Key Specifications
Engine
In-line four, four-stroke
Power
102 hp / 75 kW @ 12000 rpm
Torque
6.5 m-kg / 63.5 Nm @ 10500 rpm
Weight
193 kg / 425.5 lbs
Fuel Capacity
18 Litres / 4.2 gal
Advertisement
Full 2011 Honda CBR 600F Specifications
Year
2011
Colours
Black/yellow
Make Model
Honda CBR 600F
Ground Clearance (mm)
135 mm
Ground Clearance (in.)
5.3 inches
Seat Height
805 mm / 31.9 in
Wheelbase
1386 mm / 54.9 in
Ground Clearance
135 mm / 5.3 in
Height
1135 mm / 44.6 in
Length
2060 mm / 81.1 in
Width
685 mm / 26.9 in
Dry Weight
170 kg / 370 lbs
Fuel Capacity
18 Litres / 4.2 gal
Wet Weight
193 kg / 425.5 lbs
Fuel Control
DOHC
Engine Type
In-line four, four-stroke
Displacement
599 cc / 36.5 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Fuel System
Injection
Bore x Stroke
67 x 42,5 mm
Compression Ratio
12.0:1
Cooling System
Liquid cooled
Engine Lubrication
Wet sump
Fuel Consumption
19.8 km/it
Fuel Induction
PGM-FI electronic fuel injection. 36mm Throttle Bore
Fuel Reserve
4.00 litres / 1.06 gallons
Ignition
Computer-controlled digital transistorised with electronic advance
Lubrication
Wet sump
Starter
Electric
Valve System
4
Clutch
Wet, multiplate with coil springs
Final Drive
Chain
Gear Ratios
1st 2.750 (33/12) / 2nd 1.938 (31/16) /3rd 1.556 (28/18) / 4th 1.348 (31/23) 5th 1.208 (29/24) /6th 1.095 (23/21)
Gearbox
6-speed
Transmission / Drive
6 Speed
Frame Type
Mono-backbone; rectangular-section gravity die-cast aluminium
Suspension - Front
41mm inverted telescopic fork,
Suspension - Rear
Monoshock damper with 7-step adjustable preload,
Rake
24°
Trail
96.5 mm / 3.8 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
128 mm / 4.7 in
Lighting system
12V; 60/55W low and high headlights
Brakes - Front Diameter (in.)
11.7 inches
Brakes - Front Diameter (mm)
296 mm
Brakes - Rear Diameter (in.)
9.4 inches
Brakes - Rear Diameter (mm)
240 mm
Brakes - Front
2x 296mm discs 2 piston caliper
Brakes - Rear
Single 240mm disc 1 piston calipers
Tyres - Front
120/70ZR17
Tyres - Rear
180/55ZR17
