Full Specifications
General
Colours
White/blue/yellow
Warranty
2 Years
Dimensions
Ground Clearance (in.)
11.0 inches
Ground Clearance (mm)
280 mm
Seat Height (in.)
29.5 inches
Seat Height (mm)
750 mm
Wheelbase (in.)
44.8 inches
Wheelbase (mm)
1,137 mm
Weights & Capacities
Dry Weight (kg)
53.0 kg
Dry Weight (lbs.)
116.8 pounds
Fuel Capacity (gal.)
0.92 gallons
Fuel Capacity (l)
3.50 litres
Oil Capacity (l)
0.90 litres
Oil Capacity (Quarts)
0.06 quarts
Engine
Bore x Stroke (in,)
1.8 x 1.6 inches
Bore x Stroke (mm)
45.0 x 40.8 mm
Displacement (cc)
64.90 cc
Displacement (ci)
3.96 cubic inches
Engine Type
Single cylinder, two-stroke
Engine Lubrication
Mixture oil lubrication
Ignition
AET digital EMS
Starter
Kick
Drivetrain
Final Drive
Chain
Gearbox
6-speed
Chassis
Wheel Travel - Front (in.)
8.1 inches
Wheel Travel - Front (mm)
205 mm
Wheel Travel - Rear (in.)
7.3 inches
Wheel Travel - Rear (mm)
185 mm
Frame Type
Central-tube frame with double-cradle
Suspension - Front
WP-USD, AER 35, 35 mm
Suspension - Rear
WP shock absorber
Wheels & Brakes
Brakes - Front Diameter (in.)
7.8 inches
Brakes - Front Diameter (mm)
198 mm
Brakes - Rear Diameter (in.)
6.3 inches
Brakes - Rear Diameter (mm)
160 mm
Brakes - Front
Single disc
Brakes - Rear
Single disc
Rims
Mirroring the full size motocross range, the TC 65 uses lightweight, black anodised, aluminium rims providing the highest strength and reliability. The standard MAXXIS tyres provide progressive grip on a variety of different terrain.
