Full Specifications
General
Year
2014
Make Model
Kawasaki KLR 650
Dimensions
Seat Height
889 mm / 35 in
Wheelbase
1480 mm / 58.3 in
Ground Clearance
210 mm / 8.3 in
Height
1350 mm / 53.1 in
Length
2295 mm / 90.4 in
Width
960 mm / 37.8 in
Weights & Capacities
Fuel Capacity
23 Litres / 5.8 US gal.
Wet Weight
194 kg / 432 lbs
Performance
Max Power
42.1 hp / 31 kW @ 7000 rpm
Max Torque
47 Nm / 4.7 kgf-m @ 5000 rpm
Engine
Displacement
651 cc / 39.7 cu-in
Engine Detail
Four stroke, single cylinder, DOHC, 4 valves per cylinder
Bore x Stroke
100 x 83 mm.
Compression Ratio
9.8:1
Cooling System
Liquid cooled
Fuel Induction
Keihin CVK40
Ignition
Transistorized
Lubrication
Forced lubrication (wet sump)
Starter
Electric
Drivetrain
Clutch
Wet multi-disc, cable operation
Final Drive
Sealed Chain
Final Drive Ratio
2.867 (43/15)
Gear Ratios
1st 2.266 (34/15) 2nd 1.444 (26/18) 3rd 1.136 (25/22) 4th 0.954 (21/22) 5th 0.791 (19/24)
Primary Drive Ratios
2.272 / 75/33
Transmission / Drive
5 Speed
Chassis
Frame Type
Semi-double Cradle Made of high-tech, round-section, high-tensile steel
Suspension - Front
41mm Air-adjustable forks,
Suspension - Rear
Uni-Trak® linkage, 5-way preload shock absorber with 4way rebound damping.
Rake
28.0°
Trail
112 mm / 4.4 in
Wheel Travel - Front
200 mm / 7.8 in
Wheel Travel - Rear
185 mm / 7.2 in
Wheels & Brakes
Brakes - Front
Single 280mm disc 2 piston caliper
Brakes - Rear
Single 203mm disc 1 piston caliper
Tyres - Front
90/90 -21
Tyres - Rear
130/80 -17
