Key Specifications
Engine
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Power
55 kW / 74.8 hp @ 8750 rpm
Torque
68 Nm / 50 lb-ft @ 6500 rpm
Fuel Capacity
14 Litres / 3.7 US gal
Advertisement
Full 2023 Yamaha MT-07 Specifications
Year
2023
Make Model
Yamaha MT-07
Seat Height
805 mm / 31.7 in
Wheelbase
1400 mm / 55.1 in
Ground Clearance
140 mm / 5.5 in
Height
1105 mm / 43.5 in
Length
2085 mm / 82.1 in
Width
780 mm / 30.7 in
Fuel Capacity
14 Litres / 3.7 US gal
Wet Weight
184 kg / 406 lbs
Displacement
689 cc / 42.04 cu-in
Engine Detail
Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Bore x Stroke
80 x 68.6 mm
Compression Ratio
11.5:1
Cooling System
Liquid cooled
Emissions
Euro 5
Exhaust
Integrated 2-into-1 exhaust pipes and muffler
Fuel Induction
Mikuni 38 mm dual bore throttle body F.I.
Ignition
TCI Transistor Controlled Ignition
Lubrication
Wet sump
Starter
Electric
Clutch
Wet multiplate
Final Drive
Chain
Transmission / Drive
6 speed, constant mesh
Frame Type
Diamond
Suspension - Front
41mm Telescopic forks
Suspension - Rear
Single shock, adjustable preload and rebound damping
Rake
24.5°
Trail
90 mm
Wheel Travel - Front
130 mm / 5.1 in
Wheel Travel - Rear
130 mm / 5.1 in
Brakes - Front
2x 298mm discs, 4-piston calipers
Brakes - Rear
Single 245mm disc, single piston caliper
ABS
Standard
Tyres - Front
120/70 ZR17
Tyres - Rear
180/55 ZR17
