Key Specifications
Engine
Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder
Fuel Capacity
20 Litres / 5.3 US gal / 4.4 Imp gal
Advertisement
Full 2020 Suzuki DL 1050 V-Strom Specifications
Year
2020
Make Model
Suzuki DL 1050 V-Strom
Seat Height
855 mm / 33.7 in
Wheelbase
1554 mm / 61.2 in
Ground Clearance
165 mm / 6.5 in
Height
1515 mm / 59.6 in
Length
2265 mm / 98.2 in
Width
870 mm / 34.3 in
Fuel Capacity
20 Litres / 5.3 US gal / 4.4 Imp gal
Wet Weight
236 kg / 520 lbs
Displacement
1037 cc / 63.2 cu-in
Engine Detail
Four stroke, 90°-V-twin, DOHC, 4 valves per cylinder
Bore x Stroke
100 x 66.0mm
Compression Ratio
11.5:1
Cooling System
Liquid cooled
Fuel Induction
EFI w/ 49mm throttle body
Ignition
Electronic ignition (transistorized)
Lubrication
Wet sump
Starter
Electric
Clutch
Wet, multiple-plate
Final Drive
RK 525 O-ring chain
Transmission / Drive
6 Speed
Frame Type
Aluminium, twin spar
Suspension - Front
43mm KYB fully adjustable inverted 43mm fork
Suspension - Rear
Linkage-assisted, rebound-damping and spring-preload adjustable shock
Rake
25.3°
Trail
109 mm / 4.3 in
Wheel Travel - Front
160 mm / 6.3 in
Wheel Travel - Rear
160 mm / 6.3 in
Brakes - Front
2 x 310mm discs, radially mounted 4-piston Tokico calipers
Brakes - Rear
Single 265mm disc, 2-piston Nissin caliper
ABS
Standard
Tyres - Front
110/80 x 19
Tyres - Rear
150/70 x 17
Wheels
Cast aluminum
