BMW F 800GT Specs

2013 - 2016 • 4 variants

The BMW F 800GT is a sport tourer produced from 2013 to 2016 across 4 variants. It is powered by a four stroke, parallel twin cylinder, dohc, 4 valves per cylinder displacing 798.00 cc. Peak power output is 90 hp. Peak torque is 86 Nm.

About the BMW F 800GT

Documented here are the full technical specifications for the BMW F 800GT, a Sport touring motorcycle with a production run from 2013 to 2018. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.

AdSense - 728Ã90

BMW F 800GT by Year

2016 BMW F 800GT View specs →

2015 BMW F 800GT View specs →

2014 BMW F 800GT View specs →

2013 BMW F 800GT View specs →

Spec Evolution

How key specs changed across production years.

Specification	2013	2014	2015	2016	2017	2018
Fuel Control	DOHC	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)
Comments	-	-	Windscreen.	Windscreen.	Windscreen.	Windscreen. Riding modes rain and road.
CO2	79.1 CO	78.9 CO2 g/km. (CO2 - Carbon dioxide emission) ↓	78.9 CO2 g/km. (CO2 - Carbon dioxide emission)	78.9 CO2 g/km. (CO2 - Carbon dioxide emission)	99.8 CO2 g/km. (CO2 - Carbon dioxide emission) ↑	99.8 CO2 g/km. (CO2 - Carbon dioxide emission)
Dry Weight	166 kg / 366.0 lbs	-	-	-	206 kg / 454.2 lbs	206 kg / 454.2 lbs
Seat Height	820 mm - 765 mm / 32.3 in.- 30.1 in	820 mm - 765 mm / 32.3 in.- 30.1 in	820 mm - 765 mm / 32.3 in.- 30.1 in	820 mm - 765 mm / 32.3 in.- 30.1 in	820 mm - 765 mm / 32.3 in.- 30.1 in	800 mm / 31.5 in. ↓
Wheelbase	1514 mm / 59.6 in.	1514 mm / 59.6 in.	1514 mm / 59.6 in.	1514 mm / 59.6 in.	1514 mm / 59.6 in.	1,514 mm / 59.6 in. ↓
Brakes - Front	2 x 320 mm discs, 4 piston calipers	2 x 320 mm discs, 4 piston calipers	2 x 320 mm discs, 4 piston calipers	2 x 320 mm discs, 4 piston calipers	2 x 320 mm discs, 4 piston calipers	Double disc. ABS. Floating discs. Four-piston calipers.
Fuel Capacity	15 Litres / 4 US gal.	15 Litres / 4 US gal.	15 Litres / 4 US gal.	15 Litres / 4 US gal.	15 Litres / 4 US gal.	15.00 litres / 3.96 gallons
Brakes - Rear	Single 265 mm disc, 1 piston caliper	Single 265 mm disc, 1 piston caliper	Single 265 mm disc, 1 piston caliper	Single 265 mm disc, 1 piston caliper	Single 265 mm disc, 1 piston caliper	Single disc. ABS. Floating disc. Single-piston caliper.
Suspension - Front	43mm Marzocchi Telescopic fork	43mm Marzocchi Telescopic fork	43mm Marzocchi Telescopic fork	43mm Marzocchi Telescopic fork	43mm Marzocchi Telescopic fork	Telescopic fork, 43 mm
Top Speed	201 km/h / 125 mph	201 km/h / 125 mph	201 km/h / 125 mph	201 km/h / 125 mph	201 km/h / 125 mph	200.0 km/h / 124.3 mph ↓
Suspension - Rear	Cast aluminium single-sided swing arm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable	Cast aluminium single-sided swing arm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable	Cast aluminium single-sided swing arm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable	Cast aluminium single-sided swing arm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable	Cast aluminium single-sided swing arm with eccentric adjustment for rear axle, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable	Die-cast aluminium single-sided swing-arm with rear-wheel axle adjustable via tappet, central spring strut, spring pre-load hydraulically and steplessly adjustable via handwheel, adjustable rebound damping
Fuel System	Injection. Electronic intake pipe injection, digital engine management (BMS-K+)	Injection. Electronic intake pipe injection, digital engine management (BMS-K+)	Injection. Electronic intake pipe injection, digital engine management (BMS-K+)	Injection. Electronic intake pipe injection, digital engine management (BMS-K+)	Injection. Electronic intake pipe injection	Injection. Electronic intake pipe injection
Colours	Orange, white, grey	Orange, white, grey	Lue	Montego Blue Metallic, Light White, Monolith Metallic matte/Sapphire Black Metallic	Blue, white, black	Light white, Black Storm Metallic, Gravity Blue Metallic Matt
Clutch	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiplate-plate in oil bath	Multiple-disc clutch in oil bath, mechanically operated
Final Drive	Belt drive	Belt drive	Belt drive	Belt drive	Belt drive	Belt
Height	1248 mm / 49.1 in. (excl. mirrors)	1248 mm / 49.1 in. (excl. mirrors)	1248 mm / 49.1 in. (excl. mirrors)	1248 mm / 49.1 in. (excl. mirrors)	1248 mm / 49.1 in. (excl. mirrors)	1,248 mm / 49.1 in. ↓
Rims	Cast aluminium wheels	Cast aluminium wheels	Cast aluminium	Cast aluminum wheels	Cast aluminium wheels	Cast aluminium
Length	2156 mm / 84.9 in	2156 mm / 84.9 in	2156 mm / 84.9 in	2156 mm / 84.9 in	2156 mm / 84.9 in	2,156 mm / 84.9 in. ↓
Wet Weight	213 kg / 469.6 lbs.	213 kg / 469.6 lbs.	213 kg / 469.6 lbs.	213 kg / 469.6 lbs.	213 kg / 469.6 lbs.	214.0 kg / 471.8 lbs ↑
Emissions	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	Closed-loop 3-way catalytic converter, emission standard EU-3	EU-4 ↓	EU-4
Tyres - Front	120/70 ZR17	120/70 ZR17	120/70 ZR17	120/70 ZR17	120/70 ZR17	120/70-ZR17
Width	905 mm / 35.6 in. (incl. mirrors)	905 mm / 35.6 in. (incl. mirrors)	905 mm / 35.6 in. (incl. mirrors)	905 mm / 35.6 in. (incl. mirrors)	905 mm / 35.6 in. (incl. mirrors)	905 mm / 35.6 in.
Tyres - Rear	180/55 ZR17	180/55 ZR17	180/55 ZR17	180/55 ZR17	180/55 ZR17	180/55-ZR17
Primary Drive	Constant mesh	Belt drive with shock damper	Belt drive with shock damper	Belt drive with shock damper	Belt drive with shock damper	Belt drive with shock damper
Rake	25.8°	25.8°	25.8°	25.8°	25.8°	26.0° ↑
Fuel Consumption	3.4 L/100 km / 29.4 km/l / 69 US mpg	3.4 L/100 km / 29.4 km/l / 69 US mpg	3.4 L/100 km / 29.4 km/l / 69 US mpg	3.4 L/100 km / 29.4 km/l / 69 US mpg	3.4 L/100 km / 29.4 km/l / 69 US mpg	4.30 litres/100 km (23.3 km/l or 54.70 mpg) ↑
Fuel Reserve	5.00 litres / 1.32 gallons	3.00 litres / 0.79 gallons ↓	3.00 litres / 0.79 gallons	3.00 litres / 0.79 gallons	3.00 litres / 0.79 gallons	3.00 litres / 0.79 gallons
Trail	94.6 mm / 3.7 in.	94.6 mm / 3.7 in.	94.6 mm / 3.7 in.	94.6 mm / 3.7 in.	94.6 mm / 3.7 in.	98 mm / 3.9 in. ↑
Wheel Travel - Rear	125 mm / 4.9 in.	125 mm / 4.9 in.	125 mm / 4.9 in.	125 mm / 4.9 in.	125 mm / 4.9 in.	123 mm / 4.8 in. ↓
Max Torque	86 Nm / 8.8 kgf-m / 63 lbs/ft @ 5800 rpm	86 Nm / 8.8 kgf-m / 63 lbs/ft @ 5800 rpm	86 Nm / 8.8 kgf-m / 63 lbs/ft @ 5800 rpm	86 Nm / 8.8 kgf-m / 63 lbs/ft @ 5800 rpm	86 Nm / 8.8 kgf-m / 63 lbs/ft @ 5800 rpm	86.00 Nm (8.8 kgf-m or 63.4 ft.lbs) @ 5800 Revolutions
