Key Specifications
Power
143 kW / 195 hp @ 10750rpm
Top Speed
292 km/h / 181 mph
Weight
164 kg / 361.5 lbs
Fuel Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Advertisement
Full 2012 Ducati 1199S Panigale Specifications
Make Model
Ducati 1199S Panigale
Make Model
Ducati 1199S Panigale
Seat Height
824 mm / 32.4 in
Seat Height
824 mm / 32.4 in
Wheelbase
1437 mm / 56.6 in
Wheelbase
1437 mm / 56.6 in
Height
1100 mm / 43.31in
Height
1100 mm / 43.31in
Length
2075 mm / 81.69 in
Length
2075 mm / 81.69 in
Dry Weight (kg)
164
Dry Weight (kg)
164
Dry Weight
164 kg / 361.5 lbs
Dry Weight
164 kg / 361.5 lbs
Fuel Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Fuel Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Compression Ratio
12.5:1
Compression Ratio
12.5:1
Cooling System
Liquid cooled
Exhaust
2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum outer sleeves
Exhaust
2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum outer sleeves
Fuel Consumption
5.95 L/100 km / 16.8 km/l / 39.5 US mpg / 47.5 Imp mpg
Fuel Consumption
5.95 L/100 km / 16.8 km/l / 39.5 US mpg / 47.5 Imp mpg
Fuel Induction
Mitsubishi EFI, Full ride-by-wire elliptical throttle bodies
Fuel Induction
Mitsubishi EFI, Full ride-by-wire elliptical throttle bodies
Ignition
Digital CDI
Ignition
Digital CDI
Lubrication
Wet sump
Starter
Electric
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Final Drive
Chain 525; front sprocket 15; rear sprocket 39
Final Drive
Chain 525; front sprocket 15; rear sprocket 39
Gear Ratios
1st 37/15, 2nd 30/16, 3rd 27/18, 4th 25/20, 5th 24/22, 6th 23/24
Gear Ratios
1st 37/15, 2nd 30/16, 3rd 27/18, 4th 25/20, 5th 24/22, 6th 23/24
Transmission / Drive
6 Speed
Transmission / Drive
6 Speed
Frame Type
Monocoque aluminum
Frame Type
Monocoque aluminum
Suspension - Rear
Fully adjustable Öhlins TTX36 unit. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm
Suspension - Rear
Fully adjustable Öhlins TTX36 unit. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm
Rake
24.5°
Rake
24.5°
Trail
100 mm / 3.9 in
Trail
100 mm / 3.9 in
Wheel Travel - Front
120 mm / 4.72 in
Wheel Travel - Front
120 mm / 4.72 in
Wheel Travel - Rear
130mm / 5.12in
Brakes - Front
2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc M50 4-piston callipers, ABS optional +2.5kg (+5.5lb)
Brakes - Rear
Single 245 mm disc, 2 piston caliper
Brakes - Rear
Single 245 mm disc, 2 piston caliper
Tyres - Front
120/70 ZR17 Pirelli Diablo Supercorsa SP
Tyres - Front
120/70 ZR17 Pirelli Diablo Supercorsa SP
Tyres - Rear
200/55 ZR14 Pirelli Diablo Supercorsa SP
Tyres - Rear
200/55 ZR14 Pirelli Diablo Supercorsa SP
