Key Specifications
Engine
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Power
62.5 kW / 85 hp @ 7500 rpm
Torque
80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm
Top Speed
199.0 km/h / 124 mph
Fuel Capacity
24 Litres / 6.3 US gal.
Advertisement
Full 2013 BMW F 800GS Adventure Specifications
Year
2013
Make Model
BMW F 800GS Adventure
Seat Height
890 mm / 860 mm / 35 in. / 33.9 in.
Wheelbase
1577 mm / 62.1 in
Height
1450 mm / 57.1 in (excl. mirrors)
Length
2304 mm / 90.7 in
Width
925 mm / 36.4 in (incl. mirrors)
Dry Weight
214 kg / 472 lbs
Fuel Capacity
24 Litres / 6.3 US gal.
Max Load
496 lbs.
Wet Weight
229 kg / 505 lbs
Displacement
798 cc / 47.7 cub. in.
Engine Detail
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Bore x Stroke
82 x 75.8 mm
Compression Ratio
12.0:1
Cooling System
Liquid cooled
Fuel Consumption
4.3 L/100km / 23.3 km/l / 55 mpg
Fuel Induction
Electronic intake injection, ∅45mm throttle bodies
Ignition
Digital CDI
Lubrication
Dry sump
Starter
Electric
Clutch
Multiplate-plate in oil bath
Final Drive
Chain
Final Drive Ratio
1:2.6
Gear Ratios
1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96
Transmission / Drive
6 Speed
Frame Type
Tubular frame in steal partly carrying the engine
Suspension - Front
43mm Marzocchi upside down forks
Suspension - Rear
Double strut swing arm aluminium coast in one piece
Fork Angle
64°
Rake
26°
Trail
117 mm / 4.6 in.
Wheel Travel - Front
230 mm / 9.1 in.
Wheel Travel - Rear
215 mm / 8.5 in.
Equipment / Features
35.0 in
Brakes - Front
2 x ∅300mm discs, 4 piston calipers, ABS
Brakes - Rear
Single ∅265mm disc, 2 piston caliper, ABS
Tyres - Front
90/90 - 21 54V
Tyres - Rear
150/70 - 17 69V
Wheels
spoke
Wheels - Front
2.15 x 21"
Wheels - Rear
4.25 x 17"
