Key Specifications
Torque
111.00 Nm (11.3 kgf-m or 81.9 ft.lbs) @ 11300
Weight
230.0 kg / 507.1 lbs
Fuel Capacity
19.00 litres / 5.02 gallons
Advertisement
Full 2014 Kawasaki Z 1000SX Specifications
Colours
Black, green/black
Ground Clearance (in.)
5.3 inches
Ground Clearance (mm)
135 mm
Seat Height
820 mm / 32.3 in.
Wheelbase
1,445 mm / 56.9 in.
Height
1,170 mm / 46.1 in.
Length
2,105 mm / 82.9 in.
Width
790 mm / 31.1 in.
Fuel Capacity
19.00 litres / 5.02 gallons
Wet Weight
230.0 kg / 507.1 lbs
Bore x Stroke (in,)
3.0 x 2.2 inches
Bore x Stroke (mm)
77.0 x 56.0 mm
Displacement (cc)
1043.00 cc
Displacement (ci)
63.64 cubic inches
Engine Type
V2, four-stroke
Fuel Control
DOHC
Engine Detail
Reed valve.
Fuel System
Injection
Compression Ratio
11.8:1
Engine Lubrication
Forced lubrication, wet sump
Ignition
Digital
Starter
Electric
Valve System
4
Clutch
Wet multi-disc, manual
Final Drive
Chain
Primary Drive
Sealed chain
Frame Type
Aluminium twin-tube
Suspension - Front
41 mm inverted fork with stepless compression and rebound damping and spring preload adjustability
Suspension - Rear
Horizontal Back-link, gas-charged, with stepless rebound damping and remote spring preload adjustability
Rake
24.5°
Trail
102 mm / 4.0 in.
Brakes - Front Diameter (in.)
11.8 inches
Brakes - Front Diameter (mm)
300 mm
Brakes - Rear Diameter (in.)
9.8 inches
Brakes - Rear Diameter (mm)
250 mm
Brakes - Front
Double disc. Floating discs.
Brakes - Rear
Single disc
Tyres - Front
120/70-ZR17
Tyres - Rear
190/50-ZR17
