Oil Capacity (Quarts)
|
0.12 quarts | 0.12 quarts | 0.12 quarts | 0.12 quarts | 0.12 quarts | 1.9 US quarts ↑ | 1.9 US quarts |
|
Ground Clearance (mm)
|
255 mm | 254 mm ↓ | 254 mm | 254 mm | 254 mm | 254 mm | 254 mm |
|
Fuel Control
|
DOHC | DOHC | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) | Double Overhead Cams/Twin Cam (DOHC) |
|
Displacement (ci)
|
15.26 cubic inches | - | - | - | - | 15.23 cubic inches | 15.23 cubic inches |
|
Displacement (cc)
|
250.00 cc | - | - | - | - | 249.6 cc | 249.6 cc |
|
Comments
|
Model ID: CRF150RB | Model ID: CRF250L ↑ | Model ID: CRF250L | Model ID: CRF250L | Model ID: CRF250L | Model ID: CRF250L | Model ID: CRF250L. |
|
CO2
|
72.4 CO | 74.7 CO ↑ | 74.7 CO2 g/km. (CO2 - Carbon dioxide emission) | 74.7 CO2 g/km. (CO2 - Carbon dioxide emission) | 74.7 CO2 g/km. (CO2 - Carbon dioxide emission) | 74.7 CO2 g/km. (CO2 - Carbon dioxide emission) | 74.7 CO2 g/km. (CO2 - Carbon dioxide emission) |
|
Seat Height
|
875 mm / 34.4 in. | 875 mm / 34.7 in | 875 mm / 34.7 in | 881 mm / 34.7 in. ↑ | 881 mm / 34.7 in. | 874 mm / 34.4 in. ↓ | 874 mm / 34.4 in. |
|
Frame Type
|
Semi-double cradle | Semi-double cradle | Semi-double cradle | - | - | - | - |
|
Brakes - Front
|
Single 256mm disc 2 piston caliper | Double disc. Two-piston calipers. | Single 256mm disc 2 piston caliper | Double disc. Two-piston calipers. | Single disc. Two-piston calipers. | Single disc. Two-piston calipers. | Single disc. Two-piston calipers. |
|
Wheelbase
|
1445 mm / 56.9 in | 1,445 mm / 56.9 in. ↓ | 1445 mm / 56.9 in ↑ | 1,445 mm / 56.9 in. ↓ | 1,445 mm / 56.9 in. | 1445 mm / 56.9 in. ↑ | 1445 mm / 56.9 in. |
|
Brakes - Rear
|
Single 220mm disc 1 piston caliper | Single 220mm disc 1 piston caliper | Single 220mm disc 1 piston caliper | Single disc | Single disc | Single disc | Single disc |
|
Fuel Capacity
|
7.7 Litres / 2.0 US gal | 7.7 Litres / 2.0 gal | 7.7 Litres / 2.0 gal | 7.57 litres / 2.00 gallons ↓ | 7.57 litres / 2.00 gallons | 7.95 litres / 2.10 US gallons ↑ | 7.95 litres / 2.10 US gallons |
|
Suspension - Front
|
43mm inverted fork; | 43mm inverted fork | 43mm inverted fork; | 43mm inverted fork | 43mm inverted fork | 43mm inverted fork | 43mm inverted fork |
|
Suspension - Rear
|
Pro-Link® single shock with spring | Pro-Link® single shock with spring; 9.4 inches travel | Pro-Link® single shock with spring | Pro-Link® single shock with spring; 9.4 inches travel | Pro-Link® single shock with spring; 9.4 inches travel | Pro-Link® single shock with spring; 9.4 inches travel ↓ | Pro-Link® single shock with spring; |
|
Fuel System
|
Injection. Programmed fuel injection system (PGM-FI) | Injection. PGM-FI, 36mm throttle body | Injection. PGM-FI, 36mm throttle body | Injection. PGM-FI, 36mm throttle body | Injection. PGM-FI, 36mm throttle body | Injection. PGM-FI, 36mm throttle body | Injection. PGM-FI, 38mm throttle body ↑ |
|
Colours
|
Red/white | Red | Red/white | Red | Red | Red | Red |
|
Final Drive
|
Chain | #520 chain; 14T/40T | #520 chain; 14T/40T | Chain | Chain | Chain (final drive) | Chain (final drive) |
|
Height
|
1,195 mm / 47.0 in. | 1,195 mm / 47.0 in. | 1195 mm / 47.0 in ↑ | 1,195 mm / 47.0 in. ↓ | 1,195 mm / 47.0 in. | 1195 mm / 47.0 in. ↑ | 1195 mm / 47.0 in. |
|
Length
|
2,195 mm / 86.4 in. | 2,195 mm / 86.4 in. | 2195 mm / 86.4 in ↑ | 2,195 mm / 86.4 in. ↓ | 2,195 mm / 86.4 in. | 2195 mm / 86.4 in. ↑ | 2195 mm / 86.4 in. |
|
Wet Weight
|
147 kg / 320 lbs | 145.2 kg / 320.0 lbs ↓ | 147 kg / 320 lbs ↑ | 145.2 kg / 320.0 lbs ↓ | 145.2 kg / 320.0 lbs | 144.0 kg / 317.5 lbs ↓ | 146.0 kg / 321.9 lbs ↑ |
|
Emissions
|
Consult owners manual for optional racing parts. | Meets current California Air Resources Board (CARB) and EPA off-road emissions standards. | - | - | - | - | - |
|
Width
|
815 mm / 32.0 in | 815 mm / 32.0 in | 815 mm / 32.0 in | 815 mm / 32.1 in. | 815 mm / 32.1 in. | 815 mm / 32.1 in. | 815 mm / 32.1 in. |
|
Tyres - Rear
|
120/80-P18 | 120/80-18 | 120/80-18 | 120/80-18 | 120/80-18 | - | - |
|
Primary Drive
|
Constant mesh | #520 chain; 14T/40T | #520 chain; 14T/40T | #520 chain; 14T/40T | #520 chain; 14T/40T | #520 chain; 14T/40T | #520 chain; 14T/40T |
|
Rake
|
27.0° | 27.4° ↑ | 27° ↓ | 27.4° ↑ | 27.4° | 27.6° ↑ | 27.6° |
|
Fuel Consumption
|
3.12 litres/100 km (32.1 km/l or 75.39 mpg) | 3.22 litres/100 km (31.1 km/l or 73.05 mpg) ↑ | 3.22 litres/100 km (31.1 km/l or 73.05 mpg) | 3.22 litres/100 km (31.1 km/l or 73.05 mpg) | 3.22 litres/100 km (31.1 km/l or 73.05 mpg) | 3.22 litres/100 km (31.1 km/l or 73.05 mpg) | 3.22 litres/100 km (31.1 km/l or 73.05 mpg) |
|
Trail
|
113 mm / 4.4 in. | 112 mm / 4.4 in ↓ | 112 mm / 4.4 in | 113 mm / 4.4 in. ↑ | 113 mm / 4.4 in. | 113 mm / 4.4 in. | 113 mm / 4.4 in. |
|
Wheel Travel - Front
|
61 mm / 2.4 in. | 61 mm / 2.4 in. | 221 mm / 8.7 in ↑ | 61 mm / 2.4 in. ↓ | 249 mm / 9.8 in. ↑ | 249 mm / 9.8 in. | 249 mm / 9.8 in. |
|
Wheel Travel - Rear
|
239 mm / 9.4 in | 61 mm / 2.4 in. ↓ | 239 mm / 9.4 in ↑ | 61 mm / 2.4 in. ↓ | 239 mm / 9.4 in. ↑ | 239 mm / 9.4 in. | 239 mm / 9.4 in. |
|
Ignition
|
Full-transistor battery ignition | Full-transistor battery ignition | Full-transistor battery ignition | Computer-controlled digital transistorized with electronic advance | Computer-controlled digital transistorized with electronic advance | Computer-controlled digital transistorized with electronic advance | Computer-controlled digital transistorized with electronic advance |
|
Max Torque
|
22.00 Nm (2.2 kgf-m or 16.2 ft.lbs) @ 7000 | 22 Nm / 2.24 kg-m @ 7000 rpm | 22 Nm / 2.24 kg-m @ 7000 rpm | 22.00 Nm (2.2 kgf-m or 16.2 ft.lbs) @ 7000 Revolutions | 22.00 Nm (2.2 kgf-m or 16.2 ft.lbs) @ 7000 Revolutions | 22.0 Nm (2.2 kgf-m or 16.2 ft.lbs) @ 7000 Revolutions" | 22.0 Nm (2.2 kgf-m or 16.2 ft.lbs) @ 7000 Revolutions" |
