Honda CRF110F Specs

2014 - 2023 • 5 variants

The Honda CRF110F is an enduro motorcycle produced from 2014 to 2023 across 5 variants. Engine displacement is 109.0 cc. Peak torque is 8.9 Nm.

About the Honda CRF110F

As a Enduro / Off-Road motorcycle, the Honda CRF110F was offered from the 2013 through to the 2023 model year. The technical data presented here covers the complete specification range for this model, including all engine variants, chassis dimensions, suspension travel, brake specifications, and weight figures. This information is useful for prospective buyers, current owners, and mechanics working on the Honda CRF110F.

AdSense - 728Ã90

Honda CRF110F by Year

2023 Honda CRF110F View specs →

2022 Honda CRF110F View specs →

2017 Honda CRF110F View specs →

2016 Honda CRF110F View specs →

2014 Honda CRF110F View specs →

Spec Evolution

How key specs changed across production years.

Specification	2013	2014	2015	2016	2017	2018	2019	2020	2021	2022	2023
Brakes - Front Diameter (in.)	3.7 inches	4.3 inches ↑	4.3 inches	4.3 inches	4.3 inches	4.3 inches	-	-	-	-
Brakes - Front Diameter (mm)	95 mm	109 mm ↑	109 mm	109 mm	109 mm	109 mm	-	-	-	-
Brakes - Rear Diameter (in.)	3.7 inches	4.3 inches ↑	4.3 inches	4.3 inches	4.3 inches	4.3 inches	-	-	-	-
Brakes - Rear Diameter (mm)	95 mm	109 mm ↑	109 mm	109 mm	109 mm	109 mm	-	-	-	-
Comments	-	Model ID: CRF110F	Model ID: CRF110F	Model ID: CRF110F	Model ID: CRF110F	Model ID: CRF110F	Model ID: CRF110F	Model ID: CRF110F	Model ID: CRF110F.	Model ID: CRF110F.	Model ID: CRF110F.
Bore x Stroke (mm)	53.0 x 45.0 mm	50.0 x 55.6 mm ↓	50.0 x 55.6 mm	50.0 x 55.6 mm	50.0 x 55.6 mm	50.0 x 55.6 mm	50.0 x 55.6 mm	50.0 x 55.6 mm	50.0 x 55.6 mm	50.0 x 55.6 mm	50.0 x 55.6 mm
Bore x Stroke (in,)	2.1 x 1.8 inches	2.0 x 2.2 inches ↓	2.0 x 2.2 inches	2.0 x 2.2 inches	2.0 x 2.2 inches	2.0 x 2.2 inches	2.0 x 2.2 inches	2.0 x 2.2 inches	2.0 x 2.2 inches	2.0 x 2.2 inches	2.0 x 2.2 inches
Displacement (cc)	-	109.00 cc	-	-	-	-	109.0 cc	109.0 cc	109.0 cc	109.0 cc	109.0 cc
Fuel Control	Single Overhead Cams (SOHC)	SOHC	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)	Single Overhead Cams (SOHC)
Ground Clearance (in.)	6.9 inches	6.9 inches	6.9 inches	6.9 inches	6.9 inches	6.9 inches	6.7 inches ↓	6.7 inches	6.7 inches	6.7 inches	6.7 inches
Ground Clearance (mm)	175 mm	175 mm	175 mm	175 mm	175 mm	175 mm	170 mm ↓	170 mm	170 mm	170 mm	170 mm
Frame Type	Steel backbone	-	-	-	-	-	-	-	-	-
Seat Height	667 mm / 26.3 in.	668 mm / 26.3 in. ↑	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	658 mm / 25.9 in. ↓	658 mm / 25.9 in.	658 mm / 25.9 in.	657 mm / 25.9 in. ↓	657 mm / 25.9 in.
Wheelbase	1,064 mm / 41.9 in.	1,064 mm / 41.9 in.	1,064 mm / 41.9 in.	1,064 mm / 41.9 in.	1,064 mm / 41.9 in.	1,064 mm / 41.9 in.	1064 mm / 41.9 in. ↑	1064 mm / 41.9 in.	1064 mm / 41.9 in.	1064 mm / 41.9 in.	1064 mm / 41.9 in.
Fuel Capacity	5.00 litres / 1.32 gallons	4.16 litres / 1.10 gallons ↓	4.16 litres / 1.10 gallons	4.16 litres / 1.10 gallons	4.16 litres / 1.10 gallons	4.16 litres / 1.10 gallons	4.16 litres / 1.10 US gallons	3.79 litres / 1.00 US gallons ↓	3.79 litres / 1.00 US gallons	4.50 litres / 1.19 US gallons ↑	3.79 litres / 1.00 US gallons ↓
Suspension - Front	31mm fork	31.0mm telescopic fork	31.0mm telescopic fork	31.0mm telescopic fork	31.0mm telescopic fork	31.0mm telescopic fork	31.0mm telescopic fork	31.0mm telescopic fork	31.0mm telescopic fork	31.0mm inverted telescopic fork	31.0mm telescopic fork
Suspension - Rear	Mono shock	Single-shock	Single-shock	Single-shock	Single-shock	Single-shock	Single-shock	Single-shock	Single-shock	Single-shock	Single-shock
Fuel System	Carburettor. 22mm piston-valve carburator	Carburettor. 13mm piston-valve carburetor ↓	Carburettor. 13mm piston-valve carburetor	Carburettor. 13mm piston-valve carburetor	Carburettor. 13mm piston-valve carburetor	Carburettor. 13mm piston-valve carburetor	Carburettor. 13mm piston-valve carburetor	Injection. 19mm throttle bore ↑	Injection. 19mm throttle bore	Injection. 19mm throttle bore	Injection. 19mm throttle bore
Colours	Red/white	Red	Red	Red	Red	Red	Red	Red	Red	Red	Red/blue/white, white/green
Final Drive	Chain	Chain	Chain	Chain	Chain	Chain	Chain (final drive)	Chain (final drive)	Chain (final drive)	Chain (final drive)	Chain (final drive)
Height	912 mm / 35.9 in.	912 mm / 35.9 in.	912 mm / 35.9 in.	912 mm / 35.9 in.	912 mm / 35.9 in.	912 mm / 35.9 in.	912 mm / 35.9 in.	912 mm / 35.9 in.	912 mm / 35.9 in.	922 mm / 36.3 in. ↑	922 mm / 36.3 in.
Length	1,560 mm / 61.4 in.	1,560 mm / 61.4 in.	1,560 mm / 61.4 in.	1,560 mm / 61.4 in.	1,560 mm / 61.4 in.	1,560 mm / 61.4 in.	1560 mm / 61.4 in. ↑	1560 mm / 61.4 in.	1560 mm / 61.4 in.	1541 mm / 60.7 in. ↓	1541 mm / 60.7 in.
Wet Weight	74.0 kg / 163.1 lbs	73.9 kg / 163.0 lbs ↓	73.9 kg / 163.0 lbs	73.9 kg / 163.0 lbs	73.9 kg / 163.0 lbs	73.9 kg / 163.0 lbs	73.9 kg / 163.0 lbs	77.1 kg / 170.0 lbs ↑	77.1 kg / 170.0 lbs	76.7 kg / 169.1 lbs ↓	76.7 kg / 169.1 lbs
Warranty	6 months	Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.	Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.	Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.	Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.	Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.	Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.	Six Months transferable limited warranty	Six Months transferable limited warranty	Six Months transferable limited warranty	Six Months transferable limited warranty
Compression Ratio	9.4:1	9.0:1 ↓	9.0:1	9.0:1	9.0:1	9.0:1	9.0:1	9.0:1	9.0:1	9.0:1	9.0:1
Emissions	Meets current CARB and EPA standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.	Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.
Width	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	668 mm / 26.3 in.	678 mm / 26.7 in. ↑	678 mm / 26.7 in.
Tyres - Rear	80/100-12	80/100-12	80/100-12	80/100-12	80/100-12	80/100-12	-	-	-	-
Primary Drive	Constant mesh	#428 chain; 14T/50T	-	-	-	-	-	#420 Chain	#420 Chain	#420 Chain	#420 Chain
Rake	-	24.0°	24.0°	24.0°	24.0°	24.0°	25.0° ↑	25.1° ↑	25.1°	25.1°	25.4° ↑
Fuel Reserve	1.00 litres / 0.26 gallons	1.00 litres / 0.26 gallons	1.00 litres / 0.26 gallons	1.00 litres / 0.26 gallons	1.00 litres / 0.26 gallons	1.00 litres / 0.26 gallons	1.00 litres / 0.26 US gallons	-	-	-	-
Trail	-	53 mm / 2.1 in.	53 mm / 2.1 in.	53 mm / 2.1 in.	53 mm / 2.1 in.	53 mm / 2.1 in.	53 mm / 2.1 in.	53 mm / 2.1 in.	53 mm / 2.1 in.	53 mm / 2.1 in.	51 mm / 2.0 in. ↓
Wheel Travel - Front	90 mm / 3.5 in.	90 mm / 3.5 in.	90 mm / 3.5 in.	99 mm / 3.9 in. ↑	99 mm / 3.9 in.	99 mm / 3.9 in.	99 mm / 3.9 in.	99 mm / 3.9 in.	99 mm / 3.9 in.	99 mm / 3.9 in.	99 mm / 3.9 in.
Wheel Travel - Rear	96 mm / 3.8 in.	96 mm / 3.8 in.	96 mm / 3.8 in.	86 mm / 3.4 in. ↓	86 mm / 3.4 in.	86 mm / 3.4 in.	97 mm / 3.8 in. ↑	97 mm / 3.8 in.	97 mm / 3.8 in.	97 mm / 3.8 in.	97 mm / 3.8 in.
Ignition	CD	CDI	CDI	CDI	CDI	CDI	CDI	CDI	CDI	CDI	CDI
Max Torque	8.85 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions	8.85 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500	8.85 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions	8.85 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions	8.85 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions	8.85 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions	8.9 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions" ↑	8.9 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions"	8.9 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions"	8.9 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 Revolutions"	8.9 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500 rpm
