Key Specifications
Engine
Four stroke, parallel twin, DOHC, 4 valves per cylinder.
Power
53 kW / 72.1 hp @ 8500 rpm
Torque
66 Nm / 6.7 m-kg @ 7000 rpm
Fuel Capacity
16 Litres / 4.2 US gal
Advertisement
Full 2014 Kawasaki ER-6f Specifications
Year
2014
Make Model
Kawasaki ER-6f
Seat Height
805 mm / 31.7 in
Wheelbase
1410 mm / 55.5 in
Ground Clearance
130 mm / 5.1 in
Height
1210 mm / 47.6 in
Length
2105 mm / 82.9 in
Width
760 mm / 29.9 in
Fuel Capacity
16 Litres / 4.2 US gal
Wet Weight
209 kg / 460 lbs
Displacement
649 cc / 39.6 cu-in
Engine Detail
Four stroke, parallel twin, DOHC, 4 valves per cylinder.
Bore x Stroke
83 X 60mm
Compression Ratio
11.3;1
Cooling System
Liquid cooled,
Engine Oil Specification
Synthetic, 10-40
Fuel Induction
2x 38mm Electronic Fuel Injection Keihin
Ignition
Digital TCBI
Lubrication
Wet sump
Spark Plug
NGK, CR9EIA-9
Starter
Electric
Clutch
Wet, multiple discs, cable operated
Gear Ratios
1st 2.438 (39/16) 2nd 1.714 (36/21) 3rd 1.333 (32/24) 4th 1.111 (30/27) 5th 0.966 (28/29) 6th 0.852 (23/27)
Transmission / Drive
6 Speed
Frame Type
Perimeter, high-tensile steel
Suspension - Front
41 mm telescopic fork
Suspension - Rear
Offset laydown single-shock with adjustable preload
Rake
25°
Trail
106 mm / 4.1 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
130 mm / 5.1 in
Brakes - Front
2x 300mm discs 2 piston Calipers
Brakes - Rear
Single 220mm disc 1 piston Caliper
Tyres - Front
120/70ZR17
Tyres - Rear
160/60ZR17
