Key Specifications
Engine
Four stroke, 60° V-Twin, DOHC, 4 valves per cylinder
Torque
72.2 lb-ft / 97.7 Nm @ 6000 rpm
Fuel Capacity
12.5 Litres / 3.3 US gal
Advertisement
Full 2021 Indian Scout Bobber Specifications
Year
2020 - 21
Make Model
Indian Scout Bobber
Seat Height
649 mm / 25.6 in
Wheelbase
1576 mm / 62 in
Ground Clearance
130 mm / 5.1 in
Height
1053 mm / 41.5 in
Length
2223 mm / 87.5 in
Width
926 mm / 36.5 in
Dry Weight
242 kg / 534 lbs
Fuel Capacity
12.5 Litres / 3.3 US gal
Maximum Load / GVWR
449 kg / 988 lbs
Wet Weight
251 kg / 555 lbs
Displacement
1133 cc / 69 cu-in
Engine Detail
Four stroke, 60° V-Twin, DOHC, 4 valves per cylinder
Bore x Stroke
99 x 73.6mm
Compression Ratio
10.7:1
Cooling System
Liquid Cooled
Exhaust
Split dual exhaust with crossover
Fuel Induction
Electronic fuel injection, closed loop / 60 mm bore
Lubrication
Semi-Dry Sump
Starter
Electric
Clutch
Wet, multi-plate
Final Drive
Belt, 2.357 : 1
Gear Ratios
1st 10.926 : 1 / 2nd 7.427 : 1 / 3rd 5.918 : 1 / 4th 5.022 : 1 / 5th 4.439 : 1 / 6th 3.810 : 1
Primary Drive
Gear drive wet clutch
Transmission / Drive
6 Speed sliding-mesh/foot shift
Suspension - Front
41mm Telescopic fork - cartridge type
Suspension - Rear
Dual shocks
Rake
29°
Trail
120 mm / 4.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
51 mm / 2.0 in
Brakes - Front
Single 298 mm rotor with 2 piston caliper
Brakes - Rear
Single 298 mm rotor with 1 piston caliper
Tyres - Front
130/90B16 76H
Tyres - Rear
150/80B16 77H
Wheels - Front
Cast black 16 in x 3.5 in
Wheels - Rear
Cast black 16 in x 3.5 in
