Comments
|
Small windscreen. | Small windscreen. | - | Windscreen. Traction control. | Traction control. Small windscreen. | Traction control. Small windscreen. |
|
Displacement (cc)
|
948.00 cc | 948.0 cc | 948.0 cc | 948.0 cc | 948.0 cc | 948.0 cc |
|
Seat Height
|
820 mm / 32.3 in. | 820 mm / 32.3 in. | 836 mm / 32.9 in. ↑ | 820 mm / 32.3 in. ↓ | 820 mm / 32.3 in. | 820 mm / 32.3 in. |
|
Frame Type
|
Trellis, high tensile steel | Trellis, high tensile steel | Tubular, diamond | Tubular, diamond | Tubular, diamond | Trellis, high tensile steel |
|
Wheelbase
|
1,470 mm / 57.9 in. | 1470 mm / 57.9 in. ↑ | 1470 mm / 57.9 in. | 1470 mm / 57.9 in. | 1470 mm / 57.9 in. | 1470 mm / 57.9 in. |
|
Fuel Capacity
|
17.03 litres / 4.50 gallons | 17.03 litres / 4.50 US gallons | 17.03 litres / 4.50 US gallons | 17.03 litres / 4.50 US gallons | 17.03 litres / 4.50 US gallons | 17.03 litres / 4.50 US gallons |
|
Suspension - Front
|
41 mm inverted fork with compression and rebound damping and spring preload adjustability | 41 mm inverted fork with compression and rebound damping and spring preload adjustability | Inverted telescopic fork with (10-way) adjustable compression and rebound (12-way) damping, spring preload ↓ | Inverted telescopic fork with (10-way) adjustable compression and rebound (12-way) damping, spring preload | Inverted telescopic fork with (13-way) adjustable compression and rebound (11-way) damping, spring preload (15-turn ↑ | Inverted telescopic fork with (13-way) adjustable compression and rebound (11-way) damping, spring preload (15-turn |
|
Suspension - Rear
|
Horizontal Back-link, gas-charged shock with rebound damping and spring preload adjustability | Horizontal Back-link, gas-charged shock with rebound damping and spring preload adjustability | Horizontal back-link swingarm with stepless adjustable rebound damping and spring preload | Horizontal back-link swingarm with stepless adjustable rebound damping and spring preload | Horizontal back-link swingarm with stepless adjustable rebound damping and spring preload | Horizontal back-link swingarm with stepless adjustable rebound damping and spring preload |
|
Colours
|
Vintage Lime Green | Vintage Lime Green, Metallic Graphic Grey | Vintage Lime Green/Ebony | Pearl Storm Gray | Metallic Diablo Black | Metallic Diablo Black |
|
Clutch
|
Wet multi-disc, manual | Wet multi-disc, manual | Wet multi-disc, manual | Assist and Slipper Clutch | Wet multi-disc, manual | Wet multi-disc, manual |
|
Final Drive
|
Chain | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) |
|
Height
|
1,190 mm / 46.9 in. | 1190 mm / 46.9 in. ↑ | 1191 mm / 46.9 in. ↑ | 1191 mm / 46.9 in. | 1191 mm / 46.9 in. | 1191 mm / 46.9 in. |
|
Length
|
2,100 mm / 82.7 in. | 2100 mm / 82.7 in. ↑ | 2101 mm / 82.7 in. ↑ | 2101 mm / 82.7 in. | 2101 mm / 82.7 in. | 2101 mm / 82.7 in. |
|
Wet Weight
|
216.0 kg / 476.2 lbs | 216.0 kg / 476.2 lbs | 215.1 kg / 474.1 lbs ↓ | 216.1 kg / 476.3 lbs ↑ | 214.6 kg / 473.0 lbs ↓ | 216.1 kg / 476.3 lbs ↑ |
|
Width
|
845 mm / 33.3 in. | 845 mm / 33.3 in. | 846 mm / 33.3 in. ↑ | 846 mm / 33.3 in. | 841 mm / 33.1 in. ↓ | 841 mm / 33.1 in. |
|
Rake
|
25.0° | 25.0° | 25.0° | 25.0° | 25.0° | 25.0° |
|
Exhaust
|
- | - | - | - | Tuned stainless steel exhaust | Tuned exhaust with brushed finish |
|
Lighting system
|
- | - | - | LED headlight | Round LED headlight | Round LED headlight |
|
Max Torque
|
98.50 Nm (10.0 kgf-m or 72.7 ft.lbs) @ 6500 Revolutions | 98.5 Nm (10.0 kgf-m or 72.7 ft.lbs) @ 6500 Revolutions" | 98.5 Nm (10.0 kgf-m or 72.7 ft.lbs) @ 6500 Revolutions" | 98.5 Nm (10.0 kgf-m or 72.7 ft.lbs) @ 6500 Revolutions" | 98.0 Nm (10.0 kgf-m or 72.3 ft.lbs) @ 6500 Revolutions" ↓ | 98.0 Nm (10.0 kgf-m or 72.3 ft.lbs) @ 6500 Revolutions" |
