Honda CRF 250X Specs

2006 - 2009 • 4 variants

The Honda CRF 250X is an enduro motorcycle produced from 2006 to 2009 across 4 variants. It is powered by a four stroke single cylinder, 4 valves displacing 249.0 cc. Peak power output is 28.5 hp. Peak torque is 24.2 Nm.

About the Honda CRF 250X

Honda introduced the CRF 250X as part of their Enduro / Off-Road range, with production running from 2004 to 2019. This technical reference page documents the full specification sheet for the Honda CRF 250X, including engine displacement, power and torque figures, frame and suspension geometry, braking systems, and overall dimensions. Select a model year above to view year-specific technical data. Specifications are compiled from official manufacturer sources.

AdSense - 728Ã90

Honda CRF 250X by Year

2009 Honda CRF 250X View specs →

2008 Honda CRF 250X View specs →

2007 Honda CRF 250X View specs →

2006 Honda CRF 250X View specs →

Spec Evolution

How key specs changed across production years.

Specification	2004	2005	2006	2007	2008	2009	2010	2012	2014	2016	2017	2018	2019
Ground Clearance (mm)	-	361 mm	345 mm ↓	345 mm	340 mm ↓	340 mm	345 mm ↑	345 mm	345 mm	345 mm	345 mm	345 mm	345 mm
Ground Clearance (in.)	-	14.2 inches	13.6 inches ↓	13.6 inches	13.4 inches ↓	13.4 inches	13.6 inches ↑	13.6 inches	13.6 inches	13.6 inches	13.6 inches	13.6 inches	13.6 inches
Fuel Control	-	-	-	SOHC	SOHC	SOHC	SOHC	SOHC	SOHC	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)
Engine Type	Single cylinder	Single cylinder	Single cylinder	Single cylinder	Single cylinder	Single cylinder	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke	Single cylinder, four-stroke
Displacement (cc)	249.00 cc	249.00 cc	249.00 cc	249.00 cc	249.00 cc	249.00 cc	249.00 cc	249.00 cc	249.00 cc	-	-	-	249.0 cc
Comments	-	-	-	-	-	-	-	French brand.	Model ID: CRF250X	Model ID: CRF250X.	Model ID: CRF250X.	Model ID: CRF250X.	Model ID: CRF250X.
Seat Height	963 mm / 37.9 in.	963 mm / 37.9 in.	958 mm / 37.7 in. ↓	958 mm / 37.7 in.	958 mm / 37.7 in.	958 mm / 37.7 in.	958 mm / 37.7 in.	958 mm / 37.7 in.	958 mm / 37.7 in.	958 mm / 37.7 in	958 mm / 37.7 in.	958 mm / 37.7 in.	958 mm / 37.7 in.
Frame Type	-	-	-	-	-	-	-	Aluminium	Semi-double cradle; steel tube	Semi-double cradle, aluminium twin-spar	Semi-double cradle, aluminium twin-spar	Semi-double cradle, aluminium twin-spar	Semi-double cradle, aluminium twin-spar
Dry Weight	-	103.4 kg / 228.0 lbs	102.1 kg / 225.0 lbs ↓	102.1 kg / 225.0 lbs	114.8 kg / 253.0 lbs ↑	-	-	88 kg / 194.0 lbs	102 kg / 224.8 lbs ↑	102 kg / 224.8 lbs	-	-	-
Wheelbase	1,488 mm / 58.6 in.	1,488 mm / 58.6 in.	1,481 mm / 58.3 in.	1,481 mm / 58.3 in.	1,481 mm / 58.3 in.	1,481 mm / 58.3 in.	1,481 mm / 58.3 in.	1,481 mm / 58.3 in.	1480 mm / 58.3 in. ↑	1,481 mm / 58.3 in. ↓	1,481 mm / 58.3 in.	1,481 mm / 58.3 in.	1481 mm / 58.3 in. ↑
Brakes - Front	Single disc	Single disc	Single disc	Single disc	Single disc	Double disc	Double disc	Single disc	Single 240mm disc 2 piston caliper	Single disc. Two-piston calipers.	Single disc. Two-piston calipers.	Single disc. Two-piston calipers.	Single disc. Two-piston calipers.
Engine Detail	-	-	-	-	-	-	-	Unicam®, four-valve; 31mm intake valve, 26mm exhaust valve	Four stroke single cylinder, 4 valves ↓	Four stroke single cylinder, 4 valves	Gear-driven counterbalancer	31mm intake valve, 26mm exhaust valve	31mm intake valve, 26mm exhaust valve
Brakes - Rear	Single disc	Single disc	Single disc	Single disc	Single disc	Single disc	Single disc	Single 240mm disc 2 piston caliper	Single disc	Single 240mm disc 2 piston caliper	Single disc	Single disc	Single disc
Fuel Capacity	8.32 litres / 2.20 gallons	8.32 litres / 2.20 gallons	8.32 litres / 2.20 gallons	8.32 litres / 2.20 gallons	7.19 litres / 1.90 gallons ↓	7.19 litres / 1.90 gallons	7.19 litres / 1.90 gallons	8.6 Litres / 2.27 gal ↑	7.19 litres / 1.90 gallons ↓	7.19 litres / 1.90 gallons	7.19 litres / 1.90 gallons	7.19 litres / 1.90 gallons	7.19 litres / 1.90 US gallons
Suspension - Front	47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability.	47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47.0mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability	47mm inverted Showa® cartridge fork with 16-position rebound- and 16-position compression-damping adjustability; 12.4-inches travel	47mm inverted Showa® cartridge fork with 16-position rebound- and 16-position compression-damping adjustability; 12.4-inches travel	47mm inverted Showa® cartridge fork with 16-position rebound- and 16-position compression-damping adjustability; 12.4-inches travel	47mm inverted Showa® cartridge fork with 16-position rebound- and 16-position compression-damping adjustability; 12.4-inches travel
Suspension - Rear	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns.	Pro-Link Showa single shock with spring-preload, 17-position rebound-damping adjustability, and compression-damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)	Pro-Link Showa single shock with spring-preload, 17-position rebound-damping adjustability, and compression-damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)	Pro-Link Showa single shock with spring-preload, 17-position rebound-damping adjustability, and compression-damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)	Pro-Link Showa single-shock with spring preload, 13-position [low-speed] and 3.5-turn [high-speed] compression damping and 17-position rebound damping adjustability ↓	Pro-Link Showa single-shock with spring preload, 13-position [low-speed] and 3.5-turn [high-speed] compression damping and 17-position rebound damping adjustability	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and highspeed (3.5 turns) ↑	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns)	Pro-Link® Showa® single shock with spring-preload, 17-position rebound-damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns); 12.3 inches travel ↑	Pro-Link® Showa® single shock with spring-preload, 17-position rebound-damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns); 12.3 inches travel	Pro-Link® Showa® single shock with spring-preload, 17-position rebound-damping adjustability, and compression damping adjustment separated into low-speed (13 positions) and high-speed (3.5 turns); 12.3 inches travel ↓
Fuel System	Carburettor	Carburettor. Keihin 37.0mm flat-slide with throttle position sensor (TPS)	Carburettor. Keihin 37.0 mm flat-slide with throttle position sensor (TPS)	Carburettor. Keihin 37.0mm flat-slide with throttle position sensor (TPS)	Carburettor. 37mm Keihin flat-slide	Carburettor. 37mm Keihin flat-slide	Carburettor. Keihin 37mm flat-slide carburetor with Throttle Position Sensor (TPS)	Carburettor. Keihin 37mm flat-slide carburetor with Throttle Position Sensor (TPS)	Carburettor	Carburettor	Carburettor	Carburettor. Keihin® 37mm flat-slide carburetor with Throttle Position Sensor (TPS)	Carburettor. Keihin® 37mm flat-slide carburetor with Throttle Position Sensor (TPS) ↓
Final Drive	Chain	Chain	Chain	Chain	Chain	Chain	Chain	Chain	Chain	#520 T-ring-sealed chain; 14T/53T	Chain	Chain	Chain (final drive)
Height	-	-	-	-	-	-	-	1,150 mm / 45.3 in.	1261 mm / 49.6 in ↑	1261 mm / 49.6 in	1,261 mm / 49.6 in. ↓	1,261 mm / 49.6 in.	1261 mm / 49.6 in. ↑
Length	-	-	-	-	-	-	-	1,810 mm / 71.3 in.	2174 mm / 85.5 in ↑	2174 mm / 85.5 in	2,174 mm / 85.6 in. ↓	2,174 mm / 85.6 in.	2174 mm / 85.6 in. ↑
Compression Ratio	12.5:1	12.5:1	12.5:1	12.5:1	12.9:1 ↑	12.9:1	12.9:1	12.9:1	12.9:1	12.9:1	12.9:1	12.9:1	12.9:1
Wet Weight	-	-	-	-	-	114.8 kg / 253.0 lbs	114.8 kg / 253.0 lbs	114.8 kg / 253.0 lbs	115 kg / 253 lbs ↑	115 kg / 253 lbs	115.2 kg / 254.0 lbs ↑	115.2 kg / 254.0 lbs	115.2 kg / 254.0 lbs
Tyres - Front	80/90-21	80/70-21	80/70-21	80/100-21	80/0-21	80/21-21	80/100-21	80/100-21	80/100-21	80/100-21	80/100-21	80/100-21	80/100-21
Width	-	-	-	-	-	-	-	827 mm / 32.5 in	827 mm / 32.5 in	827 mm / 32.6 in.	827 mm / 32.6 in.	827 mm / 32.6 in.	827 mm / 32.6 in.
Tyres - Rear	100/90-18	100/90-18	100/90-18	100/90-18	100/90-18	100/18-18	100/100-18	100/100-18	110/100-18 ↑	110/100-18	100/100-18 ↓	100/100-18	-
Primary Drive	-	-	-	-	-	-	-	#520 T-ring-sealed chain; 13T/49T	#520 T-ring-sealed chain; 14T/53T	#520 T-ring-sealed chain; 14T/53T	#520 T-ring-sealed chain; 14T/53T	#520 T-ring-sealed chain; 14T/53T	#520 T-ring-sealed chain; 14T/53T
Rake	25.3°	27.5° ↑	27.9° ↑	27.9°	27.5° ↓	27.5°	27.5°	27° ↓	27.5° ↑	27.5°	27.5°	27.5°	27.5°
Trail	94 mm / 3.7 in.	120 mm / 4.7 in. ↑	118 mm / 4.6 in. ↓	118 mm / 4.6 in.	118 mm / 4.6 in.	118 mm / 4.6 in.	118 mm / 4.6 in.	118 mm / 4.6 in	118 mm / 4.6 in	118 mm / 4.6 in	118 mm / 4.6 in.	118 mm / 4.6 in.	118 mm / 4.6 in.
Wheel Travel - Front	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in	315 mm / 12.4 in	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.
Wheel Travel - Rear	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	315 mm / 12.4 in.	312 mm / 12.3 in. ↓	312 mm / 12.3 in.	312 mm / 12.3 in.	312 mm / 12.3 in.	312 mm / 12.3 in.
Ignition	-	CD with electronic advance and lighting coil	CD with electronic advance and lighting coil	CD with electronic advance and lighting coil	CD	CD	CD with electronic advance and lighting coil	CD with electronic advance and lighting coil	CD with electronic advance and lighting coil	CD with electronic advance and lighting coil	-	CD with electronic advance and lighting coil	CD with electronic advance and lighting coil
Max Torque	-	-	-	-	-	-	-	24.2 Nm / 2.47 kg-m @ 8000 rpm	24.2 Nm / 2.47 kg-m @ 8000 rpm	24.20 Nm (2.5 kgf-m or 17.8 ft.lbs) @ 8000 Revolutions	24.20 Nm (2.5 kgf-m or 17.8 ft.lbs) @ 8000 Revolutions	24.20 Nm (2.5 kgf-m or 17.8 ft.lbs) @ 8000 Revolutions	24.2 Nm (2.5 kgf-m or 17.8 ft.lbs) @ 8000 Revolutions"
Starter	-	Kick	Electric & kick	Electric & kick	-	-	Electric & kick	Electric & kick	Electric & kick	Electric & kick	Electric & kick	Electric & kick	Electric & kick
