The Honda CRF70F is an enduro motorcycle produced from 2012 across 1 variant. Engine displacement is 70.00 cc. Peak torque is 4 Nm.
About the Honda CRF70F
Honda introduced the CRF70F as part of their Cross / motocross range, with production running from 2004 to 2016. This technical reference page documents the full specification sheet for the Honda CRF70F, including engine displacement, power and torque figures, frame and suspension geometry, braking systems, and overall dimensions. Select a model year above to view year-specific technical data. Specifications are compiled from official manufacturer sources.
Honda CRF70F by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2004
|
2005
|
2006
|
2007
|
2008
|
2009
|
2010
|
2011
|
2012
|
2014
|
2015
|
2016
|
|
Fuel Control
|
SOHC | SOHC | - | SOHC | SOHC | SOHC | SOHC | SOHC | SOHC | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) |
|
Engine Type
|
Single cylinder | Single cylinder | Single cylinder | Single cylinder | Single cylinder | Single cylinder, four-stroke | Single cylinder, four-stroke | Single cylinder, four-stroke | Single cylinder, four-stroke | Single cylinder, four-stroke | Single cylinder, four-stroke | Single cylinder, four-stroke |
|
Comments
|
- | - | - | - | - | - | - | - | French brand. | Model ID: CRF70F | Model ID: CRF70F | Model ID: CRF70F |
|
Displacement (ci)
|
4.27 cubic inches | 4.39 cubic inches ↑ | 4.39 cubic inches | 4.39 cubic inches | 4.39 cubic inches | 4.39 cubic inches | 4.39 cubic inches | 4.39 cubic inches | 4.39 cubic inches | - | - | - |
|
Displacement (cc)
|
70.00 cc | 72.00 cc ↑ | 72.00 cc | 72.00 cc | 72.00 cc | 72.00 cc | 72.00 cc | 72.00 cc | 72.00 cc | - | - | - |
|
Dry Weight
|
- | 58.1 kg / 128.0 lbs | 58.1 kg / 128.0 lbs | 58.1 kg / 128.0 lbs | - | - | - | - | 58 kg / 127.9 lbs | - | - | - |
|
Fuel Capacity
|
5.67 litres / 1.50 gallons | 5.67 litres / 1.50 gallons | 5.67 litres / 1.50 gallons | 5.67 litres / 1.50 gallons | 4.92 litres / 1.30 gallons ↓ | 4.92 litres / 1.30 gallons | 4.92 litres / 1.30 gallons | 4.92 litres / 1.30 gallons | 5.50 litres / 1.45 gallons ↑ | 4.92 litres / 1.30 gallons ↓ | 4.92 litres / 1.30 gallons | 4.92 litres / 1.30 gallons |
|
Suspension - Front
|
27.0mm telescopic fork | 27.0mm telescopic fork | 27.0 mm telescopic fork | 27.0mm telescopic fork | 27.0mm telescopic fork | 27.0mm telescopic fork | 27.0mm telescopic fork | 27.0mm telescopic fork | 27mm leading-axle telescopic fork | 27.0mm telescopic fork | 27.0mm telescopic fork | 27.0mm telescopic fork |
|
Suspension - Rear
|
Single-shock. | Single-shock | Single-shock | Single-shock | Single-shock | Single-shock | Single-shock | Single-shock | Mono-cushion swingarm | Single-shock | Single-shock | Single-shock |
|
Colours
|
Red | Red | Red | - | Red | Red | Red | Red | Red/white | Red | Red | Red/white |
|
Clutch
|
- | - | - | - | - | - | - | Wet, multiplate | Automatic | Automatic | Automatic | Automatic |
|
Rims
|
- | - | - | - | - | - | - | - | Steel rim/wire spoke | - | - | Wire spoked |
|
Wet Weight
|
- | - | - | - | - | 63.0 kg / 139.0 lbs | 63.0 kg / 139.0 lbs | 63.1 kg / 139.0 lbs ↑ | 94.0 kg / 207.2 lbs ↑ | 63.1 kg / 139.0 lbs ↓ | 63.1 kg / 139.0 lbs | 63.1 kg / 139.0 lbs |
|
Tyres - Front
|
- | 70/70-19 | 70/70-19 | - | 70/0-19 | 70/14-19 | 2.50-14 ↓ | 2.50-14 | 2.50-14 | 2.50-14 | 2.50-14 | 2.50-14 |
|
Gearbox
|
Automatic | 3-speed | 3-speed | 3-speed | 3-speed | 3-speed | 3-speed | 3-speed | 3-speed | 3-speed | 3-speed | 3-speed |
|
Width
|
- | - | - | - | - | - | - | 1,016 mm / 40.0 in. | 694 mm / 27.3 in. ↑ | - | - | - |
|
Tyres - Rear
|
- | 90/90-16 | 90/90-16 | - | 90/80-16 | 90/12-16 | 3.00-.12 ↓ | 3.00-12 | 3.00-12 | 3.00-12 | 3.00-12 | 3.00-12 |
|
Primary Drive
|
- | - | - | - | - | - | - | #420 chain; 15T/36T | #420 chain; 15T/36T | #420 chain; 15T/36T | #420 chain; 15T/36T | #420 chain, 15T/36T |
|
Rake
|
27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° | 27.0° |
|
Fuel Reserve
|
1.13 litres / 0.30 gallons | - | - | - | - | - | 1.13 litres / 0.30 gallons | - | 1.10 litres / 0.29 gallons | - | 1.14 litres / 0.30 gallons | 1.14 litres / 0.30 gallons |
|
Wheel Travel - Front
|
81 mm / 3.2 in. | 81 mm / 3.2 in. | 81 mm / 3.2 in. | - | 81 mm / 3.2 in. | 81 mm / 3.2 in. | 81 mm / 3.2 in. | 81 mm / 11.8 in. | 100 mm / 3.9 in. ↑ | 90 mm / 3.5 in. ↓ | 90 mm / 3.5 in. | 90 mm / 3.5 in. |
|
Wheel Travel - Rear
|
89 mm / 3.5 in. | 89 mm / 3.5 in. | 89 mm / 3.5 in. | - | 89 mm / 3.5 in. | 89 mm / 3.5 in. | 89 mm / 3.5 in. | 89 mm / 3.5 in. | 90 mm / 3.5 in. ↑ | 70 mm / 2.8 in. ↓ | 70 mm / 2.8 in. | 70 mm / 2.8 in. |
|
Starter
|
- | - | - | - | - | - | Electric & kick | Electric | Kick | Kick | Kick | Kick |
|
Valve System
|
2 | - | 2 | - | - | - | - | 4 | - | - | 2 | 2 |
