Key Specifications
Engine
Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Advertisement
Full 2009 Ducati Streetfighter Specifications
Year
2009
Make Model
Ducati Streetfighter
Seat Height
840 mm / 33 in
Wheelbase
1475 mm / 58.1 in
Height
1114 mm / 43.8 in
Length
2102 mm / 82.7 in
Width
775 mm / 30.5 in
Dry Weight
169 kg / 373 lbs
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Wet Weight
197 kg / 434 lbs
Displacement
1099 cc / 67.1 cu in
Engine Detail
Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valves per cylinder
Bore x Stroke
104 x 64.7 mm
Compression Ratio
12.4:1
Cooling System
Liquid cooled
Exhaust
Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin stainless steel mufflers
Fuel Induction
Marelli electronic fuel injection, elliptical throttle bodies
Ignition
Digital CDI
Lubrication
Wet sump
Starter
Electric
Clutch
Dry multiplate with hydraulic control
Final Drive
Chain
Transmission / Drive
6 Speed
Frame Type
Tubular steel trellis frame
Suspension - Rear
Progressive linkage with fully adjustable Showa monoshock. Aluminium single-sided swingarm
Rake
26°
Trail
114 mm / 4.4 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
127 mm / 5.0 in
Brakes - Front
2x 330 mm Semi-floating discs, radially mounted Brembo Monobloc calipers 4-piston, 2-pad.
Brakes - Rear
Single 245 mm disc, 2 piston caliper
Tyres - Front
120/70 - ZR17
Tyres - Rear
190/55 - ZR17
Wheels - Front
5-Spoke forged light alloy, 3.50 x 17
Wheels - Rear
5-Spoke forged light alloy, 6.00 x 17
