Key Specifications
Engine
Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder
Power
104 hp / 77 kW @ 8000 rpm
Weight
194 kg / 427.7 lbs
Fuel Capacity
15.8 Litres / 4.2 US gal
Advertisement
Full 2023 KTM 890 SMT Specifications
Year
2023
Make Model
KTM 890 SMT
Seat Height
860 mm / 33.9 in
Wheelbase
1502 mm / 59.1 in
Ground Clearance
227 mm / 8.9 in
Dry Weight
194 kg / 427.7 lbs
Fuel Capacity
15.8 Litres / 4.2 US gal
Displacement
889 cc / 54.2 cu-in
Engine Detail
Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder
Bore x Stroke
90.7 x 68.8 mm
Compression Ratio
13.5:1
Cooling System
Liquid cooled with water/oil heat exchanger
Emissions
EURO5
Engine Management
Bosch EMS with RBW
Fuel Induction
DKK Dell'Orto fuel-Injection throttle body 46mm
Lubrication
Forced oil lubrication with 2 oil pumps
Starter
Electric
Clutch
PASC antihopping clutch, mechanically operated
Final Drive
Chain 520 X-Ring
Transmission / Drive
6 Speed
Frame Type
Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Suspension - Front
43mm WP APEX upside-down forks
Suspension - Rear
WP APEX Monoshock
Rake
24.3°
Steering Head Angle
64.21°
Wheel Travel - Front
180 mm / 7.1 in
Wheel Travel - Rear
180 mm / 7.1 in
Traction control
Three mode, disengageable, lean sensitive, optional
Brakes - Front
2 x 320mm discs, 4 piston, radially mounted caliper
Brakes - Rear
Single 260mm disc, 1 piston floating caliper
ABS
Bosch 9.1 MP (incl. Cornering ABS and Supermoto mode)
Tyres - Front
120/70 ZR 17
Tyres - Rear
180/55 ZR 17
Wheels - Front
Cast aluminium wheels 3.50 X 17
Wheels - Rear
Cast aluminium wheels 5.50 X 17
