Full Specifications
General
Year
2015 - 16
Make Model
Husqvarna 701 Supermoto
Dimensions
Seat Height
890 mm / 35.0 in
Wheelbase
1480 mm ± 15 mm / 58.2 in ± 0.59 in
Ground Clearance
270 mm / 10.6 in
Weights & Capacities
Dry Weight
145 kg / 319.6 lbs
Fuel Capacity
13 Litres / 3.4 US gal
Performance
Max Power
55 kW / 74 hp @ 8000 rpm
Max Torque
71 Nm / 52.4 ft-lb @ 6750 rpm
Engine
Displacement
692.7 cc / 42.27 cu in
Engine Detail
Four stroke, single cylinder, SOHC, 4 valves
Bore x Stroke
105 x 80 mm
Compression Ratio
12.7:1
Cooling System
Liquid cooling
Engine Management
Keihin EMS with Ride By Wire
Engine Oil Specification
Bel Ray, SAE 10W-50
Exhaust
Stainless steel silencer with regulated catalytic converter
Fuel Induction
Keihin EMS with RBW
Ignition
Double ignition
Lubrication
Pressure lubrication with 2 oil pumps
Starter
Electric
EV Specifics
Battery Capacity
12V 8.6Ah
Drivetrain
Clutch
APTC slipper clutch, hydraulically operated
Final Drive
Chain X-Ring 5/8 x 1/4
Final Drive Ratio
16:42
Primary Drive Ratios
36:79
Transmission / Drive
6 Speed
Chassis
Frame Type
Chromium-Molybdenum-Steel trellis frame, powder coated, Subframe Self-supporting polyamide tank
Suspension - Front
48 mm WP-USD split function fork
Suspension - Rear
WP-Monoshock with Pro-Lever linkage
Clamp Offset - Triple
35 mm / 33 mm
Handlebar
Aluminium, tapered, Ø 28/22 mm
Steering Head Angle
63°
Trail
112 mm / 4.4 in
Wheel Travel - Front
215 mm / 8.4 in
Wheel Travel - Rear
250 mm / 9.8 in
Wheels & Brakes
Brakes - Front
Single 320 mm disc, Brembo four piston, radially bolted caliper
Brakes - Rear
Single 240 mm disc, Brembo single piston, floating caliper
ABS
ABS Bosch 9M+ Two Channel (disengageable, supermoto mode)
Tyres - Front
120/70 ZR 17
Tyres - Rear
160/60 ZR 17
Wheels - Front
Spoked wheels with aluminium tubeless rims 3.50 x 17
Wheels - Rear
Spoked wheels with aluminium tubeless rims 5.00 x 17
