Key Specifications
Engine
Single cylinder, two-stroke
Weight
96.8 kg / 213.4 lbs
Fuel Capacity
9.00 litres / 2.38 US gallons
Advertisement
Full 2021 KTM 150 XC-W TPI Specifications
Ground Clearance (in.)
14.6 inches
Ground Clearance (mm)
370 mm
Seat Height
950 mm / 37.4 in.
Wheelbase
1471 mm / 57.9 in.
Dry Weight
96.8 kg / 213.4 lbs
Fuel Capacity
9.00 litres / 2.38 US gallons
Bore x Stroke (in,)
2.3 x 2.1 inches
Bore x Stroke (mm)
58.0 x 54.5 mm
Displacement (cc)
144.0 cc
Displacement (ci)
8.79 cubic inches
Engine Type
Single cylinder, two-stroke
Engine Detail
Reed intake.
Fuel System
Injection
Ignition
Continental EMS
Starter
Electric & kick
Clutch
Wet multi-plate clutch, Brembo hydraulics
Final Drive
Chain (final drive)
Gearbox
6-speed
Primary Drive
X-Ring 5/8 x 1/4´ chain
Frame Type
Central double-cradle-type 25CrMo4 steel
Suspension - Front
WP XPlor 48 upside-down fork
Suspension - Rear
WP Xplor PDS shock absorber
Rake
26.5°
Wheel Travel - Front
300 mm / 11.8 in.
Wheel Travel - Rear
310 mm / 12.2 in.
Brakes - Front
Single disc. Brembo twin-piston floating calliper
Brakes - Rear
Single disc. Brembo single-piston floating calliper
