Key Specifications
Engine
In-line four, four-stroke
Torque
114.0 Nm (11.6 kgf-m or 84.1 ft.lbs) @ 9250 rpm
Fuel Capacity
4.40 US gallons
Advertisement
Full 2023 BMW S 1000R Specifications
Comments
Three Ride Modes (Rain, Road, Dynamic, incl. HSC). Six-axis sensor incl. ABS Pro and DTC.
Colours
Black Storm Metallic, Bluestone Metallic, Motorsport red/blue/white
Warranty
Width (mm)
845 mm
Width (in.)
33.3 inches
Wheelbase (mm)
1448 mm
Wheelbase (in.)
57.0 inches
Ground Clearance (in.)
Ground Clearance (mm)
Height (in.)
48.3 inches
Height (mm)
1228 mm
Storage
Seat Heigth -Alternate (mm)
Seat Heigth -Alternate (in.)
Seat Height (mm)
831 mm
Seat Height (in.)
32.7 inches
Length (in.)
81.0 inches
Length (mm)
2057 mm
Dry Weight (kg)
Dry Weight (lbs.)
Wet Weight (lbs.)
438.7 pounds
Wet Weight (kg)
199.0 kg
Fuel Capacity (gal.)
4.40 US gallons
Fuel Capacity (l)
16.65 litres
Weight balance - Rear
Weight balance - Front
Oil Capacity (Quarts)
3.7 US quarts
Oil Capacity (l)
3.50 litres
Coolant Capacity
Stroke
Fuel Reserve (l)
4.00 litres
Fuel Reserve (gal.)
1.06 US gallons
Bore x Stroke (in,)
3.1 x 2.0 inches
Bore x Stroke (mm)
80.0 x 49.7 mm
Fuel Control
Double Overhead Cams/Twin Cam (DOHC)
Engine Type
In-line four, four-stroke
CO2
155.4 CO2 g/km. (CO2 - Carbon dioxide emission)
Displacement (cc)
999.0 cc
Displacement (ci)
60.96 cubic inches
Engine Detail
Fuel System
Injection. Electronic port fuel injection, BMS-K+ electronic engine management with RPM cut-off, twin-spark ignition: BMS-O with ride by wire.
Compression Ratio
12.5:1
Emissions
Closed-loop 3-way catalytic converter, emission standard Euro 4
Engine Lubrication
Wet sump
Exhaust
Fuel Consumption
6.70 litres/100 km (14.9 km/l or 35.11 mpg)
Idle Speed
1250 +/- 50 RPM
Ignition
Oil Filtration
Spark Plug
NGK LMAR9D-J
Starter
Electric
Valve System
4
Chain Size
525
Clutch
Multi-disc oil bath (anti-hopping) with self-reinforcement
Final Drive
Chain (final drive)
Gearbox
6-speed
Number of Chain Links
Primary Drive
Sprocket
Sprocket
17/45 (front/rear)
Fork Tube Size (in.)
1.8 inches
Fork Tube Size (mm)
46 mm
Wheel Travel - Rear (mm)
117 mm
Wheel Travel - Rear (in.)
4.6 inches
Wheel Travel - Front (mm)
120 mm
Wheel Travel - Front (mm)
Wheel Travel - Front (in.)
4.7 inches
Wheel Travel - Front (in.)
Trail (mm)
99 mm
Trail (in.)
3.9 inches
Frame Type
Bridge-type aluminum laminate frame with load-bearing engine
Suspension - Front
Upside-down telescopic fork 46 mm, compression and rebound stage adjustable
Suspension - Rear
Aluminum swingarm, central shock absorber, adjustable rebound and compression damping and adjustable spring preload
Rake
24.8°
Seat
Instrumentation
TFT display with connectivity
Lighting system
LED lighting
Brakes - Front Diameter (in.)
Brakes - Front Diameter (mm)
Brakes - Rear Diameter (in.)
Brakes - Rear Diameter (mm)
Brakes - Front
Double disc. ABS. Floating discs. Four-piston calipers.
Brakes - Rear
Single disc. ABS. Floating disc. Single-piston caliper.
Brake Fluid Type
DOT 4
Rims
Cast aluminum
Tyre Pressure - Front
36 PSI (2.5 Bar or 250 kPa)
Tyre Pressure - Rear
42 PSI (2.9 Bar or 290 kPa)
Tyres - Front
120/70-ZR17
Tyres - Front
Tyres - Rear
Tyres - Rear
