 120 mm / 4.7 in | 109 mm / 4.3 in. |
| Wheel Travel - Rear | 135 mm / 5.3 in | 104 mm / 4.1 in. |
| Electrical Systems |
| Alternator | Three-phase alternator 720 W | - |
| Instrumentation | - | 7-inch TFT display |
| Lighting system | - | Full LED lighting, LED fog lights and auto-cancelling indicators. |
| Wheels & Brakes |
| Brakes - Rear Diameter (in.) | 10.4 inches | - |
| Brakes - Rear Diameter (mm) | 265 mm | - |
| Brakes - Front Diameter (mm) | 320 mm | - |
| Brakes - Front Diameter (in.) | 12.6 inches | - |
| Brakes - Front | 2 x 320mm Discs, 4 piston callipers | Double disc. Floating discs. 6-piston calliper. ABS. |
| Brakes - Rear | Single 265mm disc, 2 piston caliper | Single disc. 3-piston calipers. ABS: |
| Rims - Front | 3.50 x 17 | - |
| Rims - Rear | 5.50 x 17 | - |
| Tyres - Front | 120/70 ZR17 | 130/70-R18 |
| Tyres - Rear | 180/60 ZR17 | - |
| Wheels | Cast aluminium | - |
