Key Specifications
Torque
124.00 Nm (12.6 kgf-m or 91.5 ft.lbs) @ 7750 Revolutions
Weight
211.0 kg / 465.2 lbs
Fuel Capacity
16.50 litres / 4.36 gallons
Advertisement
Full 2018 Ducati Monster 1200 S Specifications
Colours
Red, black
Warranty
2 years unlimited mileage
Seat Heigth -Alternate (mm)
810 mm
Seat Heigth -Alternate (in.)
31.9 inches
Seat Height
785 mm / 30.9 in.
Wheelbase
1,511 mm / 59.5 in.
Height
1,040 mm / 40.9 in.
Length
2,200 mm / 86.6 in.
Width
830 mm / 32.7 in.
Dry Weight
185 kg / 407.9 lbs
Fuel Capacity
16.50 litres / 4.36 gallons
Wet Weight
211.0 kg / 465.2 lbs
Bore x Stroke (in,)
4.2 x 2.7 inches
Bore x Stroke (mm)
106.0 x 67.9 mm
CO2
120.6 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement (cc)
1198.40 cc
Displacement (ci)
73.13 cubic inches
Engine Type
V2, four-stroke
Fuel Control
Desmodromic valve control
Fuel System
Injection. 53mm throttle bodies with full Ride by Wire
Compression Ratio
12.5:1
Emissions
Euro 4
Exhaust
Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers
Fuel Consumption
5.20 litres/100 km (19.2 km/l or 45.23 mpg)
Starter
Electric
Valve System
4
Clutch
Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Final Drive
Chain
Gearbox
6-speed
Frame Type
Tubular steel Trellis frame attached to the cylinders head
Suspension - Front
Ohlins fully adjustable usd fork
Suspension - Rear
Progressive linkage with Ohlins monoshock, preload and rebound adjustable, Aluminium single-sided swingarm
Rake
23.3°
Seat
Dual seat
Trail
93 mm / 3.7 in.
Wheel Travel - Front
130 mm / 5.1 in.
Wheel Travel - Rear
149 mm / 5.9 in.
Instrumentation
Colour TFT display
Brakes - Front Diameter (in.)
12.6 inches
Brakes - Front Diameter (mm)
320 mm
Brakes - Rear Diameter (in.)
9.6 inches
Brakes - Rear Diameter (mm)
245 mm
Brakes - Front
Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted.
Brakes - Rear
Single disc. ABS. Floating disc. Two-piston calipers.
Rims
Y-shaped 3-spoke in light alloy
Tyres - Front
120/70-ZR17
Tyres - Rear
190/55-ZR17
