Honda VT750S Specs
2012 - 2013
• 2 variants
The Honda VT750S is a cruiser produced from 2012 to 2013 across 2 variants. It is powered by a 53 degree v-twin displacing 745.00 cc. Peak torque is 62 Nm.
About the Honda VT750S
The VT750S represents Honda's contribution to the All-Round motorcycle segment, spanning the 2011 to 2016 production run. Our database contains detailed technical specifications for each model year, covering powertrain details, chassis geometry, suspension and braking systems, fuel capacity, and certified weight figures. Use the year navigation above to drill into year-specific data. All specifications are referenced from official Honda documentation.
Honda VT750S by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2011
|
2012
|
2013
|
2016
|
|
Bore x Stroke (in,)
|
3.1 x 3.0 inches | 3.1 x 3.0 inches | 3.1 x 3.0 inches | 3.1 x 3.1 inches |
|
Bore x Stroke (mm)
|
79.0 x 76.0 mm | 79.0 x 76.0 mm | 79.0 x 76.0 mm | 79.0 x 79.0 mm |
|
Fuel Control
|
SOHC | SOHC | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) |
|
Comments
|
Model ID: TRX90X | - | Sold in Australia. | - |
|
Frame Type
|
- | - | Steel | Steel-tube backbone |
|
Brakes - Front
|
Single disc | Single disc. Hydraulic disc with dual-piston caliper and sintered metal pads | Single disc. Hydraulic disc with dual-piston caliper and sintered metal pads | Single disc. Twin-piston hydraulic calliper |
|
Wheelbase
|
1,560 mm / 61.4 in. | 1,560 mm / 61.4 in. | 1,560 mm / 61.4 in. | 1,640 mm / 64.6 in. ↑ |
|
Engine Detail
|
- | 53 degree V-twin | 53 degree V-twin | 52° V-twin ↓ |
|
Suspension - Front
|
41mm telescopic fork, 118mm axle travel | 41mm telescopic fork | 41mm telescopic fork | 41mm telescopic fork |
|
Suspension - Rear
|
Dual conventional dampers with 5-step adjustable spring preload, 90mm axle travel | Dual conventional dampers with 5-step adjustable spring preload | Dual conventional dampers with 5-step adjustable spring preload | Dual shocks with five-position spring pre-load adjustability |
|
Fuel System
|
Injection. PGM-FI electronic fuel injection with automatic choke | Injection. PGM-FI with automatic choke | Injection. PGM-FI with automatic choke? | Injection |
|
Colours
|
Red, White | Black, blue/white | Black, blue/white | White |
|
Clutch
|
Automatic | Electronic Dual Clutch | - | - |
|
Final Drive
|
Chain | Chain | Chain | Shaft drive (cardan) |
|
Wet Weight
|
118.8 kg / 262.0 lbs | 277.0 kg / 610.7 lbs ↑ | - | 232.0 kg / 511.5 lbs |
|
Tyres - Front
|
100/90-M19 | 100/90-M19 | 100/90-19 | 100/90-19 |
|
Tyres - Rear
|
150/80-B16 | 150/80-B16 | 150/80-16 | 150/80-16 |
|
Primary Drive
|
O-ring sealed chain | O-ring sealed chain | O-ring sealed chain | Enclosed shaft |
|
Wheel Travel - Front
|
66 mm / 2.6 in. | 118 mm / 4.6 in. ↑ | 118 mm / 4.6 in. | 118 mm / 4.6 in. |
|
Wheel Travel - Rear
|
66 mm / 2.6 in. | 130 mm / 5.1 in. ↑ | 90 mm / 3.5 in. ↓ | 90 mm / 3.5 in. |
|
Ignition
|
CDI | Digital transistorized with electronic advance | - | Digital transistorised with electronic advance |
|
Max Torque
|
62.00 Nm (6.3 kgf-m or 45.7 ft.lbs) @ 3250 | 62.00 Nm (6.3 kgf-m or 45.7 ft.lbs) @ 3250 | 62.00 Nm (6.3 kgf-m or 45.7 ft.lbs) @ 3250 Revolutions | 65.00 Nm (6.6 kgf-m or 47.9 ft.lbs) @ 3500 Revolutions ↑ |
