The Kawasaki VN900 Custom is a cruiser produced from 2009 across 1 variant. It is powered by a reed valve. displacing 903.00 cc. Peak torque is 78 Nm.
About the Kawasaki VN900 Custom
The Kawasaki VN900 Custom is a Custom / cruiser motorcycle from Kawasaki, produced from 2009 to 2014. This page provides a comprehensive technical reference for the Kawasaki VN900 Custom, covering all available specification data including engine configuration, displacement, power output, dimensions, weight, and chassis details. Use the year selector above to find specifications for a specific model year. All data is sourced from manufacturer specifications and is intended as a technical reference for riders, mechanics, and enthusiasts.
Kawasaki VN900 Custom by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2009
|
2010
|
2011
|
2012
|
2013
|
2014
|
|
Ground Clearance (in.)
|
- | - | 9.3 inches | 9.3 inches | 5.3 inches ↓ | 5.5 inches ↑ |
|
Ground Clearance (mm)
|
- | - | 236 mm | 236 mm | 135 mm ↓ | 140 mm ↑ |
|
Seat Height
|
686 mm / 27.0 in. | 686 mm / 27.0 in. | 685 mm / 27.0 in. ↓ | 685 mm / 27.0 in. | 680 mm / 26.8 in. ↓ | 685 mm / 27.0 in. ↑ |
|
Wheelbase
|
1,646 mm / 64.8 in. | 1,646 mm / 64.8 in. | 1,645 mm / 64.8 in. | 1,645 mm / 64.8 in. | 1,645 mm / 64.8 in. | 1,645 mm / 64.8 in. |
|
Brakes - Front
|
Single disc | Single disc | Single disc | Single disc | Single disc. Twin-piston | Single disc |
|
Fuel Capacity
|
20.06 litres / 5.30 gallons | 20.06 litres / 5.30 gallons | 20.00 litres / 5.28 gallons ↓ | 20.00 litres / 5.28 gallons | 20.00 litres / 5.28 gallons | 20.00 litres / 5.28 gallons |
|
Brakes - Rear
|
Single disc | Single disc | Single disc | Single disc | Single disc. Twin-piston | Single disc |
|
Suspension - Front
|
41mm hydraulic telescopic fork / 5.9 in. | 41mm hydraulic telescopic fork / 5.9 in. | 41 mm telescopic fork | 41 mm telescopic fork | 41 mm telescopic fork with 7-way preload | 41 mm telescopic fork |
|
Suspension - Rear
|
Uni-Track swingarm, seven-way adjustable spring preload / 4.1 in. | Uni-Track® swingarm, seven-way adjustable spring preload / 4.1 in. | Uni-Trak | Uni-Trak | Uni-Trak | Uni-Trak |
|
Colours
|
Black | Black, blue | Realtree APG HD camouflage | Orange | Ebony/gray | Ebony/gray |
|
Clutch
|
- | - | - | Wet, multiplate | Wet multi-disc, manual | Wet multi-disc, manual |
|
Final Drive
|
Belt | Belt | Shaft drive (cardan) | Belt | Belt | Belt |
|
Height
|
1,120 mm / 44.1 in. | 1,120 mm / 44.1 in. | 1,120 mm / 44.1 in. | 1,146 mm / 45.1 in. ↑ | 1,120 mm / 44.1 in. ↓ | 1,120 mm / 44.1 in. |
|
Wet Weight
|
- | 282.0 kg / 621.7 lbs | 278.0 kg / 612.9 lbs ↓ | 278.0 kg / 612.9 lbs | 278.0 kg / 612.9 lbs | 278.0 kg / 612.9 lbs |
|
Tyres - Front
|
80/90-21 | 80/90-21 | 25/8-12 ↓ | 80/90-M21 ↑ | 130/90-16 ↑ | 25/8-12 ↓ |
|
Width
|
894 mm / 35.2 in. | 894 mm / 35.2 in. | 895 mm / 35.2 in. ↑ | 895 mm / 35.2 in. | 895 mm / 35.2 in. | 895 mm / 35.2 in. |
|
Tyres - Rear
|
180/70-15 | 180/70-15 | 180/70-M15 | 180/70-M15 | 180/70-15 | 180/70-M15 |
|
Exhaust
|
- | - | - | Slash-cut stacked silencers | Compact custom slash cut pipes | - |
|
Lighting system
|
- | - | - | 30W x 2 halogen | 30W x 2 halogen | 30W halogen headlights / 5W taillight / 18W stoplight |
|
Ignition
|
TCBI with Electronic Advance | TCBI with Electronic Advance | Digital | Digital | Digital | Digital |
