Key Specifications
Engine
In-line four, four-stroke
Torque
8.00 Nm (0.8 kgf-m or 5.9 ft.lbs)
Weight
265.0 kg / 584.3 lbs
Fuel Capacity
21.95 litres / 5.80 gallons
Advertisement
Full 2013 Kawasaki Ninja ZX-14R Specifications
Colours
Passion Red, Pearl Flat White, Metallic Spark Black/Golden Blazed Green (SE)
Warranty
12 months
Ground Clearance (mm)
124 mm
Ground Clearance (in.)
4.9 inches
Seat Height
800 mm / 31.5 in.
Wheelbase
1,481 mm / 58.3 in.
Height
1,171 mm / 46.1 in.
Length
2,169 mm / 85.4 in.
Width
770 mm / 30.3 in.
Fuel Capacity
21.95 litres / 5.80 gallons
Wet Weight
265.0 kg / 584.3 lbs
Bore x Stroke (in,)
3.3 x 2.6 inches
Bore x Stroke (mm)
84.0 x 65.0 mm
Displacement (cc)
1441.00 cc
Displacement (ci)
87.93 cubic inches
Engine Type
In-line four, four-stroke
Fuel Control
DOHC
Engine Detail
Reed valve.
Fuel System
Injection. DFI with four 44mm Mikuni throttle bodies
Compression Ratio
12.3:1
Engine Lubrication
Forced lubrication, wet sump
Ignition
TCBI with Digital Advance
Starter
Electric
Clutch
Centrifugal, wet multi-disc
Final Drive
Chain
Gearbox
6-speed
Primary Drive
X-Ring Chain
Frame Type
Aluminum perimeter
Suspension - Front
43mm inverted cartridge fork with adjustable preload, 18-way compression and 15-way rebound damping adjustment / 4.6 in.
Suspension - Rear
Bottom-link Uni-Trak and gas-charged shock with adjustable preload, stepless rebound and compression damping adjustments, adjustable ride height / 4.9 in.
Rake
23.0°
Trail
94 mm / 3.7 in.
Brakes - Front Diameter (in.)
12.2 inches
Brakes - Front Diameter (mm)
310 mm
Brakes - Rear Diameter (in.)
9.8 inches
Brakes - Rear Diameter (mm)
250 mm
Brakes - Front
Double disc. Petal discs with dual radial-mounted four-piston calipers and optional ABS
Brakes - Rear
Single disc. Petal disc with twin-piston caliper and optional ABS
Tyres - Front
2.50-14
Tyres - Front
120/70-ZR17
Tyres - Rear
190/50-ZR17
Tyres - Rear
3.00-12
