Key Specifications
Torque
117.97 Nm (12.0 kgf-m or 87.0 ft.lbs) @ 6750
Top Speed
45.0 km/h / 28.0 mph
Weight
307.1 kg / 677.0 lbs
Fuel Capacity
18.93 litres / 5.00 gallons
Advertisement
Full 2014 Harley-Davidson V-Rod Muscle Specifications
Comments
Lithium Iron Phosphate 48V/20Ah battery, 16.8 kg. Range 60 km. Recharging time: 4 hours. Made in Taiwan.
Colours
White Hot Denim, Charcoal Pearl, Amber Whiskey, Vivid Black
Ground Clearance (mm)
122 mm
Ground Clearance (in.)
4.8 inches
Seat Height
650 mm / 25.6 in.
Wheelbase
1,702 mm / 67.0 in.
Height
1,005 mm / 39.6 in.
Length
2,357 mm / 92.8 in.
Width
625 mm / 24.6 in.
Oil Capacity (Quarts)
0.31 quarts
Oil Capacity (l)
4.70 litres
Dry Weight
292.1 kg / 644.0 lbs
Fuel Capacity
18.93 litres / 5.00 gallons
Wet Weight
307.1 kg / 677.0 lbs
Engine Type
V2, four-stroke
Displacement (ci)
76.28 cubic inches
Displacement (cc)
1250.08 cc
CO2
147.6 CO
Bore x Stroke (in,)
4.1 x 2.8 inches
Bore x Stroke (mm)
105.0 x 72.0 mm
Engine Detail
Liquid-cooled, Revolution®, 60° V-Twin
Fuel System
Injection. Electronic Sequential Port Fuel Injection
Compression Ratio
11.5:1
Emissions
Zero emission
Engine Lubrication
Dry sump
Exhaust
Satin chrome, dual side exhaust system with turnouts
Fuel Consumption
6.36 litres/100 km (15.7 km/l or 36.98 mpg)
Starter
Electric
Clutch
Multi-plate with diaphragm spring in oil bath
Final Drive
Belt
Gearbox
6-speed
Primary Drive
Gear, 117/64 ratio primary drive
Frame Type
Steel tube
Suspension - Front
Dual Hydraulic Shock Absorber
Suspension - Rear
Single Hydraulic Shock Absorber
Rake
34.0°
Trail
142 mm / 5.6 in.
Instrumentation
Electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, tachometer
Lighting system
High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), coolant temperature, low fuel warnings
Brakes - Front
Single disc. 4-piston
Brakes - Rear
Single disc. 2-piston
Rims
Black, 5-Spoke Cast Aluminum
Tyres - Front
80/100-10
Tyres - Front
MT90-ZR19
Tyres - Rear
80/100-10
Tyres - Rear
MU85-R18
