Key Specifications
Engine
In-line four, four-stroke
Torque
97.00 Nm (9.9 kgf-m or 71.5 ft.lbs) @ 6500
Weight
250.0 kg / 551.2 lbs
Fuel Capacity
19.00 litres / 5.02 gallons
Advertisement
Full 2012 Honda CBF 1000 Specifications
Comments
French brand.
Colours
Red, silver, black, white
Ground Clearance (mm)
135 mm
Ground Clearance (in.)
5.3 inches
Seat Height
795 mm / 31.3 in.
Wheelbase
1,483 mm / 58.4 in.
Height
1,175 mm / 46.3 in.
Length
2,176 mm / 85.7 in.
Width
685 mm / 27.0 in.
Dry Weight
88 kg / 194.0 lbs
Fuel Capacity
19.00 litres / 5.02 gallons
Wet Weight
250.0 kg / 551.2 lbs
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement (ci)
60.90 cubic inches
Bore x Stroke (in,)
3.0 x 2.2 inches
Bore x Stroke (mm)
75.0 x 56.5 mm
Displacement (cc)
998.00 cc
Fuel System
Injection. PGM-FI
Fuel Reserve
4.00 litres / 1.06 gallons
Ignition
Computer-controlled digital transistorised with electronic advance
Starter
Electric
Valve System
4
Final Drive
Chain
Gearbox
6-speed
Primary Drive
#530 O-ring sealed chain
Suspension - Front
41 mm cartridge-type telescopic fork
Suspension - Rear
Pro-Link with gas-charges HMAS damper
Seat
Dual
Wheel Travel - Front
120 mm / 4.7 in.
Wheel Travel - Rear
120 mm / 4.7 in.
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Rear Diameter (mm)
240 mm
Brakes - Front Diameter (mm)
296 mm
Brakes - Front Diameter (in.)
11.7 inches
Brakes - Front
Double disc. 2-piston caliper, sintered metal pads and Combined ABS
Brakes - Rear
Single disc. 1-piston caliper, sintered metal pads and Combined ABS
Rims
Hollow-section 6-spoke cast aluminium
Tyres - Front
120/70-ZR17
Tyres - Rear
160/60-ZR17
