| General |
| Comments | 3 Ride Modes (ECO, Rain and Road). Traction Control. Hill Start Control. | - |
| Year | - | 2026 |
| Colours | Black Storm Metallic/Black/Agate Gray, Ice Grey, Light White/Racing Blue Metallic/Racing Red, Gravity Blue Metallic | - |
| Make Model | - | KTM 690 Enduro R |
| Warranty | Up to 3-years or 36,000 miles | - |
| Dimensions |
| Length (mm) | 2207 mm | - |
| Length (in.) | 86.9 inches | - |
| Height (mm) | 1430 mm | - |
| Height (in.) | 56.3 inches | - |
| Seat Height (in.) | 35.0 inches | - |
| Seat Height (mm) | 890 mm | - |
| Seat Heigth -Alternate (in.) | 35.8 inches | - |
| Width (mm) | 953 mm | - |
| Width (in.) | 37.5 inches | - |
| Wheelbase (mm) | 1504 mm | - |
| Seat Heigth -Alternate (mm) | 910 mm | - |
| Wheelbase (in.) | 59.2 inches | - |
| Seat Height | 890 mm / 35.0 in. | 935 mm / 36.8 in |
| Wheelbase | 1504 mm / 59.2 in. | 1506 mm / 59.3 in |
| Ground Clearance | - | 265 mm / 10.4 in |
| Height | 1430 mm / 56.3 in. | - |
| Length | 2207 mm / 86.9 in. | - |
| Width | 953 mm / 37.5 in. | - |
| Weights & Capacities |
| Oil Capacity (Quarts) | 4.23 US quarts | - |
| Oil Capacity (l) | 4.00 litres | - |
| Fuel Capacity (l) | 29.90 litres | - |
| Fuel Capacity (gal.) | 7.90 US gallons | - |
| Wet Weight (kg) | 268.1 kg | 162 |
| Wet Weight (lbs.) | 591.0 pounds | - |
| Fuel Capacity | 29.90 litres / 7.90 US gallons | 13.3 Litres / 3.5 US gal |
| Coolant Capacity | 2.00 litres (0.53 US gallons) | - |
| Wet Weight | 268.1 kg / 591.0 lbs | 162 kg / 357 lbs |
| Performance |
| Top Speed (mph.) | 120.0 mph | - |
| Top Speed (km/h) | 193.1 km/h | - |
| Top Speed | 193.1 km/h / 120.0 mph | - |
| Max Power | - | 79 hp / 58.1 kW |
| Max Torque | 143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 6500 Revolutions" | 73 Nm / 54 lb-ft |
| Engine |
| CO2 | 110.2 CO2 g/km. (CO2 - Carbon dioxide emission) | - |
| Displacement (cc) | 1254.0 cc | - |
| Displacement (ci) | 76.52 cubic inches | - |
| Engine Type | Two cylinder boxer, four-stroke | - |
| Fuel Control | Double Overhead Cams/Twin Cam (DOHC) | - |
| Fuel Reserve (gal.) | 1.06 US gallons | - |
| Fuel Reserve (l) | 4.00 litres | - |
| Bore x Stroke (in,) | 4.0 x 3.0 inches | - |
| Bore x Stroke (mm) | 102.5 x 76.0 mm | - |
| Displacement | - | 692.7 cc / 42.27 cu in |
| Engine Detail | Balance shaft and variable engine timing system | Single cylinder, 4-stroke, SOHC, 4-valve |
| Fuel System | Injection. Electronic intake pipe injection | - |
| Compression Ratio | 12.5:1 | - |
| Cooling System | - | Liquid cooled |
| Emissions | Regulated three-way catalytic converter, compliant with Euro 5 emission standard | - |
| Engine Lubrication | Dry sump | - |
| Exhaust | - | Stainless steel primary and secondary silencer |
| Fuel Consumption | 4.75 litres/100 km (21.1 km/l or 49.52 mpg) | - |
| Fuel Induction | - | Keihin EFI (throttle body 50 mm) |
| Fuel Reserve | 4.00 litres / 1.06 US gallons | - |
| Idle Speed | 1050 +/- 100 RPM | - |
| Ignition | - | Keihin EMS with RBW, double ignition |
| Lubrication System | - | Pressure lubrication with 2 oil pumps |
| Starter | Electric | Electric |
| Valve System | 4 | - |
| Drivetrain |
| Clutch | Wet clutch with an anti-hopping function, hydraulic activation | PASC slipper clutch, hydraulically operated |
| Final Drive | Shaft drive (cardan) (final drive) | Chain, 520 X-ring |
| Gearbox | 6-speed | - |
| Primary Drive | Constant mesh | - |
| Transmission / Drive | - | 6-Speed |
| Chassis |
| Fork Tube Size (mm) | 37 mm | - |
| Fork Tube Size (in.) | 1.5 inches | - |
| Trail (in.) | 3.8 inches | - |
| Trail (mm) | 97 mm | - |
| Wheel Travel - Front (in.) | 8.3 inches | - |
| Wheel Travel - Front (mm) | 210 mm | - |
| Wheel Travel - Rear (in.) | 8.7 inches | - |
| Wheel Travel - Rear (mm) | 220 mm | - |
| Frame Type | Two-section frame, front- and bolted on rear frame, load-bearing engine | Chromium-molybdenum-steel trellis frame, powder coated |
| Suspension - Front | BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut | WP USD XPLOR 48 forks, compression and rebound adjustable |
| Suspension - Rear | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel. | WP XPLOR shock absorber with Pro-Lever linkage, preload adjuster |
| Rake | 24.9° | - |
| Steering Head Angle | - | 62.3° |
| Subframe | - | Self-supporting plastic tank |
| Trail | 97 mm / 3.8 in. | 120 mm / 4.7 in |
| Wheel Travel - Front | 210 mm / 8.3 in. | 265 mm / 10.4 in |
| Wheel Travel - Rear | 220 mm / 8.7 in. | 250 mm / 9.8 in |
| Electrical Systems |
| Instrumentation | TFT color display with connectivity | - |
| Lighting system | LED headlight | - |
| Wheels & Brakes |
| Brakes - Front | Double disc. ABS. Floating discs. Four-piston calipers. | Single 300 mm disc, Brembo 2 piston floating caliper |
| Brakes - Rear | Single disc. ABS. Floating disc. Two-piston calipers. | Single 240 mm disc, Brembo single piston floating caliper |
| ABS | - | Bosch 9.1 MP (incl. Cornering ABS and offroad mode, disengageable) |
| Brake Fluid Type | DOT 4 | - |
| Rims | Cross spoke wheels | - |
| Tyre Pressure - Front | 36 PSI (2.5 Bar or 250 kPa) | - |
| Tyre Pressure - Rear | 42 PSI (2.9 Bar or 290 kPa) | - |
| Tyres - Front | 120/70-R19 | 90/90 -21 |
| Tyres - Rear | - | 140/80 -18 |
| Wheels - Front | - | Spoked wheels with aluminum rims, 1.85 x 21″ |
| Wheels - Rear | - | Spoked wheels with aluminum rims, 2.50 x 18″ |
