Key Specifications
Engine
Four stroke, 60° V Twin , DOHC, 4-Valves per Cylinder, Graded Buckets
Power
120 hp / 89.5 kW @ 6000 rpm
Torque
115.2 Nm / 85 lb-ft @ 6000 rpm
Fuel Capacity
12.9 Litres / 3.4 US gal
Advertisement
Full 2020 Indian FTR 1200S Specifications
Year
2019 - 20
Make Model
Indian FTR1200S
Seat Height
841 mm / 33.1 in
Wheelbase
1524 mm / 60 in
Ground Clearance
183 mm / 7.2 in
Height
1297 mm / 51.1 in
Length
2286 mm / 90 in
Width
850 mm / 33.5 in
Dry Weight
221 kg / 489 lbs
Fuel Capacity
12.9 Litres / 3.4 US gal
Maximum Load / GVWR
430 kg / 948 lb
Wet Weight
235 kg / 518 lbs
Displacement
1203 cc / 73 cu-in
Engine Detail
Four stroke, 60° V Twin , DOHC, 4-Valves per Cylinder, Graded Buckets
Bore x Stroke
102 x 73.6 mm
Compression Ratio
12.5:1
Cooling System
Liquid Cooled
Exhaust
2-1-2
Fuel Induction
Electronic Fuel Injection Closed Loop, 60 mm Bore
Starter
Electric
Clutch
Wet multi-plate w/ assist-and-slip
Final Drive
525 Chain
Final Drive Ratio
2.882 : 1
Gear Ratios
1st 2.769 : 1 2nd 1.882 : 1 3rd 1.500 : 1 4th 1.273 : 1 5th 1.125 : 1 6th 1.036 : 1
Transmission / Drive
6 Speed
Frame Type
Steel trellis
Suspension - Front
Fully adjustable inverted 43mm telescopic cartridge fork
Suspension - Rear
Fully adjustable piggyback IFP
Lean Angle
43°
Rake
26.3°
Trail
130 mm / 5.1 in
Wheel Travel - Front
150 mm / 5.9 in
Wheel Travel - Rear
150 mm / 5.9 in
Brakes - Front
2x 320mm Rotor Brembo with 4-Piston Calipers
Brakes - Rear
Single 265mm Rotor Brembo with 2-Piston Calipers
ABS
Standard, defeatable (Standard, not defeatable)
Tyres - Front
120/70R19 60V Dunlop DT3-R Radial
Tyres - Rear
150/80R18 70V Dunlop DT3-R Radial
Wheels - Front
Cast 19 in x 3 in
Wheels - Rear
Cast 18 in x 4.25 in
