2015 Triumph Bonneville Newchurch Special Edition Specifications

Name: 2015 Triumph Bonneville Newchurch Special Edition
Brand: Triumph

No images available

Tap to enlarge

2015 Triumph Bonneville Newchurch Special Edition Overview

The 2015 Triumph Bonneville Newchurch Special Edition is a naked bike motorcycle built around 865 cc of displacement. Under the tank sits a Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, 360° firing interval engine, a compression ratio of 9.2:1. 2015 Triumph Bonneville Newchurch Special Edition delivers 50.7 kW @ 7500 rpm of peak power and 68 Nm @ 5800 rpm of torque. From a practical standpoint, the 2015 Bonneville Newchurch Special Edition tips the scales at 225 kg, carries a 16-litre fuel tank, offers a seat height of 740 mm and spans a 1490 mm wheelbase. Scroll down for the complete 2015 Triumph Bonneville Newchurch Special Edition spec sheet covering every technical detail from suspension travel to tyre sizes.

2015 Bonneville Newchurch Special Edition - Pros & Cons

Strengths

Strong power output: 2015 Triumph Bonneville Newchurch Special Edition makes 50.7 kW @ 7500 rpm with 68 Nm @ 5800 rpm of torque - competitive figures for its class.
Accessible seat height: At 740 mm, the seat height is approachable for a wide range of rider heights and builds confidence in low-speed manoeuvring.

Considerations

Age-related wear: As with any used Bonneville Newchurch Special Edition, a thorough pre-purchase inspection covering consumables, service history and tyres is always recommended.

Owner Experiences & Common Issues

Low-speed confidence

At 225 kg, the Bonneville Newchurch Special Edition is a substantial machine. New owners occasionally mention that slow-speed manoeuvring in car parks takes a little getting used to. Once moving, the weight disappears - but practising slow-speed exercises builds confidence quickly.

Bonneville Newchurch Special Edition - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2015 Triumph Bonneville Newchurch Special Edition, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained Bonneville Newchurch Special Edition should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any Bonneville Newchurch Special Edition. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

2015 Triumph Bonneville Newchurch Special Edition - Frequently Asked Questions

What engine does the 2015 Triumph Bonneville Newchurch Special Edition have?

The 2015 Triumph Bonneville Newchurch Special Edition uses a Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, 360° firing interval engine with 865 cc of displacement. It is air-cooled.

How much does the 2015 Triumph Bonneville Newchurch Special Edition weigh?

The 2015 Triumph Bonneville Newchurch Special Edition weighs 225 kg. This is the manufacturer's wet figure.

How much power does the 2015 Triumph Bonneville Newchurch Special Edition make?

The 2015 Triumph Bonneville Newchurch Special Edition produces 50.7 kW @ 7500 rpm of power and 68 Nm @ 5800 rpm of torque. These are peak figures.

What is the fuel tank capacity of the 2015 Triumph Bonneville Newchurch Special Edition?

The 2015 Triumph Bonneville Newchurch Special Edition has a 16-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 266-320 km between stops.

Is the 2015 Triumph Bonneville Newchurch Special Edition suitable for shorter riders?

The 2015 Triumph Bonneville Newchurch Special Edition has a seat height of 740 mm. This is a comfortable, accessible height for most riders.

What brakes does the 2015 Triumph Bonneville Newchurch Special Edition have?

The 2015 Triumph Bonneville Newchurch Special Edition uses Single 310 mm disc, Nissin 2 piston floating calipers at the front and Single 255 mm disc, Nissin 2 piston floating calipers at the rear.

What tyre sizes does the 2015 Triumph Bonneville Newchurch Special Edition use?

The 2015 Triumph Bonneville Newchurch Special Edition runs 110/70 R17 front and 130/80 R17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.

What gearbox does the 2015 Triumph Bonneville Newchurch Special Edition have?

The 2015 Triumph Bonneville Newchurch Special Edition is fitted with a 5 Speed transmission.

Key Specifications

Engine

Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, 360° firing interval

Power

50.7 kW / 68 hp @ 7500 rpm

Torque

68 Nm / 6.93 kgf-m / 50.2 ft-lb @ 5800 rpm

Top Speed

N/A

Weight

225 kg / 496 lbs

Fuel Capacity

16 Litres / 4.2 gal / 3.5 Imp gal

Full 2015 Triumph Bonneville Newchurch Special Edition Specifications

Year 2015

Colours Cranberry red/pure white, Sapphire blue/pure white with black detailing

Make Model Triumph Bonneville Newchurch Special Edition

Max Power 50.7 kW / 68 hp @ 7500 rpm

Max Torque 68 Nm / 6.93 kgf-m / 50.2 ft-lb @ 5800 rpm

Displacement 865 cc / 52.8 cub in.

Engine Detail Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, 360° firing interval

Bore x Stroke 90 x 68 mm

Compression Ratio 9.2:1

Cooling System Air-cooled

Engine Oil Specification Synthetic, 15W/50

Exhaust Stainless steel with twin chromed silencers, upswept

Fuel Consumption 4.2 L/100 km / 23.6 km/l / 55.6 US mpg /67.3 Imp mpg

Fuel Induction Multipoint Sequential Fuel injection with SAI

Ignition Digital

Lubrication Wet sump

Starter Electric
