2022 KTM 1290 Super Duke GT Overview

The 2022 KTM 1290 Super Duke GT is a sport motorcycle built around 1301 cc of displacement. Under the tank sits a 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves engine. 2022 KTM 1290 Super Duke GT delivers 175 hp @ 9750 rpm of peak power and 141 Nm @ 7000 rpm of torque. From a practical standpoint, the 2022 1290 Super Duke GT tips the scales at 225 kg, carries a 23-litre fuel tank, offers a seat height of 835 mm and spans a 1482 mm ±15 mm wheelbase. Scroll down for the complete 2022 KTM 1290 Super Duke GT spec sheet covering every technical detail from suspension travel to tyre sizes.

2022 1290 Super Duke GT - Pros & Cons

Strengths

  • Strong power output: 2022 KTM 1290 Super Duke GT makes 175 hp @ 9750 rpm with 141 Nm @ 7000 rpm of torque - competitive figures for its class.
  • Large fuel range: The 23-litre tank is generously sized, translating to extended range between stops - ideal for touring or longer commutes.

Considerations

  • Tall seat height: The 835 mm seat height will challenge shorter riders - tiptoeing at low speeds is something to factor into your decision.

Owner Experiences & Common Issues

Low-speed confidence

At 225 kg, the 1290 Super Duke GT is a substantial machine. New owners occasionally mention that slow-speed manoeuvring in car parks takes a little getting used to. Once moving, the weight disappears - but practising slow-speed exercises builds confidence quickly.

1290 Super Duke GT - Buying & Maintenance Guide

What to check before buying

When inspecting a used 2022 KTM 1290 Super Duke GT, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained 1290 Super Duke GT should fire up cleanly and settle to a smooth idle within a few seconds.

Oil and filter changes

Regular oil changes are the single most important maintenance task on any 1290 Super Duke GT. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.

2022 KTM 1290 Super Duke GT - Frequently Asked Questions

What engine does the 2022 KTM 1290 Super Duke GT have?
The 2022 KTM 1290 Super Duke GT uses a 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves engine with 1301 cc of displacement. It is liquid cooling.
How much does the 2022 KTM 1290 Super Duke GT weigh?
The 2022 KTM 1290 Super Duke GT weighs 225 kg. This is the manufacturer's wet figure.
How much power does the 2022 KTM 1290 Super Duke GT make?
The 2022 KTM 1290 Super Duke GT produces 175 hp @ 9750 rpm of power and 141 Nm @ 7000 rpm of torque. These are peak figures.
What is the fuel tank capacity of the 2022 KTM 1290 Super Duke GT?
The 2022 KTM 1290 Super Duke GT has a 23-litre fuel tank. At around 5-6 litres per 100 km, that is roughly 383-460 km between stops.
Is the 2022 KTM 1290 Super Duke GT suitable for shorter riders?
The 2022 KTM 1290 Super Duke GT has a seat height of 835 mm. This is towards the tall end of the spectrum and will require most riders under 175 cm to tiptoe at stops.
What brakes does the 2022 KTM 1290 Super Duke GT have?
The 2022 KTM 1290 Super Duke GT uses 2x 320 mm discs, Brembo four-piston radial fixed calliper at the front and Single 240 mm disc, Brembo twin-piston fixed calliper at the rear.
What tyre sizes does the 2022 KTM 1290 Super Duke GT use?
The 2022 KTM 1290 Super Duke GT runs 120/70 x 17, Pirelli Angel GT front and 190/55 x 17, Pirelli Angel GT rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.
What gearbox does the 2022 KTM 1290 Super Duke GT have?
The 2022 KTM 1290 Super Duke GT is fitted with a 6-Speed with up/down quickshifter transmission.

KTM 1290 Super Duke GT Spec Evolution

The KTM 1290 Super Duke GT was produced across 8 model years (2016-2023). The table below highlights the key specifications that changed across the production run - useful whether you are comparing years or tracking down a specific variant.

Specification 2016 2017 2018 2019 2020 2021 2022 2023
Max Power 129 kW / 173 hp @ 129 kW / 173 hp @ 129 kW / 173 hp @ 173 hp / 129 kW @ 173 hp / 129 kW @ 173 hp / 129 kW @ 175 hp / 130.4 kW @ 9750 rpm 175 hp / 130.4 kW @ 9750 rpm
Wet Weight 228 kg / 506 lbs 228 kg / 506 lbs 228 kg / 506 lbs 225.4 kg / 497 lbs 225.4 kg / 497 lbs 225.4 kg / 497 lbs 225 kg / 496 lbs 223 kg / 492 lbs
Engine Detail 75º V twin, 4 stroke, DOHC, 4 valve 75º V twin, 4 stroke, DOHC, 4 valve 75° V twin, 4 stroke, DOHC, 4 valve 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves
Seat Height 835 mm / 32.9 in 835 mm / 32.9 in 835 mm / 32.9 in 835 mm / 32.9 in 835 mm / 32.9 in 835 mm / 32.9 in 835 mm / 32.9 in 835 mm / 32.8 in
Frame Type Chrome-moly steel trellis Chrome-moly steel trellis Chrome-moly steel trellis Chromemoly steel trellis Chromemoly steel trellis Chromemoly steel trellis Chrome-moly tubular space frame, powder-coated Chromoly steel trellis with cast-aluminum/composite subframe, powder-coated
Wheelbase 1482 mm ±15 mm / 58.34 in ±0.59 in 1482 mm ±15 mm / 58.34 in ±0.59 in 1482 mm ±15 mm / 58.34 in ±0.59 in 1482 mm ±15 mm / 58.34 in ± 0.59 in 1482 mm ±15 mm / 58.34 in ± 0.59 in 1482 mm ±15 mm / 58.34 in ± 0.59 in 1482 mm ±15 mm / 58.34 in ± 0.59 in 1482 mm ±15 mm / 58.3 in ± 0.59 in
Brakes - Front 320 mm Dual floating discs, Brembo M50 4-piston calipers, ABS 320 mm Dual floating discs, Brembo M50 4-piston calipers, ABS 320 mm Dual floating discs, Brembo M50 4-piston calipers, ABS 2x 320 mm floating discs, Brembo calipers, ABS 2x 320 mm floating discs, Brembo calipers, ABS 2x 320 mm floating discs, Brembo calipers, ABS 2x 320 mm discs, Brembo four-piston radial fixed calliper 2x 320 mm discs, Brembo four-piston radial fixed calliper
Ground Clearance 140 mm / 5.5 in 140 mm / 5.5 in 140 mm / 5.5 in 140 mm / 5.5 in 140 mm / 5.5 in 140 mm / 5.5 in 141 mm / 5.5 in 141 mm / 5.5 in

Key Specifications

Engine

75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves

Power

175 hp / 130.4 kW @ 9750 rpm

Torque

141 Nm / 104 lb-ft @ 7000 rpm

Top Speed

N/A

Weight

225 kg / 496 lbs

Fuel Capacity

23 Litres / 6.1 US gal

Advertisement

Full 2022 KTM 1290 Super Duke GT Specifications

Year 2022
Make Model KTM 1290 Super Duke GT
Max Power 175 hp / 130.4 kW @ 9750 rpm
Max Torque 141 Nm / 104 lb-ft @ 7000 rpm
Displacement 1301 cc / 79.4 cu in
Engine Detail 75° V twin, 4 stroke, DOHC, 4 valve per cylinder, titanium inlet valves
Bore x Stroke 108 x 71 mm
Cooling System Liquid cooling
Fuel Induction Keihin EFI, throttle body 56 mm
Ignition Keihin EMS with RBW and cruise control, dual ignition
Lubrication System Pressure lubrication, 3 Eaton pumps
Starter Electric
