Honda CRF250RX Specs
2019 - 2023
• 2 variants
The Honda CRF250RX is an enduro motorcycle produced from 2019 to 2023 across 2 variants. It is powered by a 33mm intake valve, titanium; 26mm exhaust, titanium displacing 249.0 cc.
About the Honda CRF250RX
The Honda CRF250RX is a Enduro / Off-Road motorcycle from Honda, produced from 2019 to 2023. This page provides a comprehensive technical reference for the Honda CRF250RX, covering all available specification data including engine configuration, displacement, power output, dimensions, weight, and chassis details. Use the year selector above to find specifications for a specific model year. All data is sourced from manufacturer specifications and is intended as a technical reference for riders, mechanics, and enthusiasts.
Honda CRF250RX by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2019
|
2020
|
2021
|
2022
|
2023
|
|
Comments
|
Model ID: CRF250RX | Model ID: CRF250RX | Model ID: CRF250RX | Model ID: CRF250RX. HRC Launch Control. 3 riding modes. | Model ID: CRF250RX. HRC Launch Control. 3 riding modes. |
|
Displacement (cc)
|
249.0 cc | 249.0 cc | 249.0 cc | 249.4 cc ↑ | 249.4 cc |
|
Displacement (ci)
|
15.19 cubic inches | 15.19 cubic inches | 15.19 cubic inches | 15.22 cubic inches ↑ | 15.22 cubic inches |
|
Ground Clearance (in.)
|
12.9 inches | 12.9 inches | 12.9 inches | 13.2 inches ↑ | 13.2 inches |
|
Ground Clearance (mm)
|
328 mm | 328 mm | 328 mm | 335 mm ↑ | 335 mm |
|
Oil Capacity (l)
|
1.80 litres | - | - | 1.40 litres | 1.40 litres |
|
Oil Capacity (Quarts)
|
1.9 US quarts | - | - | 1.48 US quarts | 1.48 US quarts |
|
Seat Height
|
960 mm / 37.8 in. | 960 mm / 37.8 in. | 960 mm / 37.8 in. | 964 mm / 38.0 in. ↑ | 964 mm / 38.0 in. |
|
Wheelbase
|
1481 mm / 58.3 in. | 1486 mm / 58.5 in. ↑ | 1486 mm / 58.5 in. | 1477 mm / 58.1 in. ↓ | 1477 mm / 58.1 in. |
|
Brakes - Front
|
Single disc. Two-piston calipers. | Single disc. Hydraulic | Single disc. Hydraulic | Single disc. Hydraulic | Single disc. Hydraulic |
|
Brakes - Rear
|
Single disc | Single disc. Hydraulic | Single disc. Hydraulic | Single disc. Hydraulic | Single disc. Hydraulic |
|
Fuel Capacity
|
8.52 litres / 2.25 US gallons | 8.52 litres / 2.25 US gallons | 8.52 litres / 2.25 US gallons | 8.00 litres / 2.11 US gallons ↓ | 8.00 litres / 2.11 US gallons |
|
Suspension - Front
|
49mm fully adjustable leading-axle inverted telescopic Showa SPG coil-spring fork. | 49mm fully adjustable leading-axle inverted telescopic Showa SPG coil-spring fork. | 49mm fully adjustable leading-axle inverted telescopic Showa SPG coil-spring fork. | 49mm Showa coil-spring USD fork | 49mm leading-axle inverted Showa® SPG coil-spring fork with rebound- and compression-damping adjustability |
|
Suspension - Rear
|
Pro-Link system; fully adjustable Showa single shock | Pro-Link system; fully adjustable Showa single shock | Pro-Link system; fully adjustable Showa single shock | Showa Mono shock with Honda Pro-Link | Showa single shock with spring preload, rebound- and compression-damping adjustability |
|
Fuel System
|
Injection. Dual-Timing Programmed Fuel Injection (PGM-FI), 46mm throttle body | Injection. Dual-Timing Programmed Fuel Injection (PGM-FI), 46mm throttle body | Injection. Rogrammed Fuel-Injection system (PGM-FI); 44mm throttle bore ↓ | - | Injection. Rogrammed Fuel-Injection system (PGM-FI); 44mm throttle bore |
|
Clutch
|
Multi plate wet clutch | Multi plate wet | Multi plate wet | Multi plate wet | Multi plate wet |
|
Height
|
1262 mm / 49.7 in. | 1262 mm / 49.7 in. | 1262 mm / 49.7 in. | 1281 mm / 50.4 in. ↑ | 1281 mm / 50.4 in. |
|
Rims
|
Dunlop Geomax MX3S | Dunlop Geomax AT81 ↑ | Dunlop Geomax AT81 | - | Dunlop Geomax AT81 tires. |
|
Length
|
2184 mm / 86.0 in. | 2184 mm / 86.0 in. | 2184 mm / 86.0 in. | 2170 mm / 85.4 in. ↓ | 2170 mm / 85.4 in. |
|
Wet Weight
|
110.7 kg / 244.0 lbs | 110.7 kg / 244.0 lbs | 110.7 kg / 244.0 lbs | 108.0 kg / 238.1 lbs ↓ | 108.0 kg / 238.1 lbs |
|
Tyres - Front
|
80/100-21 | 80/100-21 | 80/100-21 | 80/100-21 | 90/90-21 ↑ |
|
Width
|
828 mm / 32.6 in. | 828 mm / 32.6 in. | 828 mm / 32.6 in. | 839 mm / 33.0 in. ↑ | 839 mm / 33.0 in. |
|
Primary Drive
|
#520 Chain; 13T/48T | #520 Chain; 13T/48T | #520 Chain; 13T/48T | #520 Chain; 13T/48T | #520 Chain; 13T/50T |
|
Rake
|
27.0° | 27.2° ↑ | 27.2° | 27.2° | 27.2° |
|
Sprocket
|
- | - | - | 13/48 (front/rear) | 13/50 (front/rear) |
|
Wheel Travel - Front
|
305 mm / 12.0 in. | 305 mm / 12.0 in. | 305 mm / 12.0 in. | 305 mm / 12.0 in. | 310 mm / 12.2 in. ↑ |
|
Wheel Travel - Rear
|
315 mm / 12.4 in. | 315 mm / 12.4 in. | 315 mm / 12.4 in. | 315 mm / 12.4 in. | 312 mm / 12.3 in. ↓ |
|
Ignition
|
Full transistor | Full transistor | Full transistorized | Full transistorized | Full transistorized |
