Fuel Control
|
DOHC | Double Overhead Cams/Twin Cam (DOHC) |
|
Engine Type
|
Two cylinder boxer, two-stroke | Two cylinder boxer, four-stroke |
|
Comments
|
Blata is from the Czech Republic. | Windscreen. Riding Modes Rain and Road. |
|
CO2
|
106.7 CO | 115.1 CO2 g/km. (CO2 - Carbon dioxide emission) ↑ |
|
Brakes - Rear Diameter (mm)
|
265 mm | 276 mm ↑ |
|
Brakes - Rear Diameter (in.)
|
10.4 inches | 10.9 inches ↑ |
|
Frame Type
|
Tubular steel frame, load-bearing power unit | Two-section frame, front- and bolted on rear frame, load-bearing engine |
|
Seat Height
|
850 mm - 870 mm / 33.4 in - 34.2 in | 850 mm / 33.5 in. |
|
Engine Detail
|
Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder | Balancer shaft |
|
Wheelbase
|
1507 mm / 59.3 in | 1,507 mm / 59.3 in. ↓ |
|
Brakes - Front
|
2 x 305mm discs, 4 piston caliper | Double disc. ABS. Floating discs. Four-piston calipers. |
|
Fuel Capacity
|
20 Litres / 5.2 US gal | 20.00 litres / 5.28 gallons |
|
Brakes - Rear
|
Single 265mm disc 2 piston caliper | Single disc. ABS. Floating disc. Two-piston calipers. |
|
Suspension - Front
|
Telelever, stanchion diameter 41mm, central spring strut, spring preload 9 times mechanically adjustable | BMW Motorrad Telelever |
|
Suspension - Rear
|
Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever, WAD strut (travel-related damping), spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable. | Cast aluminium single-sided swing arm with BMW Motorrad Paralever |
|
Top Speed
|
206.8 km/h / 129 mph. | 200.0 km/h / 124.3 mph ↓ |
|
Fuel System
|
Injection. Electronic intake pipe injection/BMS-K digital engine management with overrun fuel cut-off, twin spark ignition | Injection. Electronic intake pipe injection |
|
Colours
|
Silver/red/blue | Lupin Blue Metallic/Cordoba Blue/Gold |
|
Clutch
|
Single-plate dry clutch, 180mm | Oil lubricated clutch, hydraulically operated |
|
Final Drive
|
Shaft | Shaft drive (cardan) |
|
Rims
|
Cross-spoke wheels | Cross Spoke Wheels |
|
Height
|
1450 mm / 57.1 in | 1,450 mm / 57.1 in. ↓ |
|
Length
|
2210 mm / 87.0 in | 2,207 mm / 86.9 in. ↓ |
|
Compression Ratio
|
12.0:1 | 12.5:1 ↑ |
|
Wet Weight
|
238 kg / 525 lbs | 244.0 kg / 537.9 lbs ↑ |
|
Emissions
|
Closed-loop 3-way catalytic converter | Closed-loop 3-way catalytic converter, emission standard EU-4 |
|
Tyres - Front
|
110/80 ZR19 | 120/70-R19 ↑ |
|
Width
|
953 mm / 37.5 in | 953 mm / 37.5 in. |
|
Tyres - Rear
|
150/70 ZR17 | 170/60-R17 ↑ |
|
Rake
|
24.8° | 25.5° ↑ |
|
Seat
|
Two section dual seat with variable height riders seat | Single Rallye Seat |
|
Fuel Consumption
|
4.60 litres/100 km (21.7 km/l or 51.13 mpg) | 4.96 litres/100 km (20.2 km/l or 47.42 mpg) ↑ |
|
Fuel Reserve
|
4 Litres / 1.1 US gal | 4.00 litres / 1.06 gallons |
|
Trail
|
89 mm / 3.5 in. | 100 mm / 3.9 in. ↑ |
|
Wheel Travel - Front
|
190 mm / 7.5 in | 190 mm / 7.5 in. |
|
Wheel Travel - Rear
|
200 mm / 7.9 in | 200 mm / 7.9 in. |
|
Max Torque
|
120 Nm / 88 lb-ft @ 6000 rpm | 125.00 Nm (12.7 kgf-m or 92.2 ft.lbs) @ 6500 Revolutions ↑ |
