Ducati Diavel Carbon Specs

2013 - 2018 • 5 variants

The Ducati Diavel Carbon is a cruiser produced from 2013 to 2018 across 5 variants. It is powered by a four stroke, 90° °l° twin cylinder, dohc, desmodromic 4 valves per cylinder.. Peak power output is 162 hp. Peak torque is 127.5 Nm.

About the Ducati Diavel Carbon

The Ducati Diavel Carbon is a Custom / cruiser motorcycle from Ducati, produced from 2013 to 2018. This page provides a comprehensive technical reference for the Ducati Diavel Carbon, covering all available specification data including engine configuration, displacement, power output, dimensions, weight, and chassis details. Use the year selector above to find specifications for a specific model year. All data is sourced from manufacturer specifications and is intended as a technical reference for riders, mechanics, and enthusiasts.

AdSense - 728Ã90

Ducati Diavel Carbon by Year

2018 Ducati Diavel Carbon View specs →

2016 Ducati Diavel Carbon View specs →

2015 Ducati Diavel Carbon View specs →

2014 Ducati Diavel Carbon View specs →

2013 Ducati Diavel Carbon View specs →

Spec Evolution

How key specs changed across production years.

Specification	2013	2014	2015	2016	2018
Dry Weight	210 Kg / 463 lbs	205 Kg / 452 lbs ↓	210 Kg / 463 lbs ↑	210 Kg / 463 lbs	210 Kg / 463 lbs
Displacement	-	-	1198.4	1198.4	1198.4 cc / 73.1 cu-in
Seat Height	770 mm / 30.3in	770 mm / 30.3in	770 mm / 30.3in	770 mm / 30.3in	770 mm / 30.3in
Engine Detail	Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder.	Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder.	Four stroke, 90°°L°twin cylinder, DOHC, desmodromic 4 valve per cylinder.	Four stroke, 90°°L°twin cylinder, DOHC, desmodromic 4 valve per cylinder.	Four stroke, 90Â°â€œLâ€twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Brakes - Front	2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS	2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS	2 x 320mm semi-floating discs, radially mounted Monobloc Brembo callipers, 4-piston with ABS	2 x 320mm semi-floating discs, radially mounted Monobloc Brembo callipers, 4-piston with ABS	2 x 320mm semi-floating discs, radially mounted Monobloc Brembo callipers, 4-piston with ABS
Brakes - Rear	Single 265 mm disc, 2-piston floating caliper with ABS	Single 265 mm disc, 2-piston floating caliper with ABS	Single 265mm disc, 2-piston floating calliper with ABS	Single 265mm disc, 2-piston floating calliper with ABS	Single 265mm disc, 2-piston floating calliper with ABS
Fuel Capacity	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 5.3 gal	17 Litres / 5.3 gal	-
Suspension - Front	Marzocchi 50mm fully adjustable USD forks	Marzocchi 50mm fully adjustable USD forks	Marzocchi 50mm fully adjustable USD forks,	Marzocchi 50mm fully adjustable USD forks,	Marzocchi 50mm fully adjustable USD forks,
Bore x Stroke	106 x 67.9 mm	106 x 67.9 mm	106 x 67.9mm	106 x 67.9mm	106 x 67.9mm
Wet Weight	234 kg / 516 lbs	-	239 kg / 527lbs ABS	239 kg / 527lbs ABS	239 kg / 527lbs ABS
Cooling System	Liquid cooled	Liquid cooled	Liquid cooled,	Liquid cooled,	Liquid cooled,
Gear Ratios	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25	1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25
Rake	28°	28°	28°	28°	28Â°
Steering Angle	70°	70°	70°	70°	70Â°
Max Power	119 kW / 162 hp / @ 9500rpm	119 kW / 162 hp / @ 9500rpm	162 hp / 119 kW @ 9500rpm ↑	162 hp / 119 kW @ 9500rpm	152 hp / 113.3 kW @ 9500rpm ↓
Max Torque	127.5 Nm / 13.0 kgf-m / 94 lb-ft / @ 8000rpm	127.5 Nm / 13.0 kgf-m / 94 lb-ft / @ 8000rpm	94 lb-ft / 127.5 Nm @ 8000rpm ↓	94 lb-ft / 127.5 Nm @ 8000rpm	94 lb-ft / 127.5 Nm @ 8000rpm
