Key Specifications
Engine
Single cylinder, four-stroke
Power
25.3 kW / 34 hp @ 7500 rpm
Torque
34.3 Nm / 25.8 lb-ft @ 6000 rpm
Top Speed
139.0 km/h / 86.4 mph
Fuel Capacity
12.80 litres / 3.38 US gallons
Advertisement
Full 2020 BMW C 400GT Specifications
Comments
Windscreen.
Comments
Windscreen.
Year
2019 - 20
Colours
Alpine White, Moonwalkgrey Metallic, Blackstorm Metallic
Colours
Alpine White, Moonwalkgrey Metallic, Blackstorm Metallic
Make Model
BMW C 400GT
Seat Height
775 mm / 30.5 in.
Seat Height
775 mm / 30.5 in
Wheelbase
1565 mm / 61.6 in.
Wheelbase
1564.5 mm / 61.6 in
Height
1305 mm / 51.4 in.
Height
1437 mm / 56.5 in
Length
2210 mm / 87.0 in.
Length
2210 mm / 87 in
Seat Height (Inner Leg Curve)
1760 mm / 69.3 in
Width
835 mm / 32.9 in.
Width
835 mm / 32.9 in
Dry Weight
203 kg / 450 lbs
Fuel Capacity
12.80 litres / 3.38 US gallons
Fuel Capacity
12.8 Litres / 3.4 US gal
Wet Weight
212.0 kg / 467.4 lbs
Wet Weight
212 kg / 467 lbs
Fuel Control
Overhead Cams (OHC)
Engine Type
Single cylinder, four-stroke
Displacement (ci)
21.36 cubic inches
Displacement (cc)
350.0 cc
CO2
81.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
80.0 x 69.6 mm
Bore x Stroke (in,)
3.1 x 2.7 inches
Fuel Control
Overhead Cams (OHC)
Engine Type
Single cylinder, four-stroke
CO2
81.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement
350 cc / 21.3 cub in
Engine Detail
Four stroke, Single cylinder, SOHC, 4 Valves, with rocker arm
Fuel System
Injection
Fuel System
Injection
Bore x Stroke
80 x 69.6 mm
Compression Ratio
11.5:1
Compression Ratio
11.5:1
Cooling System
Liquid cooled
Emissions
Closed-loop 3-way catalytic converter, emission standard EU-4
Emissions
Closed-loop 3-way catalytic converter, emission standard EU-4
Engine Lubrication
Wet sump
Engine Lubrication
Wet sump
Exhaust
Stainless Steel
Exhaust
Stainless Steel
Fuel Consumption
3.50 litres/100 km (28.6 km/l or 67.21 mpg)
Fuel Consumption
3.50 litres/100 km (28.6 km/l or 67.21 mpg)
Fuel Induction
Fuel injection, BMS-E2 40mm throttle valve diameter
Fuel Reserve
4.00 litres / 1.06 US gallons
Fuel Reserve
4.00 litres / 1.06 US gallons
Fuel Type
Unleaded super 95 (ROZ), E10 compatible
Ignition
BMS-E2 digital engine management
Ignition
BMS-E2 digital engine management
Starter
Electric, 500 kW
Starter
Electric
Valve System
4
Valve System
4
Battery Capacity
12 V / 9 Ah, maintenance-free
Clutch
Centrifugal dry clutch
Clutch
Centrifugal dry clutch
Final Drive
Chain (final drive)
Final Drive
Chain (final drive)
Gearbox
Automatic
Gearbox
Automatic
Primary Drive
Chain drive in oil bath
Primary Drive
Chain drive in oil bath
Secondary Drive
Two step spur gearing
Transmission / Drive
Stepless CVT gearbox
Frame Type
Steel tube construction with aluminum die cast unit
Frame Type
Steel tube construction with aluminum die cast unit and #8232;
Suspension - Front
35mm Telescopic forks.
Suspension - Front
Telescopic front fork, Ø 35 mm
Suspension - Rear
Double aluminum swingarm, double springs struts, adjustable preload
Suspension - Rear
Double Aluminum swingarm, Double spring struts, adjustable preload
Rake
26.4°
Rake
26.4°
Steering Head Angle
63,6°
Trail
81 mm / 3.2 in.
Trail
81.2 mm / 3.2 in
Wheel Travel - Front
110 mm / 4.3 in
Wheel Travel - Front
110 mm / 4.3 in.
Wheel Travel - Rear
112 mm / 4.4 in
Wheel Travel - Rear
112 mm / 4.4 in.
Alternator
Three-phase generator 316 W
Lighting system
LED headlights
Lighting system
LED headlights
Brakes - Front
Double disc. 4-piston calipers. ABS.
Brakes - Front
2x 265mm Rigid discs 4 piston caliper
Brakes - Rear
Single disc. 1-piston calipers. ABS.
Brakes - Rear
Single 265mm disc 1 piston caliper
ABS
BMW Motorrad ABS
Rims
Cast aluminum
Rims
Cast aluminum
Rims - Front
3.50 x 15
Rims - Rear
4.25 x 14
Tyres - Front
120/70-ZR15
Tyres - Front
120/70 ZR15
Tyres - Rear
150/70 ZR14
Wheels
Aluminum cast wheels
