Key Specifications
Engine
Four stroke, parallel twin, DOHC, 4 valves per cylinder.
Power
51 kW / 69 hp @ 8500 rpm
Torque
64 Nm / 6.5 kg--m @ 7000 rpm
Fuel Capacity
21 Litres / 5.5 gal
Advertisement
Full 2015 Kawasaki KLE 650 Versys Specifications
Year
2015
Make Model
Kawasaki KLE 650 Versys
Seat Height
840 mm / 33.1 in
Wheelbase
1415 mm / 55.7 in
Ground Clearance
170 mm / 6.6 in
Height
1100 mm / 43.3 in
Length
2165 mm / 85.2 in.
Width
840 mm / 33.1 in.
Fuel Capacity
21 Litres / 5.5 gal
Wet Weight
216 kg / 476 lbs
Displacement
650 cc / 39.6 cu-in
Engine Detail
Four stroke, parallel twin, DOHC, 4 valves per cylinder.
Bore x Stroke
83 X 60mm
Compression Ratio
10.6:1
Cooling System
Liquid cooled
Fuel Induction
Fuel injection: Ø38 mm
Ignition
Digital CBI
Lubrication
Forced lubrication (semi-dry sump)
Starter
Electric
Clutch
Wet multi-disc, manual
Final Drive
Chain
Final Drive Ratio
3.067 (46/15)
Gear Ratios
1st 2.438 (39/16) 2nd 1.714 (36/21) 3rd 1.333 (32/24) 4th 1.111 (30/27) 5th 0.966 (28/29) 6th 0.852 (23/27)
Transmission / Drive
6 Speed
Frame Type
Diamond, high-tensile steel
Suspension - Front
41 mm inverted telescopic fork with stepless (right-side) adjustable rebound damping and adjustable preload.
Suspension - Rear
Offset laydown single-shock with 13-way adjustable rebound damping and 7-way adjustable preload.
Rake
25°
Trail
110 mm / 4.3 in
Wheel Travel - Front
150 mm / 5.9 in.
Wheel Travel - Rear
145 mm / 5.7 in
Brakes - Front
2x 300mm discs 2 piston calipers
Brakes - Rear
Single 220mm disc 1 piston caliper
Tyres - Front
120/70ZR17
Tyres - Rear
160/60ZR17M
