| General |
| Year | - | 2024 |
| Colours | Candy Lime Green/Metallic Spark Black, Metallic Carbon Gray/Metallic Spark Black, Candy Plasma Blue/Metallic Spark Black | - |
| Make Model | - | Yamaha MT-09 SP |
| Warranty | 24 Months Unlimited Kilometres | - |
| Dimensions |
| Width (mm) | 790 mm | - |
| Ground Clearance (in.) | 4.9 inches | - |
| Ground Clearance (mm) | 125 mm | - |
| Height (in.) | 41.3 inches | - |
| Height (mm) | 1050 mm | - |
| Length (in.) | 80.3 inches | - |
| Length (mm) | 2040 mm | - |
| Seat Height (in.) | 32.1 inches | - |
| Seat Height (mm) | 815 mm | - |
| Width (in.) | 31.1 inches | - |
| Wheelbase (mm) | 1435 mm | - |
| Wheelbase (in.) | 56.5 inches | - |
| Seat Height | 815 mm / 32.1 in. | 825.5 mm / 32.5 in |
| Wheelbase | 1435 mm / 56.5 in. | 1430 mm / 56.3 in |
| Ground Clearance | - | 140 mm / 5.5 in |
| Height | 1050 mm / 41.3 in. | 1145 mm / 45.1 in |
| Length | 2040 mm / 80.3 in. | 1145 mm / 45.1 in |
| Width | 790 mm / 31.1 in. | 820 mm / 32.3 in |
| Weights & Capacities |
| Fuel Capacity (gal.) | 4.49 US gallons | - |
| Fuel Capacity (l) | 17.00 litres | - |
| Wet Weight (kg) | 221.0 kg | 194 |
| Wet Weight (lbs.) | 487.2 pounds | - |
| Fuel Capacity | 17.00 litres / 4.49 US gallons | 14 Litres / 3.7 US gal |
| Wet Weight | 221.0 kg / 487.2 lbs | 194 kg / 427.7 lbs |
| Performance |
| Max Power | - | 117.4 hp / 119PS / 87.5 kW @ 10000 rpm |
| Max Torque | 111.0 Nm (11.3 kgf-m or 81.9 ft.lbs) @ 7300 Revolutions" | 93 Nm / 68.6lb-ft @ 7000 rpm |
| Engine |
| Fuel Control | Double Overhead Cams/Twin Cam (DOHC) | - |
| Displacement (cc) | 1043.0 cc | - |
| Bore x Stroke (in,) | 3.0 x 2.2 inches | - |
| Bore x Stroke (mm) | 77.0 x 56.0 mm | - |
| Engine Type | In-line four, four-stroke | - |
| Displacement (ci) | 63.64 cubic inches | - |
| Displacement | - | 889 cc / 54.2 cu-in |
| Engine Detail | - | Four stroke, transverse triple cylinder, DOHC, 4 valves per cylinder |
| Fuel System | Injection. DFI 4 X 38 mm with oval sub throttles | - |
| Bore x Stroke | - | 78 x 62.1 mm |
| Compression Ratio | 10.3:1 | 11.5:1 |
| Cooling System | - | Liquid cooled |
| Fuel Induction | - | Fuel injection with YCC-T |
| Ignition | Digital | TCI: Transistor Controlled Ignition |
| Lubrication | - | Wet sump |
| Starter | Electric | Electric |
| Drivetrain |
| Clutch | - | Multiplate assist and slipper clutch |
| Final Drive | - | O-ring chain |
| Transmission / Drive | - | 6 Speed |
| Chassis |
| Wheel Travel - Front (in.) | 1.6 inches | - |
| Wheel Travel - Front (mm) | 41 mm | - |
| Frame Type | Aluminium twin tube | Controlled-fill die-cast aluminum with subframe |
| Suspension - Front | Inverted fork with stepless compression and rebound damping and spring preload adjustability | 41mm KYB inverted fork, adjustable preload, compression and rebound |
| Suspension - Rear | Horizontal Back-link, gas-charged with stepless rebound damping and spring preload adjustability | Linkage-free, fully adjustable horizontal Öhlins shock |
| Rake | - | 24.4° |
| Trail | - | 108 mm / 4.3 in |
| Wheel Travel - Front | 41 mm / 1.6 in. | 130 mm / 5.1 in |
| Wheel Travel - Rear | - | 122 mm / 4.8 in |
| Wheels & Brakes |
| Brakes - Front | Double disc. ABS. Floating discs. Hydraulic. Four-piston calipers. | 2x 298mm hydraulic discs, 4-piston calipers |
| Brakes - Rear | Single disc. ABS. Two-piston calipers. | Single 245mm hydraulic disc, single piston caliper |
| ABS | - | Standard |
| Rims | Petal disc with single-bore pin-slide calipers, ABS | - |
| Tyres - Front | 120/70-17 | 120/70 ZR17 M/C |
| Tyres - Rear | - | 180/55 ZR17 M/C |
