Key Specifications
Torque
143.0 Nm (14.6 kgf-m or 105.5 ft.lbs) @ 6250 Revolutions">RPM
Fuel Capacity
18.17 litres
Advertisement
Full 2022 BMW R 1250R Specifications
Comments
2 Ride Modes (Rain/Road). Automatic Stability Control.
Colours
Black Storm Metallic, Blue/Red/White, Mineral Gray
Warranty
3-years or 36,000 miles
Width (mm)
880 mm
Width (in.)
34.6 inches
Wheelbase (mm)
1515 mm
Wheelbase (in.)
59.6 inches
Storage
Saddle bags
Seat Height (mm)
820 mm
Seat Height (in.)
32.3 inches
Length (mm)
2165 mm
Length (in.)
85.2 inches
Height (mm)
1300 mm
Height (in.)
51.2 inches
Wet Weight (lbs.)
526.9 pounds
Wet Weight (kg)
239.0 kg
Oil Capacity (Quarts)
4.23 US quarts
Oil Capacity (l)
4.00 litres
Fuel Capacity (l)
18.17 litres
Fuel Capacity (gal.)
4.80 US gallons
Coolant Capacity
2.00 litres (0.53 US gallons)
Fuel Reserve (l)
4.00 litres
Fuel Reserve (gal.)
1.06 US gallons
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
Twin, four-stroke
Displacement (ci)
76.52 cubic inches
Displacement (cc)
1254.0 cc
CO2
109.0 CO2 g/km. (CO2 - Carbon dioxide emission)
Bore x Stroke (mm)
102.5 x 76.0 mm
Bore x Stroke (in,)
4.0 x 3.0 inches
Engine Detail
One balance shaft and variable engine timing system
Fuel System
Injection. Electronic fuel injection with ride-by-wire throttle system
Compression Ratio
12.5:1
Emissions
Euro 4. Closed-loop 3-way catalytic converter.
Engine Lubrication
Wet sump
Fuel Consumption
4.70 litres/100 km (21.3 km/l or 50.05 mpg)
Idle Speed
1050 +/- 100 RPM
Starter
Electric
Valve System
4
Clutch
Oil lubricated clutch, hydraulically operated
Final Drive
Shaft drive (cardan) (final drive)
Gearbox
6-speed
Trail (in.)
4.9 inches
Trail (mm)
126 mm
Wheel Travel - Front (in.)
5.5 inches
Wheel Travel - Front (mm)
140 mm
Wheel Travel - Rear (in.)
5.5 inches
Wheel Travel - Rear (mm)
140 mm
Frame Type
Two section frame, front - and bolted on rear frame, load bearing engine
Suspension - Front
Upside-down telescopic fork, Ø 45 mm
Suspension - Rear
Cast aluminum single-sided swing arm with BMW Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable
Rake
27.7°
Instrumentation
TFT-Display with connectivity
Brakes - Front
Double disc. ABS, 4-piston radial calipers
Brakes - Rear
Single disc. ABS, dual-piston floating caliper
Brake Fluid Type
DOT 4
Tyre Pressure - Front
36 PSI (2.5 Bar or 250 kPa)
Tyre Pressure - Rear
42 PSI (2.9 Bar or 290 kPa)
Tyres - Front
120/70-ZR17
