Key Specifications
Power
37.3 kW / 50 hp @ 6800 rpm
Torque
60 Nm / 6.12 kgf-m / 44.25 lb-ft. @ 5200 rpm
Top Speed
183.4 km/h / 114 mph
Weight
191 kg / 421.1 lbs.
Fuel Capacity
17.3 Litres / 4.6 US gal.
Advertisement
Full 2007 BMW F 650GS Specifications
Year
2007
Colours
Red Non-Metallic, Night Black, Iceberg Silver Metallic
Make Model
BMW F 650GS
Seat Height
780 mm / 30.7 in.
Wheelbase
1479 mm / 58.2 in.
Height
1265 mm / 49.8 in.
Length
2175 mm / 85.6 in.
Width
910 mm / 35.8 in.
Dry Weight
176 kg / 388 lbs.
Fuel Capacity
17.3 Litres / 4.6 US gal.
Wet Weight
191 kg / 421.1 lbs.
Stroke
4
Engine Type
Single cylinder
Displacement
652 cc / 39.8 cub. in.
Engine Detail
Four stroke, single cylinder, DOHC, 4 valves per cylinder
Fuel System
Injection. Electronic fuel injection
Bore x Stroke
100 x 83mm
Compression Ratio
11.5:1
Cooling System
Liquid cooled
Fuel Consumption
4.7 l/100 km / 60.5 US mpg
Fuel Induction
Fuel induction
Fuel Range
370.2 kms / 230 miles
Fuel Reserve
Approx. 4.5 Litres / 1.2 US gal.
Ignition
Capacitor Discharge Ignition system
Lubrication
Dry sump
Starter
Electric
Valve System
4
Battery Capacity
12V / 12Ah
Clutch
Multiple-disc clutch in oil bath, mechanically operated
Final Drive
Chain
Gear Ratios
1st 2.75 / 2nd 1.75 / 3rd 1.31 / 4th 1.05 / 5th 0.88:1
Gearbox
5-speed
Transmission / Drive
5 Speed
Frame Type
Bridge-type steel section frame with bolted-on rear section
Suspension - Front
41mm Telescopic fork with stabilizer bridge
Suspension - Rear
Spring setting and rebound stage damping continuously adjustable
Steering Head Angle
60.8°
Trail
123 mm / 4.8 in.
Wheel Travel - Front
170 mm / 6.6 in
Wheel Travel - Rear
165 mm / 6.4 in
Alternator
Three-phase alternator 400W
Brakes - Front Diameter (in.)
11.8 inches
Brakes - Front Diameter (mm)
300 mm
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Rear Diameter (mm)
240 mm
Brakes - Front
Single ∅300mm disc, 2 piston caliper
Brakes - Rear
Single ∅240mm disc, 1 piston caliper
Tyres - Front
100/90-19
Tyres - Rear
130/80-17
Wheels
Wire spoke wheels
Wheels - Front
2.50 x 19
Wheels - Rear
3.00 x 17
