Triumph Speed Triple Specs

2011 • 1 variants

The Triumph Speed Triple is a sport motorcycle produced from 2011 across 1 variant. It is powered by a four stroke, transverse three cylinder. dohc, 4 valves per cylinder. Peak power output is 131 hp. Peak torque is 105 Nm.

About the Triumph Speed Triple

The Triumph Speed Triple is a Sport motorcycle from Triumph, produced from 2005 to 2016. This page provides a comprehensive technical reference for the Triumph Speed Triple, covering all available specification data including engine configuration, displacement, power output, dimensions, weight, and chassis details. Use the year selector above to find specifications for a specific model year. All data is sourced from manufacturer specifications and is intended as a technical reference for riders, mechanics, and enthusiasts.

AdSense - 728Ã90

Triumph Speed Triple by Year

2011 Triumph Speed Triple View specs →

Spec Evolution

How key specs changed across production years.

Specification	2005	2006	2007	2008	2009	2010	2011	2012	2013	2014	2015	2016
Frame Type	Tubular, fabricated aluminum alloy, perimeter	Tubular, fabricated aluminum alloy, perimeter	Tubular, fabricated aluminum alloy, perimeter	Tubular, fabricated aluminum alloy, perimeter	Tubular, fabricated aluminum alloy, perimeter	Aluminium beam twin-spar, perimiter	Aluminium beam twin-spar	Aluminium beam twin-spar	Aluminium beam twin-spar	Aluminium beam twin-spar	Aluminium beam twin-spar, single sided swingarm, aluminium alloy	Aluminium beam twin-spar, single sided swingarm, aluminium alloy
Dry Weight	189 kg / 416.7 lbs	189 kg / 416.7 lbs	189 kg / 416.7 lbs	189 kg / 416.7 lbs	189 kg / 416.7 lbs	-	-	-	-	-	186 kg / 410 lbs	192 kg / 423 lbs ↑
Displacement	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.07 cu-in	1050 cc / 64.1 cub in	1050 cc / 64.1 cub in
Seat Height	815 mm / 32.1 in	815 mm / 32.1 in	815 mm / 32.1 in	815 mm / 32.1 in	815 mm / 32.1 in	828 mm / 32.6in ↑	828 mm / 32.6in	828 mm / 32.6in	828 mm / 32.6in	828 mm / 32.6in	825 mm / 32.5in ↓	825 mm / 32.5in
Brakes - Front	2 x 320 mm Discs, 4 piston calipers	2 x 320 mm Discs, 4 piston calipers	2 x 320 mm Discs, 4 piston calipers	2 x 320 mm Discs, 4 piston calipers	2 x 320 mm Discs, 4 piston calipers	2 x 320 mm Discs, 4 piston calipers, Brembo	2 x 320 mm Discs, 4 piston calipers, Brembo	2 x 320 mm Discs, 4 piston calipers, Brembo	2 x 320 mm Discs, 4 piston calipers, Brembo	2 x 320 mm Discs, 4 piston calipers, Brembo	2 x 320 mm floating discs, Brembo 4 piston monobloc radial calipers, ABS	2 x 320 mm floating discs, Brembo 4 piston monobloc radial calipers, switchable ABS
Wheelbase	1429 mm / 56.3 in	1429 mm / 56.3 in	1429 mm / 56.3 in	1429 mm / 56.3 in	1429 mm / 56.3 in	1435mm / 56.5in ↑	1435mm / 56.5in	1435mm / 56.5in	1435mm / 56.5in	1435mm / 56.5in	1435 mm / 56.5in	1435 mm / 56.5in
Brakes - Rear	Single 220 mm disc, 2 piston caliper	Single 220 mm disc, 2 piston caliper	Single 220 mm disc, 2 piston caliper	Single 220 mm disc, 2 piston caliper	Single 220 mm disc, 2 piston caliper	Single 255 mm disc, 2 piston caliper, Brembo ↑	Single 255 mm disc, 2 piston caliper, Nissen	Single 255 mm disc, 2 piston caliper, Nissen	Single 255 mm disc, 2 piston caliper, Nissen	Single 255 mm disc, 2 piston caliper, Nissen	Single 255 mm disc, Nissin 2 piston sliding caliper, ABS	Single 255 mm disc, Nissin 2 piston sliding caliper, switchable ABS
Fuel Capacity	18 Litres / 4.89 gal	18 Litres / 4.89 gal	18 Litres / 4.89 gal	18 Litres / 4.89 gal	18 Litres / 4.89 gal	17.5 Litres / 4.6 US gal / 3.8 Imp gal ↓	17.5 L / 4.6 US gal / 3.8 Imp gal	17.5 L / 4.6 US gal / 3.8 Imp gal	17.5 L / 4.6 US gal / 3.8 Imp gal	17.5 L / 4.6 US gal / 3.8 Imp gal	17.5 L / 4.6 US gal / 3.8 Imp gal	15.5 Litres / 4.1 US gal / 3.4 Imp gal ↓
Suspension - Front	45 mm Upside down forks with dual rate springs and adjustable preload, compression and rebound damping	45 mm Upside down forks with dual rate springs and adjustable preload, compression and rebound damping	45 mm Upside down forks with dual rate springs and adjustable preload, compression and rebound damping	45 mm Upside down forks with dual rate springs and adjustable preload, compression and rebound damping	45 mm Upside down forks with dual rate springs and adjustable preload, compression and rebound damping	Showa 43mm upside down forks ↓	Showa 43 mm upside down forks	Showa 43 mm upside down forks	Showa 43 mm upside down forks	Showa 43 mm upside down forks	Öhlins 43mm NIX30 upside down forks with adjustable rebound and compression damping	Showa 43mm upside down forks with adjustable rebound and compression damping
Suspension - Rear	Monoshock with adjustable preload, compression and rebound damping	Monoshock with adjustable preload, compression and rebound damping	Monoshock with adjustable preload, compression and rebound damping	Monoshock with adjustable preload, compression and rebound damping	Monoshock with adjustable preload, compression and rebound damping	Showa monoshock	Showa monoshock	Showa monoshock	Showa monoshock	Showa monoshock	Öhlins TTX36 twin tube Monoshock with rebound and compression damping	Single sided swingarm, Showa twin tube monoshock with rebound and compression damping
Top Speed	248.7 km/h / 154.5 in	248.7 km/h / 154.5 in	248.7 km/h / 154.5 in	248.7 km/h / 154.5 in	248.7 km/h / 154.5 in	226.8 km/h / 140.9 mph ↓	226.8 km/h / 140.9 mph	226.8 km/h / 140.9 mph	226.8 km/h / 140.9 mph	226.8 km/h / 140.9 mph	253.8 km/h / 157.7 mph ↑	-
Clutch	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate	Wet, multi-plate, slip assist
Final Drive	Chain	Chain	Chain	Chain	Chain	X ring chain	X ring chain	X ring chain	X ring chain	X ring chain	X ring chain	X ring chain
Height	1250 mm / 49.2 in	1250 mm / 49.2 in	1250 mm / 49.2 in	1250 mm / 49.2 in	1250 mm / 49.2 in	without mirrors 1110mm / 43.7 in ↓	without mirrors 1110mm / 43.7 in	without mirrors 1110mm / 43.7 in	without mirrors 1110mm / 43.7 in	without mirrors 1110mm / 43.7 in	1110 mm / 43.7 in (without mirrors)	1070 mm / 42.1 in (without mirrors) ↓
Length	2115 mm / 83.3 in	2115 mm / 83.3 in	2115 mm / 83.3 in	2115 mm / 83.3 in	2115 mm / 83.3 in	2100 mm / 82.6 in ↓	2100 mm / 82.6 in	2100 mm / 82.6 in	2100 mm / 82.6 in	2100 mm / 82.6 in	2100 mm / 82.6 in	-
Compression Ratio	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.0:1	12.25:1 ↑
Wet Weight	-	-	-	-	-	219 kg / 471lbs	214 kg / 472lbs ↓	214 kg / 472lbs	214 kg / 472lbs	214 kg / 472lbs	214 kg / 472 lbs	-
Tyres - Front	120/70 ZR17	120/70 ZR17	120/70 ZR17	120/70 ZR17	120/70 ZR17	120/70 ZR 17	120/70 ZR 17	120/70 ZR 17	120/70 ZR 17	120/70 ZR 17	120/70 ZR 17	120/70 ZR17
Width	780 mm / 30.7 in	780 mm / 30.7 in	780 mm / 30.7 in	780 mm / 30.7 in	780 mm / 30.7 in	(handlebars) 795 mm / 31.3 in ↑	(handlebars) 795 mm / 31.3 in	(handlebars) 795 mm / 31.3 in	(handlebars) 795 mm / 31.3 in	(handlebars) 795 mm / 31.3 in	795 mm / 31.3 in (handlebars)	780 mm / 30.7 in (handlebars) ↓
Tyres - Rear	190/50 ZR17	190/50 ZR17	190/50 ZR17	190/50 ZR17	190/50 ZR17	190/55 ZR 17	190/55 ZR 17	190/55 ZR 17	190/55 ZR 17	190/55 ZR 17	190/55 ZR 17	190/55 ZR17
Rake	24°	24°	24°	24°	24°	22.8° ↓	22.8°	22.8°	22.8°	22.8°	22.8°	22.9° ↑
Wheels - Front	-	-	-	-	-	Forged aluminium alloy, 5 spoke 17 x 3.5 in	Forged aluminium alloy 5 spoke, 17 x 3.5in	Forged aluminium alloy 5 spoke, 17 x 3.5in	Forged aluminium alloy 5 spoke, 17 x 3.5in	Forged aluminium alloy 5 spoke, 17 x 3.5in	Cast aluminium alloy multi spoke 17 x 3.5 in ↑	Cast aluminium alloy multi spoke 17 x 3.5 in
Wheels - Rear	-	-	-	-	-	Forged aluminium alloy 5 spoke, 17 x 6.0 in	Forged aluminium alloy 5 spoke, 17 x 6.0in	Forged aluminium alloy 5 spoke, 17 x 6.0in	Forged aluminium alloy 5 spoke, 17 x 6.0in	Forged aluminium alloy 5 spoke, 17 x 6.0in	Cast aluminium alloy multi spoke 17 x 6.0 in ↑	Cast aluminium alloy multi spoke 17 x 6.0 in
Fuel Consumption	-	-	-	-	-	5.2 L/100 km / 19.1 km/l / 44.9 US mpg / 54 Imp mpg	5.2 L/100 km / 19.1 km/l / 44.9 US mpg / 54 Imp mpg	5.2 L/100 km / 19.1 km/l / 44.9 US mpg / 54 Imp mpg	5.2 L/100 km / 19.1 km/l / 44.9 US mpg / 54 Imp mpg	5.2 L/100 km / 19.1 km/l / 44.9 US mpg / 54 Imp mpg	90 km/h / 56 mph: 4.7 L/100 km / 21.3 km/l / 50 US mpg / 60 Imp mpg ↑	5.4 L/100 km / 18.5 km/l / 43.6 US mpg / 52.3 Imp mpg ↓
Fuel Induction	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	Multipoint sequential electronic fuel injection	-	Multipoint sequential electronic fuel injection with SAI
Trail	84 mm / 3.3 in	84 mm / 3.3 in	84 mm / 3.3 in	84 mm / 3.3 in	84 mm / 3.3 in	90.9 mm / 3.6 in ↑	90.9 mm / 3.6 in	90.9 mm / 3.6 in	90.9 mm / 3.6 in	90.9 mm / 3.6 in	90.9 mm / 3.6 in	91.3 mm / 3.6 in ↑
Max Power	94.9 kW / 131 hp @ 9100 rpm	94.9 kW / 131 hp @ 9100 rpm	94.9 kW / 131 hp @ 9100 rpm	94.9 kW / 131 hp @ 9100 rpm	94.9 kW / 131 hp @ 9100 rpm	94.9 kW / 131 hp @ 9100 rpm	95 kW / 128 hp @ 9250 rpm ↑	95 kW / 128 hp @ 9250 rpm	95 kW / 128 hp @ 9250 rpm	95 kW / 128 hp @ 9250 rpm	99 kW / 135 hp @ 9400 rpm ↑	102.9 kW / 138 hp @ 9500 rpm ↑
Wheel Travel - Front	120 mm / 4.7	120 mm / 4.7	120 mm / 4.7	120 mm / 4.7	120 mm / 4.7	120 mm / 4.7 in	120 mm / 4.7 in	120 mm / 4.7 in	120 mm / 4.7 in	120 mm / 4.7 in	120 mm / 4.7 in	120 mm / 4.7 in
Wheel Travel - Rear	140 mm / 5.7 in	140 mm / 5.7 in	140 mm / 5.7 in	140 mm / 5.7 in	140 mm / 5.7 in	130 mm / 5.1 in ↓	130 mm / 5.1 in	130 mm / 5.1 in	130 mm / 5.1 in	130 mm / 5.1 in	130 mm / 5.1 in	130 mm / 5.1 in
Ignition	Digital inductive type	Digital inductive type	Digital inductive type	Digital inductive type	Digital inductive type	Digital°inductive type via electronic engine management system	Digital°inductive type via electronic engine management system	Digital°inductive type via electronic engine management system	Digital°inductive type via electronic engine management system	Digital°inductive type via electronic engine management system	Digital°inductive type via electronic engine management system	Digital°inductive type via electronic engine management system
Max Torque	105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm	105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm	105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm	105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm	105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm	105 Nm / 10.7 kgf-m / 78 ft-lb @ 5100 rpm	111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7500rpm ↑	111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7500rpm	111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7500rpm	111 Nm / 11.3 kgf-m / 82 ft.lbs @ 7500rpm	111Nm / 11.3 kgf-m / 82 ft.lbs @ 7750rpm	112 Nm / 11.4 kgf-m / 82.6 ft.lbs @ 7850rpm ↑
Standing Start ¼ Mile	11.8 sec	11.8 sec	11.8 sec	11.8 sec	11.8 sec	11.6 sec ↓	11.6 sec	11.6 sec	11.6 sec	11.6 sec	11.3 sec ↓	-
