Key Specifications
Engine
Two cylinder boxer
Power
44.5 kW / 61 hp @ 5000 rpm
Torque
98 Nm / 10.0 kgf-m / 72.27 lb-ft @ 3000 rpm
Top Speed
164.8 km/h / 102.4 mph
Fuel Capacity
17.5 Litres / 4.5 gal
Advertisement
Full 2004 BMW R 1200CL Specifications
Year
2004
Year
2003 - 04
Colours
Silver, Blue, Brown
Make Model
BMW R 1200CL
Make Model
BMW R 1200CL
Seat Height
745 mm / 29.3 in
Seat Height
745 mm / 29.3 in
Wheelbase
1641 mm / 64.6 in
Wheelbase
1641 mm / 64.6 in
Height
1435 mm / 56.1 in
Height
1435 mm / 56.1 in
Length
2415 mm / 95.0 in
Length
2415 mm / 95.0 in
Width
1075 mm / 42.3 in
Width
1075 mm / 42.3 in
Dry Weight
289 kg / 637 lbs
Dry Weight
289 kg / 637 lbs
Fuel Capacity
17.5 Litres / 4.5 gal
Fuel Capacity
17.5 Litres / 4.5 gal
Wet Weight
308 kg / 679 lbs
Wet Weight
308 kg / 679 lbs
Stroke
4
Engine Type
Two cylinder boxer
Fuel Control
SOHC
Engine Type
Two cylinder boxer, four-stroke
CO2
118.3 CO
Displacement
1170 cc / 71.4 cu in.
Displacement
1170 cc / 71.4 cu in.
Engine Detail
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Detail
Four stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Fuel System
Injection
Bore x Stroke
101 x 73mm
Bore x Stroke
101 x 73mm
Compression Ratio
10.0:1
Compression Ratio
10.0:1
Cooling System
Air/Oil cooled
Cooling System
Air/Oil cooled
Fuel Consumption
5.1 L/100 km / 19.8 km/l / 46.5 US mpg
Fuel Consumption
5.1 L/100 km / 19.8 km/l / 46.5 US mpg
Fuel Induction
Bosch Motronic MA 2.4 Fuel injection
Fuel Induction
Bosch Motronic MA 2.4 Fuel injection
Fuel Reserve
4.00 litres / 1.06 gallons
Ignition
Digital CDI Bosch Electronic
Ignition
Digital CDI Bosch Electronic
Lubrication
Wet sump
Lubrication
Wet sump
Starter
Electric
Starter
Electric
Valve System
4
Battery Capacity
BMW Mareg, 19.5 Amp/h low maintenance
Battery Capacity
BMW Mareg, 19.5 Amp/h low maintenance
Clutch
Dry, single plate, hydraulic operated
Clutch
Dry, single plate, hydraulic operated
Final Drive
Shaft
Final Drive
Shaft
Gear Ratios
1st 2.045 / 2nd 1.600 / 3rd 1.267 / 4th 1.038 / 5th 0.800:1
Gear Ratios
1st 2.045 / 2nd 1.600 / 3rd 1.267 / 4th 1.038 / 5th 0.800:1
Gearbox
5-speed
Transmission / Drive
5 Speed
Transmission / Drive
5 Speed
Frame Type
Three section composite frame consisting of front & rear section, load bearing engine
Frame Type
Three section composite frame consisting of front & rear section, load bearing engine
Suspension - Front
Motorrad Telelever, stanchion ∅35mm, central strut
Suspension - Front
Motorrad Telelever, stanchion ∅35mm, central strut
Suspension - Rear
Die cast aluminium single sided swinging arm with BMW Motorrad Monolever, WAD strut (travel related damping), spring preload adjustable to continuously variable levels by means of hydraulic handwheel.
Suspension - Rear
Die cast aluminium single sided swinging arm with BMW Motorrad Monolever, WAD strut (travel related damping), spring preload adjustable to continuously variable levels by means of hydraulic handwheel.
Trail
86 mm / 3.4 in
Trail
86 mm / 3.4 in
Wheel Travel - Front
145 mm / 5.7 in
Wheel Travel - Front
145 mm / 5.7 in
Wheel Travel - Rear
110 mm / 4.3 in
Wheel Travel - Rear
110 mm / 4.3 in
Charging System
14 V 50 Amp Alternator (700 W)
Charging System
14 V 50 Amp Alternator (700 W)
Brakes - Rear Diameter (mm)
285 mm
Brakes - Rear Diameter (in.)
11.2 inches
Brakes - Front Diameter (mm)
305 mm
Brakes - Front Diameter (in.)
12.0 inches
Brakes - Front
2 x ∅305mm discs, 4 piston calipers
Brakes - Front
2 x ∅305mm discs, 4 piston calipers
Brakes - Rear
Single ∅285mm disc, 2 piston caliper
Brakes - Rear
Single ∅285mm disc, 2 piston caliper
Tyres - Front
100/90-18
Tyres - Front
100/90-18
Tyres - Rear
170/80-15
Tyres - Rear
170/80-15
Wheels - Front
2.50 x 18, 5-spoke alloy
Wheels - Front
2.50 x 18, 5-spoke alloy
Wheels - Rear
4.00 x 15, 5-spoke alloy
Wheels - Rear
4.00 x 15, 5-spoke alloy
