Key Specifications
Engine
Single cylinder, four-stroke
Power
25.3 kW / 34 hp @ 7500 rpm
Torque
35.0 Nm (3.6 kgf-m or 25.8 ft.lbs) @ 6000 Revolutions"
Top Speed
139.0 km/h / 86.4 mph
Fuel Capacity
12.8 Litres / 3.4 US gal
Advertisement
Full 2019 BMW C 400X Specifications
Comments
Windscreen.
Year
2018 - 19
Colours
Alpine White, Zenith Blue Metallic, Black Storm Metallic
Make Model
BMW C 400X
Seat Height
775 mm / 30.5 in.
Seat Height
775 mm / 30.5 in
Wheelbase
1565 mm / 61.6 in.
Wheelbase
1564.5 mm / 61.6 in
Height
1305 mm / 51.4 in.
Length
2210 mm / 87 in
Length
2210 mm / 87.0 in.
Seat Height (Inner Leg Curve)
1760 mm / 69.3 in
Width
833 mm / 32.8 in
Width
835 mm / 32.9 in.
Dry Weight
193 kg / 425.5 lbs
Fuel Capacity
12.8 Litres / 3.4 US gal
Fuel Capacity
12.80 litres / 3.38 US gallons
Wet Weight
204.0 kg / 449.7 lbs
Wet Weight
204 kg / 450 lbs
Bore x Stroke (mm)
80.0 x 69.5 mm
Bore x Stroke (in,)
3.1 x 2.7 inches
CO2
81.2 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement (cc)
350.0 cc
Displacement (ci)
21.36 cubic inches
Engine Type
Single cylinder, four-stroke
Fuel Control
Overhead Cams (OHC)
Displacement
350 cc / 21.3 cu-in
Engine Detail
Four stroke, single cylinder, SOHC, 4 Valves, with rocker arm
Fuel System
Injection
Bore x Stroke
80 x 69.6 mm
Compression Ratio
11.5:1
Compression Ratio
11.5:1
Cooling System
Liquid cooled
Emissions
Closed-loop 3-way catalytic converter, emission standard EU-4
Engine Lubrication
Wet sump
Exhaust
Stainless Steel
Fuel Consumption
3.50 litres/100 km (28.6 km/l or 67.21 mpg)
Fuel Induction
Fuel injection, BMS-E2 40mm throttle valve diameter
Fuel Reserve
4.00 litres / 1.06 US gallons
Fuel Type
Regular lead free (95 RON)
Ignition
BMS-E2 digital engine management
Starter
Electric
Starter
Electric, 500 kW
Valve System
4
Battery Capacity
12/9 V/Ah
Clutch
Centrifugal dry clutch
Clutch
Centrifugal clutch
Final Drive
Gear reduction cog wheel pairing
Final Drive
Chain (final drive)
Gearbox
Automatic
Primary Drive
Chain drive in oil bath
Transmission / Drive
Continuously variable CVT belt transmission
Frame Type
Tubular spaceframe
Frame Type
Steel tube construction with aluminum die cast unit and #8232;
Suspension - Front
Telescopic front fork, Ø 35 mm
Suspension - Front
35mm Telescopic forks.
Suspension - Rear
Aluminum double-sided swing arm, double spring strut, adjustable spring preload
Suspension - Rear
Double aluminum swingarm, double springs struts, adjustable preload
Rake
26.4°
Rake
26.4°
Trail
81 mm / 3.2 in.
Trail
81.2 mm / 3.2 in
Wheel Travel - Front
110 mm / 4.3 in
Wheel Travel - Front
110 mm / 4.3 in.
Wheel Travel - Rear
112 mm / 4.4 in
Wheel Travel - Rear
112 mm / 4.4 in.
Alternator
316W
Lighting system
LED headlights
Brakes - Front
2x 265mm Rigid discs 4 piston caliper.
Brakes - Front
Single disc. 4-piston calipers. ABS.
Brakes - Rear
Single 265mm disc 1 piston caliper.
Brakes - Rear
Single disc. 1-piston calipers. ABS.
ABS
BMW Motorrad ABS
Rims
Cast aluminum
Rims - Front
3.50 x 15
Rims - Rear
4.25 x 14
Tyres - Front
120/70-ZR15
Tyres - Front
120/70 ZR15
Tyres - Rear
150/70 ZR14
Wheels
Die-cast aluminum wheels
