2009 Suzuki GSX 1300 B-King Overview
The 2009 Suzuki GSX 1300 B-King is a naked bike motorcycle built around 1340 cc of displacement. Under the tank sits a Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder engine, a compression ratio of 12.5:1. 2009 Suzuki GSX 1300 B-King delivers 132.1 kW @ 9500 rpm of peak power and 146 Nm @ 7200 rpm of torque. The factory-quoted top speed stands at 252.9 km/h, making it a capable performer in its class. From a practical standpoint, the 2009 GSX 1300 B-King tips the scales at 235 kg, carries a 16.5-litre fuel tank, offers a seat height of 805 mm and spans a 1525 mm wheelbase. Scroll down for the complete 2009 Suzuki GSX 1300 B-King spec sheet covering every technical detail from suspension travel to tyre sizes.
2009 GSX 1300 B-King - Pros & Cons
Strengths
-
⚡
Strong power output: 2009 Suzuki GSX 1300 B-King makes 132.1 kW @ 9500 rpm with 146 Nm @ 7200 rpm of torque - competitive figures for its class.
Considerations
-
ℹ️
Age-related wear: As with any used GSX 1300 B-King, a thorough pre-purchase inspection covering consumables, service history and tyres is always recommended.
Owner Experiences & Common Issues
General ownership notes
The 2009 Suzuki GSX 1300 B-King has built a reputation for solid everyday reliability when serviced to schedule. As with any motorcycle of this era, documented service history is the single biggest indicator of long-term reliability when buying used.
GSX 1300 B-King - Buying & Maintenance Guide
What to check before buying
When inspecting a used 2009 Suzuki GSX 1300 B-King, start with the basics: check the service book for oil change frequency, inspect the chain and sprockets for wear, and look for oil seepage around the engine casings and rocker covers. A cold start test is invaluable - a well-maintained GSX 1300 B-King should fire up cleanly and settle to a smooth idle within a few seconds.
Oil and filter changes
Regular oil changes are the single most important maintenance task on any GSX 1300 B-King. Stick to the manufacturer's interval - typically every 6,000 km or once a year, whichever comes first. Always use the correct viscosity grade as specified in the owner's manual.
2009 Suzuki GSX 1300 B-King - Frequently Asked Questions
What engine does the 2009 Suzuki GSX 1300 B-King have?
The 2009 Suzuki GSX 1300 B-King uses a Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder engine with 1340 cc of displacement. It is liquid cooled.
What is the top speed of the 2009 Suzuki GSX 1300 B-King?
The 2009 Suzuki GSX 1300 B-King has a factory-quoted top speed of 252.9 km/h. Real-world speeds vary depending on rider weight, conditions and state of tune.
How much does the 2009 Suzuki GSX 1300 B-King weigh?
The 2009 Suzuki GSX 1300 B-King weighs 235 kg. This is the manufacturer's dry figure.
How much power does the 2009 Suzuki GSX 1300 B-King make?
The 2009 Suzuki GSX 1300 B-King produces 132.1 kW @ 9500 rpm of power and 146 Nm @ 7200 rpm of torque. These are peak figures.
What is the fuel tank capacity of the 2009 Suzuki GSX 1300 B-King?
The 2009 Suzuki GSX 1300 B-King has a 16.5-litre fuel tank.
Is the 2009 Suzuki GSX 1300 B-King suitable for shorter riders?
The 2009 Suzuki GSX 1300 B-King has a seat height of 805 mm. This is a moderate seat height that suits a wide range of rider heights.
What brakes does the 2009 Suzuki GSX 1300 B-King have?
The 2009 Suzuki GSX 1300 B-King uses 2 x 310 mm Discs, 4 piston calipers at the front and Single 260m disc, 1 piston caliper at the rear.
What tyre sizes does the 2009 Suzuki GSX 1300 B-King use?
The 2009 Suzuki GSX 1300 B-King runs 120/70 ZR17 front and 200/50 ZR17 rear tyres. A good selection of sport, touring and all-weather rubber is available in these sizes.
What gearbox does the 2009 Suzuki GSX 1300 B-King have?
The 2009 Suzuki GSX 1300 B-King is fitted with a 6 Speed transmission.
Key Specifications
Engine
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Power
132.1 kW / 181.5 hp @ 9500 rpm
Torque
146 Nm / 14.9 kgf-m / 108 lb-ft @ 7200 rpm
Top Speed
252.9 km/h / 157.1 mph
Weight
235.0 kg / 518.1 lbs
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Advertisement
Full 2009 Suzuki GSX 1300 B-King Specifications
Year
2009
Year
2009
Make Model
Suzuki GSX 1300 B-King
Make Model
Suzuki GSX 1300 B-King
Seat Height
805 mm / 31.7 in
Seat Height
805 mm / 31.7 in
Wheelbase
1525 mm / 60.0 in
Wheelbase
1525 mm / 60.0 in
Ground Clearance
120 mm / 4.7 in
Ground Clearance
120 mm / 4.7 in
Length
2245 mm / 88.4 in
Length
2245 mm / 88.4 in
Width
800 mm / 31.5 in
Width
800 mm / 31.5 in
Dry Weight
235.0 kg / 518.1 lbs
Dry Weight
235.0 kg / 518.1 lbs
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Fuel Capacity
16.5 Litres / 4.4 US gal / 3.6 Imp gal
Displacement
1340 cc / 81.8 cu-in
Displacement
1340 cc / 81.8 cu-in
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Engine Detail
Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Bore x Stroke
81 x 65 mm
Bore x Stroke
81 x 65 mm
Compression Ratio
12.5:1
Compression Ratio
12.5:1
Cooling System
Liquid cooled
Cooling System
Liquid cooled
Exhaust
4-into-2-into-1 exhaust system with a large capacity catalyzer, oxygen sensors and an oval cross section canister with dual openings that meets Euro 3 and Tier 2 regulation
Exhaust
4-into-2-into-1 exhaust system with a large capacity catalyzer, oxygen sensors and an oval cross section canister with dual openings that meets Euro 3 and Tier 2 regulation
Fuel Consumption
6.2 L/100 km / 16.1 km/l / 38 US mpg / 45 Imp mpg
Fuel Consumption
6.2 L/100 km / 16.1 km/l / 38 US mpg / 45 Imp mpg
Fuel Induction
Fuel injection . Suzuki SDTV fuel injection system with dual injectors per cylinder and ram air intake with large volume airbox
Fuel Induction
Fuel injection . Suzuki SDTV fuel injection system with dual injectors per cylinder and ram air intake with large volume airbox
Ignition
Electronic
Ignition
Electronic
Lubrication
Wet sump
Lubrication
Wet sump
Starter
Electric
Starter
Electric
Clutch
Wet, multiple discs, hydraulic operated
Clutch
Wet, multiple discs, hydraulic operated
Final Drive
Chain, RK GB50GSV Z4, 118 links
Final Drive
Chain, RK GB50GSV Z4, 118 links
Transmission / Drive
6 Speed
Transmission / Drive
6 Speed
Frame Type
Twin-spar cast aluminum alloy
Frame Type
Twin-spar cast aluminum alloy
Suspension - Front
Inverted telescopic coil springs, spring preload, rebound and compression damping fully adjustable.
Suspension - Front
Inverted telescopic coil springs, spring preload, rebound and compression damping fully adjustable.
Suspension - Rear
Link type, oil damped, coil springs, spring preload, rebound and compression damping fully adjustable.
Suspension - Rear
Link type, oil damped, coil springs, spring preload, rebound and compression damping fully adjustable.
Rake
25.7°
Rake
25.7°
Trail
107 mm / 4.2 in
Trail
107 mm / 4.2 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Front
120 mm / 4.7 in
Wheel Travel - Rear
137 mm / 5.4 in
Wheel Travel - Rear
137 mm / 5.4 in
Brakes - Front
2 x 310 mm Discs, 4 piston calipers
Brakes - Front
2 x 310 mm Discs, 4 piston calipers
Brakes - Rear
Single 260m disc, 1 piston caliper
Brakes - Rear
Single 260m disc, 1 piston caliper
Tyres - Front
120/70 ZR17
Tyres - Front
120/70 ZR17
Tyres - Rear
200/50 ZR17
Tyres - Rear
200/50 ZR17
Wheels - Front
3.50 x 17
Wheels - Front
3.50 x 17
Wheels - Rear
6.00 x 17
Wheels - Rear
6.00 x 17
