Comments
|
Windscreen. | Adjustable Windshield. 2 Ride Modes (Rain/Road). Automatic Stability Control. | Adjustable Windshield. 2 Ride Modes (Rain/Road). Automatic Stability Control. | Adjustable Windshield. 2 Ride Modes (Rain/Road). Automatic Stability Control. | Adjustable Windshield. 3 Ride Modes (Rain/Road/Eco). Automatic Stability Control. Hill Start Control. ↑ |
|
Engine Detail
|
Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder | Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder | Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, Intake 40mm, outlet 34 mm | Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, Intake 40mm, outlet 34 mm | Four stroke, two cylinder horizontally opposed Boxer, with two overhead, spur gear driven camshafts , a counterbalance shaft and variable intake camshaft control system BMW ShiftCam, 4 valves per cylinder, Intake 40mm, outlet 34 mm |
|
Fuel Capacity
|
18 Litres / 4.7 US gal | 18 Litres / 4.7 US gal | 18 Litres / 4.7 US gal | 18 Litres / 4.7 US gal | 18 Litres / 4.8 US gal |
|
Suspension - Rear
|
Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel- related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel- related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel- related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel- related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel- related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable at handwheel - Optional Dynamic ESA Next Generation |
|
Fuel System
|
Injection. Electronic intake pipe injection | Injection. Electronic fuel injection with ride-by-wire throttle system | Injection. Electronic fuel injection with ride-by-wire throttle system | Injection. Electronic fuel injection with ride-by-wire throttle system | Injection. Electronic fuel injection with ride-by-wire throttle system |
|
Colours
|
Black Storm Metallic, Style Sport, Style Exclusive, Option 719 Dtardust Metallic | Black Storm Metallic, Style Sport, Style Exclusive, Sparkling Bronze Metallic | Black Storm Metallic, Style Sport Yellow, Style Exclusive Blue | Black Storm Metallic, Light White, Style Imperial Blue Metallic | Black Storm Metallic/Agate Grey, Light White, Light White/Racing Blue Metallic/Racing Red |
|
Battery Capacity
|
12V/12Ah | 12V/12Ah | 12 V / 11.8 Ah, maintenance-free | 12 V / 11.8 Ah, maintenance-free | - |
|
Rims
|
Aluminium-Gussräder | - | Cast aluminum | - | - |
|
Emissions
|
Closed-loop three-way catalytic converter, exhaust standard , Euro 4 | Closed-loop three-way catalytic converter, exhaust standard , Euro 4 | Closed-loop three-way catalytic converter, compliant with Euro 5 emission standard ↑ | Closed-loop three-way catalytic converter, compliant with Euro 5 emission standard | Closed-loop three-way catalytic converter, compliant with Euro 5 emission standard |
|
Engine Management
|
BMS-O | BMS-O | Digital engine control: BMS-O with e-gas | Digital engine control: BMS-O with e-gas | BMS-O, electronic fuel injection with ride-by-wire throttle |
|
Rake
|
25.5° | 25.5° | 26.7° ↑ | 26.7° | 27.7° ↑ |
|
Lighting system
|
- | LED | LED | LED headlight | LED headlight |
|
Fuel Induction
|
Electronic intake pipe injection, 52mm Ø throttle valve | Electronic intake pipe injection, 52mm Ø throttle valve | Electronic intake pipe fuel injection, 52mm throttle valve | Electronic intake pipe fuel injection, 52mm throttle valve | Electronic intake pipe fuel injection, 52mm throttle valve |
|
Fuel Type
|
Unleaded super, octane number 95 (RON) adapive fuel quality regulation (91 to 98 RON) | Unleaded super, octane number 95 (RON) adapive fuel quality regulation (91 to 98 RON) | Super petrol unleaded, octane number 95 (ROZ), adaptation through engine control (91 to 98 ROZ) | Super petrol unleaded, octane number 95 (ROZ), adaptation through engine control (91 to 98 ROZ) | Super petrol unleaded, octane number 95 (ROZ), adaptation through engine control (91 to 98 ROZ) |
|
Trail
|
110.9 mm / 4.3 in | 110.9 mm / 4.3 in | 110.9 mm / 4.3 in | 110.9 mm / 4.3 in | 110.9 mm / 4.3 in |
|
Max Torque
|
143 Nm / 105.4 lb-ft @ 6250 rpm | 143 Nm / 105.4 lb-ft @ 6250 rpm | 143 Nm / 105.4 lb-ft @ 6250 rpm | 143 Nm / 105.4 lb-ft @ 6250 rpm | 143 Nm / 105.4 lb-ft @ 6250 rpm |
|
Starter
|
Electric 900W | Electric 900W | Electric | Electric | Electric |
