Key Specifications
Engine
Four stroke, 90° V-twin, SOHC, 4 valves per cylinder
Power
71 kW / 96 hp @ 6500 rpm
Torque
121 Nm / 12.3 kgf-m / 89.2 ft/lb @ 3000 rpm
Fuel Capacity
20.5 Litres / 4.7 US gal
Advertisement
Full 2017 Moto Guzzi Audace Specifications
Year
2017
Make Model
Moto Guzzi Audace
Seat Height
740 mm / 29.1 in (Optimal 720 mm / 28.3 in)
Wheelbase
1685 mm / 66.3 in
Ground Clearance
165 mm / 6.4 in
Height
1180 mm / 46.5 in
Length
2445 mm / 90.2 in
Width
940 mm / 37.0 in
Fuel Capacity
20.5 Litres / 4.7 US gal
Wet Weight
299 kg / 659 lbs
Displacement
1380 cc / 84.2 cu-in
Engine Detail
Four stroke, 90° V-twin, SOHC, 4 valves per cylinder
Fuel System
Phased electronic multipoint sequential injection, Magneti Marelli IAW7SM; Øride by wireØ Ø 52 mm throttle body, IWP 243 Magneti Marelli injectors, double oxygen sensor, integrated management of 3 engine mappings, traction control, cruise control
Bore x Stroke
104 x 81.2 mm
Compression Ratio
10.5:1
Cooling System
Air and oil cooled
Exhaust
Stainless steel, 2-in-2 type, three-way catalytic converter with double oxygen sensor, Euro 4
Fuel Reserve
5 Litres / 1.3 US gal
Ignition
Electronic
Lubrication
Wet sump
Spark Plug
NGK LMAR8F, 2 per cylinder
Starter
Electric
Timing System Diagram
Intake valve opens 19° BTDC (1-mm checking clearance) intake valve closes 55° ABDC exhaust valve opens 49° BBDC exhaust valve closes 12° ATDC
Battery Capacity
12V - 18 Ah
Clutch
Single-disc with integrated anti-vibration buffer
Final Drive
Shaft
Final Drive Ratio
Double cardan joint and fixed bevel gear seat, drive ratio 10:36 = 1:3.6
Gear Ratios
1st 17:38 = 1:2.235 / 2nd 20:34 = 1:1.700 / 3rd 23:31 = 1:1.348 / 4th 26:29 = 1:1.115 / 5th 31:30 = 1:0.968 / 6th 30:24 = 1:0.8
Primary Drive
26:35 = 1:1.346
Transmission / Drive
6 speed with final overdrive
Frame Type
Steel tubing, closed double cradle with elastic kinematic engine mounting system to isolate vibrations.
Suspension - Front
Standard fork, ø45 mm, with radial caliper mounting bracket
Suspension - Rear
Swingarm with double shock absorber with adjustable extension and spring preload with remote tank
Rake
32°
Steering Angle
38°
Trail
155 mm / 6.1 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
120 mm / 4.7 in
Brakes - Front
2 x Ø320 mm stainless steel floating discs, Brembo radial calipers with 4 horizontally opposed pistons
Brakes - Rear
Single Ø282 mm stainless steel fixed disc, Brembo floating caliper with 2 parallel pistons
Tyres - Front
130/70 R18
Tyres - Rear
200/60 R16
Wheels - Front
Aluminium alloy 3.50" x 18"
Wheels - Rear
Aluminium alloy 6.00" x 16"
