Key Specifications
Torque
107.70 Nm (11.0 kgf-m or 79.4 ft.lbs) @ 3000
Top Speed
45.0 km/h / 28.0 mph
Weight
354.7 kg / 782.0 lbs
Fuel Capacity
18.93 litres / 5.00 gallons
Advertisement
Full 2014 Harley-Davidson CVO Softail Deluxe Specifications
Comments
Lithium Iron Phosphate 48V/20Ah battery, 16.8 kg. Range 60 km. Recharging time: 4 hours. Made in Taiwan.
Colours
Crimson Red Sunglo and Ruby Red with Airflow Graphics, Candy Cobalt and White Gold Pearl with Airflow Graphics, Maple Metallic and Atomic Orange with Airflow Graphics
Storage
Saddle bags
Ground Clearance (mm)
122 mm
Ground Clearance (in.)
4.8 inches
Seat Height
622 mm / 24.5 in.
Wheelbase
1,638 mm / 64.5 in.
Height
1,005 mm / 39.6 in.
Length
2,405 mm / 94.7 in.
Width
625 mm / 24.6 in.
Oil Capacity (Quarts)
0.22 quarts
Oil Capacity (l)
3.30 litres
Dry Weight
56.2 kg / 123.9 lbs
Fuel Capacity
18.93 litres / 5.00 gallons
Wet Weight
354.7 kg / 782.0 lbs
Engine Type
V2, four-stroke
Displacement (ci)
103.00 cubic inches
Displacement (cc)
1687.97 cc
CO2
129.9 CO
Bore x Stroke (mm)
98.4 x 111.1 mm
Bore x Stroke (in,)
3.9 x 4.4 inches
Engine Detail
Air-cooled, Twin Cam 103B?
Fuel System
Injection. Electronic Sequential Port Fuel Injection
Compression Ratio
9.7:1
Emissions
Zero emission
Exhaust
Chrome, shorty-dual exhaust w/slashdown chrome mufflers and chrome heat shields
Fuel Consumption
5.60 litres/100 km (17.9 km/l or 42.00 mpg)
Starter
Electric
Clutch
Multi-plate with diaphragm spring in oil bath
Final Drive
Belt
Gearbox
6-speed
Primary Drive
Primary chain, 34/46 ratio
Frame Type
Steel tube
Suspension - Front
Dual Hydraulic Shock Absorber
Suspension - Rear
Single Hydraulic Shock Absorber
Rake
32.1°
Trail
147 mm / 5.8 in.
Instrumentation
Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicat
Lighting system
High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings
Brakes - Front
Single disc. ABS, 4-piston
Brakes - Rear
Single disc. ABS, 2-piston
Rims
Chrome 9-spoke cast aluminium
Tyres - Front
MT90-B16
Tyres - Front
80/100-10
Tyres - Rear
80/100-10
Tyres - Rear
MU85-B16
