Suzuki SV 650S Specs

2005 - 2007 • 3 variants

The Suzuki SV 650S is a sport motorcycle produced from 2005 to 2007 across 3 variants. It is powered by a four stroke, 90°-v-twin, dohc, 4 valves per cylinder displacing 645.00 cc. Peak torque is 64 Nm.

About the Suzuki SV 650S

Suzuki introduced the SV 650S as part of their All-Round range, with production running from 1999 to 2016. This technical reference page documents the full specification sheet for the Suzuki SV 650S, including engine displacement, power and torque figures, frame and suspension geometry, braking systems, and overall dimensions. Select a model year above to view year-specific technical data. Specifications are compiled from official manufacturer sources.

AdSense - 728Ã90

Suzuki SV 650S by Year

2007 Suzuki SV 650S View specs →

2006 Suzuki SV 650S View specs →

Spec Evolution

How key specs changed across production years.

Specification	1900	2000	2002	2004	2006	2007	2012	2014	2015	2016
Ground Clearance (mm)	-	-	140 mm	133 mm ↓	155 mm ↑	155 mm	150 mm ↓	135 mm ↓	135 mm	155 mm ↑
Ground Clearance (in.)	-	-	5.5 inches	5.2 inches ↓	6.1 inches ↑	6.1 inches	5.9 inches ↓	5.3 inches ↓	5.3 inches	6.1 inches ↑
Fuel Control	-	-	DOHC	DOHC	DOHC	DOHC	DOHC	DOHC	Double Overhead Cams/Twin Cam (DOHC)	Double Overhead Cams/Twin Cam (DOHC)
Engine Type	-	V2	V2	V2	V2	V2	V2, four-stroke	V2, four-stroke	V2, four-stroke	V2, four-stroke
Displacement (ci)	-	39.91 cubic inches	39.36 cubic inches ↓	39.36 cubic inches	39.36 cubic inches	39.36 cubic inches	39.36 cubic inches	39.36 cubic inches	-	39.36 cubic inches
Displacement (cc)	-	654.00 cc	645.00 cc ↓	645.00 cc	645.00 cc	645.00 cc	645.00 cc	645.00 cc	-	645.00 cc
Comments	-	-	-	-	-	-	A black/green limited edition version is available.	Sold in the Philippines.	-	-
Frame Type	Aluminium, Trellis frame	-	Aluminium, Trellis frame	Aluminium	Pressure cast aluminium alloy diamond truss	-	Pressure cast aluminium alloy diamond truss	Trellis steel frame	Pressure cast aluminium alloy diamond truss	Aluminium-truss frame
Seat Height	800 mm / 31.5 in	805 mm / 31.7 in. ↑	805 mm / 31.7 in.	800 mm / 31.5 in. ↓	800 mm / 31.5 in.	800 mm / 31.5 in.	800 mm / 31.5 in.	800 mm / 31.5 in	800 mm / 31.5 in	800 mm / 31.5 in.
Dry Weight	169 kg / 372 lbs	169 kg / 372.6 lbs	169 kg / 372 lbs	169 kg / 372.6 lbs	169 kg / 372.6 lbs	169 kg / 372.6 lbs	169 kg / 372 lbs - ABS 171 kg / 376 lbs	169 kg / 372 lbs - ABS 171 kg / 376 lbs	169 kg / 372 lbs - ABS 171 kg / 376 lbs	-
Engine Detail	Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder	-	Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder	Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder	Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder	-	90 degree V-twin	Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder	Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder	90-degree V-Twin
Wheelbase	1 420 mm / 55.9 in	1,420 mm / 55.9 in. ↑	1,420 mm / 55.9 in.	1,430 mm / 56.3 in. ↑	1,430 mm / 56.3 in.	1,430 mm / 56.3 in.	1 430 mm / 56.3 in ↓	1,425 mm / 56.1 in. ↑	1 470 mm / 57.9 in ↓	1,425 mm / 56.1 in. ↑
Brakes - Front	2 x 290 mm Discs, 2 piston calipers	Single disc	2 x 290 mm Discs, 2 piston calipers	Double disc	Double disc	Double disc	2 x 290 mm Discs, 2 piston calipers	Double disc	2 x 290 mm Discs, 2 piston calipers	Double disc
Brakes - Rear	Single 240 mm disc, 2 piston caliper	Single disc	Single disc	Single 240 mm disc, 2 piston caliper	Single 240 mm disc, 2 piston caliper	Single disc	Single disc	Single disc	Single 240 mm disc, 2 piston caliper	Single disc
Fuel Capacity	17 Litres / 4.5 US gal / 3.7 Imp gal	16.00 litres / 4.23 gallons ↓	16.00 litres / 4.23 gallons	17.00 litres / 4.49 gallons ↑	17 Litres / 4.5 US gal / 3.7 Imp gal	17.00 litres / 4.49 gallons	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17 Litres / 4.5 US gal / 3.7 Imp gal	17.00 litres / 4.49 gallons
Suspension - Front	Telescopic, coil spring, oil damped, fully adjustable preload	-	Telescopic, coil spring, oil damped, fully adjustable preload	Telescopic, coil spring, oil damped, fully adjustable preload	Telescopic 41 mm, coil spring, oil damped, fully adjustable preload	Telescopic, coil spring, oil damped, fully adjustable preload	Telescopic, coil spring, oil damped, fully adjustable preload	Telescopic, coil spring, oil damped	Telescopic 41 mm, coil spring, oil damped, fully adjustable preload	Telescopic, coil spring, oil damped
Suspension - Rear	Link-type, 7-way adjustable spring preload	-	Link-type, 7-way adjustable spring preload	KYB single shock, adjustable spring preload	KYB single shock, adjustable spring preload	Link-type, 7-way adjustable spring preload	Link-type, 7-way adjustable spring preload	Link, type, coil spring, oil damped	KYB single shock, adjustable spring preload	Link, type, coil spring, oil damped
Top Speed	204.3 km/h / 126.9 mph	200.0 km/h / 124.3 mph ↓	204.3 km/h / 126.9 mph ↑	204.3 km/h / 126.9 mph	204.3 km/h / 126.9 mph	-	204.3 km/h / 126.9 mph	204.3 km/h / 126.9 mph	204.3 km/h / 126.9 mph	-
Fuel System	-	-	Carburettor	Injection	Injection	Injection	Injection	Injection	Injection	Injection
Colours	-	Yellow, blue	-	Blue, Yellow	Blue, Yellow	Blue, Red	Black, white	Black, White	Pearl Nebular Black, Glass Sparkle White	Pearl Nebular Black, Glass Splash White
Clutch	Wet, multiple discs, cable operated	-	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	-	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	Wet, multiple discs, cable operated	-
Final Drive	Chain, #525 O-ring	-	Chain, #525 O-ring	Chain	Chain	Chain	Chain	Chain, #525 O-ring	Chain, #525 O-ring	Chain
Height	1060 mm / 41.7 in	-	1060 mm / 41.7 in	1,170 mm / 46.1 in. ↓	1,170 mm / 46.1 in.	1,170 mm / 46.1 in.	1,170 mm / 46.1 in.	1175 mm / 46.3 in ↑	1170 mm / 46.1 in ↓	1,170 mm / 46.1 in. ↓
Length	2045 mm / 80.5 in	-	2,045 mm / 80.5 in.	2,085 mm / 82.1 in. ↑	2,080 mm / 81.9 in.	2,085 mm / 82.1 in.	2130 mm / 83.9 in ↑	2,085 mm / 82.1 in. ↓	2120 mm / 83.5 in ↑	2,085 mm / 82.1 in. ↓
Wet Weight	189 kg / 417 lbs	-	189 kg / 417 lbs	189 kg / 417 lbs	189 kg / 417 lbs	-	196.0 kg / 432.1 lbs	202.0 kg / 445.3 lbs ↑	189 kg / 417 lbs - ABS 172 kg / 423 lbs ↓	202.0 kg / 445.3 lbs ↑
Warranty	-	-	-	-	-	-	1 year unlimited mileage limited warranty	1 year limited warranty.	-	-
Tyres - Front	120/60 ZR17	-	120/60-ZR17	120/60-ZR17	120/60-ZR17	120/60-ZR17	120/60-ZR17	120/60-ZR17	120/60 ZR17M/C 55W	120/60-ZR17
Width	790 mm / 31.1 in	-	790 mm / 31.1 in	730 mm / 28.7 in ↓	730 mm / 28.7 in.	730 mm / 28.7 in.	730 mm / 28.7 in	730 mm / 28.7 in.	730 mm / 28.7 in	730 mm / 28.7 in.
Tyres - Rear	160/60 ZR17	-	160/60 ZR17	160/60 ZR17	160/60 ZR17	160/60-ZR17	160/60 ZR17	160/60 ZR17	160/60 ZR17M/C 69W	160/60-ZR17
Primary Drive	-	-	-	-	-	-	#525 chain	5-forward and 1-reverse ↓	-	-
Rake	25°	-	25°	25°	25°	-	25°	25°	25°	25.0°
Fuel Induction	2x Mikuni BDSR39 carburetors	-	2x Mikuni BDSR39 carburetors	Fuel Injection	Fuel Injection	-	Fuel Injection	Fuel Injection	Fuel Injection	-
Trail	102 mm / 4.0 in	-	102 mm / 4.0 in	102 mm / 4.0 in	102 mm / 4.0 in	-	102 mm / 4.0 in	102 mm / 4.0 in	102 mm / 4.0 in	104 mm / 4.1 in. ↑
Wheel Travel - Front	130 mm / 5.1 in	-	130 mm / 5.1 in	130 mm / 5.1 in	130 mm / 5.1 in	-	130 mm / 5.1 in.	130 mm / 5.1 in	130 mm / 5.1 in	-
Wheel Travel - Rear	125 mm / 4.7 in	-	125 mm / 4.7 in	125 mm / 4.7 in	125 mm / 4.7 in	-	134 mm / 5.2 in	134 mm / 5.2 in	134 mm / 5.2 in	-
Ignition	Digital transistorised	-	Digital transistorised	Digital transistorised	Digital transistorised	Digital/Transistorized	Digital transistorised	Digital transistorised	Digital transistorised	Electronic ignition (Transistorised)
Max Torque	64 Nm / 6.53 kg-m / 47.2 lb-ft @ 7200 rpm	62.00 ↓	64 Nm / 6.53 kg-m / 47.2 lb-ft @ 7200 rpm ↑	64 Nm / 6.53 kg-m / 47.2 lb-ft @ 7200 rpm	64 Nm / 6.53 kg-m / 47.2 lb-ft @ 7200 rpm	-	64 Nm / 6.53 kg-m / 47.2 lb-ft @ 7200 rpm	64 Nm / 6.53 kg-m / 47.2 lb-ft @ 7200 rpm	64 Nm / 6.53 kg-m / 47.2 lb-ft @ 7200 rpm	64.00 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 7200 Revolutions
Power-to-Weight Ratio	-	0.4142 HP/kg	0.4242 HP/kg ↑	0.4364 HP/kg ↑	-	-	-	-	-	-
Valve System	-	-	4	4	-	-	4	-	2	2
