Key Specifications
Engine
Single cylinder, four-stroke
Weight
122.0 kg / 269.0 lbs
Fuel Capacity
3.00 litres / 0.79 gallons
Advertisement
Full 2014 Honda CRF50F Specifications
Comments
Model ID: CRF450X
Colours
Red/white
Ground Clearance (mm)
147 mm
Ground Clearance (in.)
5.8 inches
Seat Height
549 mm / 21.6 in.
Wheelbase
914 mm / 36.0 in.
Dry Weight
47 kg / 103.6 lbs
Fuel Capacity
3.00 litres / 0.79 gallons
Wet Weight
122.0 kg / 269.0 lbs
Fuel Control
SOHC
Engine Type
Single cylinder, four-stroke
Displacement (ci)
2.99 cubic inches
Displacement (cc)
49.00 cc
Bore x Stroke (mm)
39.0 x 41.4 mm
Bore x Stroke (in,)
1.5 x 1.6 inches
Fuel System
Carburettor. 13mm piston-valve carburator
Compression Ratio
10.0:1
Emissions
Meets current CARB and EPA standards.
Fuel Reserve
0.80 litres / 0.21 gallons
Ignition
CD
Starter
Kick
Clutch
Automatic
Final Drive
Chain
Gearbox
3-speed
Primary Drive
#520 T-ring-sealed chain; 13T/51T
Suspension - Front
21.7mm inverted telescopic fork
Suspension - Rear
Monoshock with cantilever-type swingarm
Rake
25.0°
Trail
110 mm / 4.3 in.
Wheel Travel - Front
90 mm / 12.4 in.
Wheel Travel - Front
315 mm / 12.4 in.
Wheel Travel - Front
90 mm / 3.5 in.
Wheel Travel - Front
315 mm / 3.5 in.
Wheel Travel - Rear
312 mm / 12.3 in.
Brakes - Front Diameter (in.)
9.4 inches
Brakes - Front Diameter (mm)
240 mm
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Rear Diameter (mm)
240 mm
Brakes - Front
Expanding brake (drum brake)
Brakes - Rear
Expanding brake (drum brake)
Rims
Wire spoke
Tyres - Front
2.50-10
Tyres - Rear
2.50-10
Tyres - Rear
110/100-18
